StarTech.com ICUSB1284D25 System manual

6 ft USB to DB25 Parallel Printer Adapter Cable - M/F

StarTech ID: ICUSB1284D25

The ICUSB1284D25 6 ft USB to DB25 Parallel Printer Adapter Cable turns an available USB port on a host PC into

a DB25 Female Parallel port - allowing you to connect a DB25 printer to the computer as if the necessary parallel

port was built-on.

A cost-effective and reliable solution, the USB to DB25 adapter saves the expense of replacing a parallel printer for

the sake of USB capability.

Backed by a StarTech.com 2-year warranty and free lifetime technical support .

Applications

Allows you to quickly add a parallel port to your computer for use with printers with DB25 connectors

Ideal solution for notebooks or desktops without a Parallel port

Features

Fully Plug & Play for easy installation

USB bus-powered operation, no external power adapter required

Eliminates the need for manual or automatic parallel switch boxes

uk.startech.com

0800 169 0408

Technical Specifications

Warranty 2 Years

Chipset ID Prolific - PL-2305

Ports 1

Bus Type USB 2.0

Connector Type(s) 1 - DB-25 (25 pin; D-Sub) Female

Connector Type(s) 1 - USB A (4 pin) Male

Maximum Data Transfer Rate 1.5Mbps

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000, 98SE

Mac OS 10.4 and up (Tested up to 10.8)

Product Length 1.9 m [6.1 ft]

Product Weight 100 g [3.5 oz]

Operating Temperature 5°C to 40°C (41°F to 140°F)

Storage Temperature -20°C to 70°C (-4°F to 158°F)

Humidity 0~80% RH non-condensing

Shipping (Package) Weight 0.1 kg [0.3 lb]

Included in Package 1 - USB to Parallel Adapter Cable

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

uk.startech.com

0800 169 0408

Certifications, Reports and Compatibility

uk.startech.com

0800 169 0408
