Spirit XBR55 User manual

XBR55 Fitness BIke

OWNER’S MANUAL

Please carefully read this entire manual before operating your new tness bike

TABLE OF CONTENTS

ATTENTION

This tness bike is intended for residential use only and is warranted for this

application. Any other application voids this warranty in its entirety.

Product Registration

Important Safety Instructions

Important Electrical Instructions

Important Operation Instructions

XBR55 Assembly Instructions

Features

Console Operation

Programmable Features

Using Heart Rate Transmitter

General Maintenance

Manufacturer’s Limited Warranty

XBR55 Fitness Bike

RECORD YOUR SERIAL NUMBER

Please record the Serial Number of this tness product

in the space provided below.

Serial Number

The self-addressed product registration card must be completed in full and returned to

Spirit Manufacturing, Inc. You can also go to www.spirittness.com/warranty.asp under

the support tab to register online.

Thank you for your purchase of this quality tness bike from Spirit Manufacturing, Inc. Your

new tness bike was manufactured by one of the leading tness manufacturers in the world

and is backed by one of the most comprehensive warranties available. Through your dealer,

Spirit will do all we can to make your ownership experience as pleasant as possible for many

years to come. If not purchased direct from Spirit, the local dealership where you purchased

this tness bike is your administrator for all Spirit warranty and service needs. Their

responsibility is to provide you with the technical knowledge and service personnel to

make your experience more informed and any difculties easier to remedy.

Please take a moment at this time to record the name of the dealer, their telephone number,

and the date of purchase below to make any future, needed contact easy. We appreciate

your support and we will always remember that you are the reason that we are in business.

Please complete and mail your registration card today and enjoy your new tness bike.

Yours in Health,

Spirit Manufacturing, Inc.

Congratulations on your new tness bike and welcome to the Spirit family!

Name of Dealer

Dealer Phone #

Purchase Date

PRODUCT REGISTRATION

XBR55_20110118

XBR55 Fitness Bike 2

IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this appliance.

DANGER - To reduce the risk of electric shock disconnect your Spirit tness bike from

the electrical outlet prior to cleaning and/or service work.

WARNING - To reduce the risk of burns, re, electric shock, or injury to persons, install

the tness bike on a at level surface with access to a 110-volt, 15-amp grounded outlet

with only the tness bike plugged into the circuit.

DO NOT USE AN EXTENSION CORD UNLESS IT IS A 14AWG OR BETTER, WITH

ONLY ONE OUTLET ON THE END:

Do not operate tness bike on deeply padded, plush or shag carpet. Damage to both

carpet and tness bike may result.

Keep children away from the tness bike. There are obvious pinch points and other

caution areas that can cause harm.

Keep hands away from all moving parts.

Never operate the tness bike if it has a damaged cord or plug. If the tness bike is

not working properly, call your dealer.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is

being administered. Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

Do not use outdoors.

To disconnect, turn all controls to the off position, then remove the plug from

the outlet.

Do not attempt to use your tness bike for any purpose other than for the purpose it

is intended.

The hand pulse sensors are not medical devices. Their purpose is to provide you

with an approximate measurement in relation to your target heart rate. Use of a chest

transmitter strap is a much more accurate method of heart rate analysis . Various

factors, including the user’s movement, may affect the accuracy of heart rate

readings. The pulse sensors are intended only as exercise aids in determining heart

rate trends in general.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for

use on your tness bike. Quality athletic shoes are recommended to avoid leg fatigue.

SAVE THESE INSTRUCTIONS - THINK SAFETY!

XBR55 Fitness Bike

WARNING!

NEVER remove any cover without rst disconnecting AC power. If voltage varies by ten

percent (10%) or more, the performance of your tness bike may be affected. Such

conditions are not covered under your warranty. If you suspect the voltage is low, contact

your local power company or a licensed electrician for proper testing.

NEVER expose this tness bike to rain or moisture. This product is NOT designed for

use outdoors, near a pool or spa, or in any other high humidity environment. The

operating temperature specication is 40 to 120 degrees Fahrenheit, and humidity is

95% non-condensing (no water drops forming on surfaces).

IMPORTANT ELECTRICAL INSTRUCTIONS

NEVER operate this tness bike without reading and completely understanding the

results of any operational change you request from the computer.

Understand that changes in resistance do not occur immediately. Set your

desired resistance level on the computer console and release the adjustment key.

The computer will obey the command gradually.

NEVER use your tness bike during an electrical storm. Surges may occur in your

household power supply that could damage tness bike components. Unplug the

tness bike during an electrical storm as a precaution.

Use caution while participating in other activities while pedaling on your tness bike;

such as watching television, reading, etc. These distractions may cause you to lose

balance which may result in serious injury.

Do not use excessive pressure on console control keys. They are precision set to

function properly with little nger pressure.

