StarTech.com EC1U2F User manual
Manual Revision: 12/15/2011
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
EC1U2F
1 Port USB 2.0 & 2 Port FireWire
ExpressCard/34 Adapter Card
*actual product may vary from photos
Instruction Manual
i
Table of Contents
Introduction ...........................................................................................1
Features ........................................................................................................................................................ 1
Package Contents ..................................................................................................................................... 1
System Requirements.............................................................................................................................. 1
Installation ..............................................................................................2
Connecting FireWire and USB devices to the ExpressCard........................................................ 2
Basic troubleshooting ...........................................................................2
Specications..........................................................................................3
Technical Support ..................................................................................4
Warranty Information............................................................................4
Instruction Manual
1
Introduction
Thank for purchasing a StarTech.com 2 Port Firewire and 1 Port USB 2.0 ExpressCard
adapter. Providing a versatile connectivity solution, this device oers data transfer
rates of up to 480Mbps (when used with high-speed USB peripherals), and 400Mbps
(FireWire), providing the ideal platform for connecting any FireWire or USB peripheral.
Features
• USB 2.0 and IEEE-1394a compliant
• Supports USB transfer rates up to 480 Mbps and USB 1.1 transfer rates up to 12
Mbps
• Supports FireWire 100/200/400 Mbps transfer rates
• Compliant with ExpressCard/34 Type II standard
Package Contents
• 1 x ExpressCard Adapter
• 1 x Instruction Manual
System Requirements
• One available ExpressCard Slot
• Windows 2000/ XP/ Vista/ 7
Instruction Manual
2
Installation
1. Insert the ExpressCard into an available ExpressCard/54 or 34mm slot. Since this
card is hot-pluggable, this can be performed while the computer is on or o. Once
the card has been inserted, ensure the computer is powered, to proceed with
installation.
2. Windows will detect that the card has been inserted, and will prompt for driver
installation. To install the necessary software, follow the on-screen instructions.
Once the driver has been installed, the operating system will notify you that your
new hardware is ready for use.
Connecting FireWire and USB devices to the ExpressCard
To begin using your FireWire and USB peripherals with EC1U2F, simply insert the
FireWire or USB connector provided by the peripheral or attached cable as appropriate
into one of the ports provided by the ExpressCard.
Once USB and/or FireWire devices are connected to the ExpressCard, Windows will
request the required drivers for each device respectively. For further information
regarding the attached peripheral drivers, please consult the documentation that
accompanied the purchase of the peripheral device(s).
Please note: For peripherals requiring lower voltages, EC1U2F oers built-in power
capability. If more power is required, an external 5VDC power adapter (not included
with EC1U2F) can be connected to the power port on the ExpressCard.
Basic troubleshooting
If you nd that the peripherals connected to EC1U2F (in the powered state) are not
functioning, or are not being detected, please ensure the following:
1. The drivers have been installed.
2. Any previous driver installations (if this product has been previously installed) have
been removed.
3. There are no conicts with other device drivers. To determine this:
a. Browse to the Device Manager, by right-clicking on My Computer, and selecting
Manage. In the left pane, click on Device Manager.
b. Look for any exclamation marks (!) or question marks (?) listed next to the
FireWire controller card, in the right pane.
Instruction Manual
3
Specications
Bus Type ExpressCard 1.0a
Form Factor ExpressCard/34 (34mm)
Chipset ID TI XIO2200
Connectors 1 x USB 2.0 Type A
2 x FireWire 6-pin
Power Adapter Optional: 5V DC, 1A (not included)
Maximum Data Transfer Rate USB 2.0: 480Mbps
FireWire400: 400Mbps
OS Support Windows 2000/ XP/ Vista/ 7
Regulatory Certications CE, ROHS, FCC
Instruction Manual
4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
