One Year Warranty
This product is warranted to be free of manufacturing defects for a 1-year period from
the original consumer date of purchase. The warranty does not include damage to the
product resulting from accident, misuse, improper installation, operation, or
unauthorized repair or alteration. Opening the product case will void this warranty. If the
product should become defective within the warranty period, Sports Radar Ltd., will
repair or replace it at our option, free of charge. You must fill out and return the enclosed
registration form to ensure warranty coverage. Failure to fill out registration form may
void warranty. To obtain warranty service, first contact Sports Radar’s warranty repair
department, then, upon approval, send the unit at purchaser's cost to:
Sports Radar, Ltd., 9119 W. Veterans Dr., Homosassa, FL 34448
Return shipping to purchaser will be at Sports Radar Ltd.’s cost inside the 48 continental
united states, international shipping is the sole responsibility of the purchaser.
The consumer's sole remedy shall be such repair or replacement as is expressly provided
above, and we shall in no event be liable for any incidental or consequential damages
arising out of the use or inability to use this product for any purpose whatsoever. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. This warranty gives you specific
rights. You may also have other rights, which vary, from state to state.
Manufactured by Sports Radar, Ltd. in the U.S.A.
SPECIFICATIONS: DL431
Mechanical Width12-1/4”, Height 6-3/8”, Depth1-1/2”; Weight 1.5lb
Display Type Light Emitting Diode (LED), Color RED, Character height: 4”
Voltage 6VDC minimum, 14VDC maximum
Current 0.5A in the high bright mode, 0.3A in the normal bright mode
Visibility 200 feet typical in shaded light
Input RJ45, 8/8 jack
Data Format RS232, 1200 Baud (SR standard protocol)
Mounting 1/4-20 thread nut (standard tripod type) and wall mount clips
Temperature Operating 40-110 deg F. Storage 30-125 deg F
*******************OPTIONAL ACCESSORIES*******************
*WA6VDC: Power supply, plugs into a standard 110VAC household outlet.
*AA12VDC: Power supply adapter, plugs into a standard automotive accessory outlet.
*TRI-POD: For mounting the Display or Radar Gun at various heights on a playing fields. Tri pod
has universal mounting 1/4-20 threads that will work with most cameras and camcorders.
*Tabletop Stand: Sturdy low profile mounting stand.
*USM: A universal mounting bracket for wall or post mounting.
*RDL-TX35 and RDL-RX: Wireless Adapter for connecting the DL431 to an SR3500 Radar gun,
requires RJ11-RJ45 special cable, consult your dealer prior to ordering.
*Extender RJ45-8/8 cables, sold in 25’ and 50’ lengths, can be stacked up to 100 feet between the
radar gun and the DL431 for data communications.
*Coupler: RJ45-8/8 coupler for extender cables
The DL431 is not waterproof and should be kept clean and dry.
Instruction Manual
DL431 LED DISPLAY
Congratulations
On your purchase of the Sports Radar DL431 remote LED display,
designed to provide coaches, sports enthusiast and fans the same
visibility to performance as the users. Please read this manual before
operating your new products.
If at any time you need additional information, or experience problems
with your Sports Radar product, please contact Sports Radar, Ltd. directly.
All warranty information is located at our offices, therefore it is important
that you contact us, not your retailer. Sports Radar products are thoroughly
tested and inspected prior to shipping, and most issues can be resolved
with a phone call. However mishaps do occur, so be sure to fill out and
return the warranty card, as any product return is subject to verification of
roper return authorization. Information and authorization number may be
obtained by writing or calling our offices or log on to
www.sportsradargun.com and fill out the RMA request.
Sports Radar, Ltd.
9119 W. Veterans Dr.
Homosassa, FL 34448
℡352-563-5298
htpp://www.sportsradargun.com
Contact your retailer for available accessories.
Read this instruction manual completely before connecting power or data to theDL431