IMPORTANT OPERATION INSTRUCTIONS

XBR55 Fitness Bike 4

ASSEMBLY TOOLS

1. Using a razor knife (Box Cutter), cut the banding straps that wrap around

the carton. Reach under the bottom edge of the carton and pull it away

from the cardboard underneath, separating the staples that join the two

together. Lift the box over the unit and unpack.

2. Carefully remove all parts from carton and inspect for any damage or

missing parts. If damaged parts are found, or parts are missing, contact

your dealer immediately.

3. Locate the hardware package. The hardware is separated into four steps.

Remove the tools rst. Remove the hardware for each step as needed to

avoid confusion. The numbers in the instructions that are in parenthesis (#)

are the item number from the assembly drawing for reference.

PRE-ASSEMBLY

XBR55 ASSEMBLY INSTRUCTIONS

#114. Phillips Head

Screwdriver

#115. L Allen

Wrench

#112. 12/14mm

Wrench

#130. 13/14mm

Wrench

#113. 13/15mm

Wrench

XBR55 Fitness Bike

1. Attach the Rear Stabilizer (7) to the Main Frame (1) with the four Hex Head Bolts (65) and four

Flat Washers (84). Tighten completely with the wrench (112).

2. Attach the Seat Back (5) to the Seat Carriage (4) of the main frame. Slide a Hex Head Bolt (67)

through each side, then attach a Nyloc Nut (89) to each bolt. Tighten the bolts just enough so

there is no side to side play, but freedom of movement front to back. Use the wrenches pro-

vided (112 & 130).

REAR STABILIZER & SEAT BACK ASSEMBLY

#89. 3/8” x 7T

Nyloc Nut

(2 pcs)

#84. 3/8” x 25 x 2T

Flat Washer

(4 pcs)

HARDWARE

#65. 3/8” x 2-1/4”

Hex Head Bolt

(4 pcs)

#67. 3/8” x 4”

Hex Head Bolt

(2 pcs)

XBR55 Fitness Bike 6

1. Slide the Computer Cable (44), Handlebar resistance control cable (148), and Hand pulse cable

(133) through the bottom of the Console Mast Cover (31) and then the bottom of the Console

Mast (2). Make sure the Console Mast Cover is correctly oriented (see illustration).

2. Install the Console Mast (2) into the receiving tube (make sure not to pinch cables; damage to

the electronics could occur) of the Main Frame (1). Insert two Hex Head Bolts (68) and two Flat

Washers (76) on each side. Insert two Hex Head Bolts and two Curved Washers (83) on the

front. Tighten all six bolts rmly with the Wrench (112).

3. Remove the white Styrofoam pad (factory installed to prevent bolts from being accidentally

dropped into the console mast tube).

4. Attach the Handle Bar Assembly (3) onto the Console Mast (2) bracket with the two Hex Head

Bolts (68), two Split Washers (82), and two Flat Washers (76). Completely tighten with the

wrench (112).

5. Insert the Computer Cable (44), Handlebar resistance control cable (148), and Hand Pulse Cable

(133) into their respective connectors in the back of the Console Assembly (19). Attach the

console onto the mounting plate with four Phillips Head Screws (99). Tighten with the Phillips

Head Screw Driver (114).

CONSOLE MAST ASSEMBLY

#82. 8 x 1.5T

Split Washer

(2 pcs)

#83. 5/16” x 19 x 1.5T

Curved Washer

(2 pcs)

#76. 5/16” x 18 x 1.5T

Flat Washer

(6 pcs)

HARDWARE

#68. 5/16” x 15mm

Hex Head Bolt

(8 pcs)

#99. M5 x 12mm

Phillips Head Screw

(4 pcs)

XBR55 Fitness Bike

1. Install the Seat (61) on the Seat Carriage (4) with four Phillips Head Screws (98). Tighten with the

Phillips Head Screw Driver (114).

2. Attach the Seat Handle Bar (6) to the Seat Carriage (4) with the four Hex Head Bolts (71), four

Flat Washers (77), and four Nyloc Nuts (89). Tighten with the wrenches provided (112 & 130).

3. Plug the Hand Pulse Sensor Cables (27) into the rear two holes on the left side of the rear

plastic cover. Plug the Handlebar resistance cables (150) into the remaining front hole.

4. Attach the Front Stabilizer Cover (32) and the Rear Stabilizer Cover (37) to the Main Frame with

four Phillips Head Screws (99). Tighten with the Phillips Head Screw Driver (114).

SEAT & HANDLE BAR ASSEMBLY

#98. M6 x 15mm

Phillips Head Screw

(4 pcs)

#89. 3/8” x 7T

Nyloc Nut

(4 pcs)

HARDWARE

#99. M5 x 12mm

Phillips Head Screw

(4 Pcs)

#77. 3/8” x 19 x 1.5T

Flat Washer

(4 Pcs)

#71. 3/8” x 1-3/4”

Hex Head Bolt

(4 Pcs)
