ERROR CODES / DIAGNOSTICS
Note: most error conditions require mains power to be turned OFF
and back ON before the error is cleared.
ER2 - HEATER PLUG: Heater sensor cable fault. Check the
"Heater" sensor lead is plugged firmly into the spa control.
ER3 - WATER PRIME: Heater tube failed to fill with water. Press
Pump A button to retry water prime. Check spa water level, clean
and soak filters, bleed potential air locks from pipework.
ER4 - THERMAL TRIP: Low or NO water flow over element whilst
heating has activated thermal cut-out device on heater. Turn mains
power OFF and wait 20~30 minutes for heater to cool and thermal
cut-out to reset. Check spa water level, clean & soak filters, check
all shut-off valves are open, bleed potential air locks from pipework.
ER5 - POOL TOO HOT: Temperature sensor has reported a
o
temperature reading in excess of 45 C. Remove spa cover & allow
spa to cool. Check daily filtration time & reduce setting if required.
ER6 - HEATER SENSOR: Communication between spa control
and heater has been lost. Turn mains power OFF and unplug and
reconnect "Heater" sensor lead from spa control.
ER7 - IN POOL SENSOR: In Pool Temperature Sensor has
faulted. Contact your local dealer. Disconnect "In Pool Sensor" lead
from spa control to continue spa operation.
ER8 - CTRL FAULT: An internal controller fault has been detected.
Reset mains power. Contact your local dealer if problem persists.
RAMPING BLOWER MODE
The spa controller features a ramping blower mode,
were the blower speed gradually fluctuates between
high and low in a ramping manner.
To turn the blower on in ramping mode:
1) Press the BLOWER ( ) button twice to start
the blower in ramping mode. The blower will turn
ON and the screen will display [RAMP] to indicate
ramping mode.
2) Press the BLOWER ( ) button again to turn
the blower OFF.
ONE-TOUCH SANITISE BUTTON
A sanitise cycle runs the filtration pump and ozone /
uv (if fitted) to filter the spa water to restore and
refresh water quality after use.
In addition, at the start and end of the cycle, the
controller will sequentially run any additional pumps
and the blower (if fitted) for one minute each to
purge the plumbing and clear any unfiltered water
trapped in those lines.
To activate a 20 minute water clean-up cycle:
1) Press the SANITISE ( ) button once after spa
use to activate the water clean [W.CLN] cycle.
Note:
SANITISE
If cycle running, cycle can be cancelled by
pressing the button again.
AIR BLOWER BUTTON
The BLOWER ( ) button is used to control the air
blower and allow adjustment of the blower speed.
The last used speed is saved and will be restored the
next time the blower is turned on, for future ON/OFF
use. Note: that when the blower is first turned on it will run
at maximum speed for approx three seconds before
changing to your preset speed; this is normal.
To turn the blower on/off:
1) Press the BLOWER ( ) button once to turn
the blower ON in variable speed mode.
2) The blower will turn ON (at the last used speed)
and the screen will display the blower speed
[B.SPD] adjustment screen (refer below).
3) Use the UP ( ) or DOWN ( ) buttons to
adjust the blower speed. Note: the bar graph will
change indicating current blower speed.
4) Press the OK ( ) button to confirm selection.
5) Press the BLOWER ( ) button again to turn
the blower OFF.
Note: The B.SPD adjustment screen is displayed for 10
seconds when the blower is first turned ON. If no
adjustment is made the blower will run at the last used
speed setting, and the screen will time-out and revert to the
default display mode. If you wish to adjust the blower speed
once the blower has been running for a period of time, the
blower must be turned OFF and back ON again to restore
the B.SPD adjustment screen.
OK
SA SU MO TU WE TH FR
SET TEMP
SET TEMP
°C
°F
°C
°F
°C
°F
MODE
SPD
BRT
MODE
BRT
SPD
OFF
ON
AM
PM
AM
PM
:
2000
6.SPD
:
10 30
:
2 35 4 0.0
Bargraph indicates blower speed
LIGHT BUTTONS
The light button is used to control the many features
of the multi colour LED spa light.
( ) LIGHT ON / OFF BUTTON
Press to toggle light ON and OFF. The button is
backlit green to indicate when the light has been
turned ON.
When the light is first turned on the light mode menu
will be displayed. The current light mode in use will be
shown. Use the UP ( ) or DOWN ( ) button to
step through the four colour modes:
(1) White [WHTE]
(2) User Colour [U.CLR]
(3) Fade Effect [FADE]
(4) Step Effect [STEP]
Press OK ( ) to confirm selection of desired light
mode or wait for the 10 second idle menu timeout
where the screen steps to the light speed [L.SPD] or
user colour [CL:xx] adjustment screens. If FADE or
STEP effect modes are selected the current light
speed [L.SPD] will be displayed. If the user colour
[U.CLR] light mode is selected the current colour
number will be displayed (refer below).
Press the UP ( ) or DOWN ( ) button to adjust
the light effect transition speed OR select from 20
colour choices. Press OK ( ) to confirm selection
or wait for the 10 second idle menu timeout where the
screen steps to the light brightness [L.BRT] screen.
Note: If White [WHTE] colour mode is selected the Light
Speed / Colour adjustment screens will NOT be displayed.
[L.BRT] LIGHT BRIGHTNESS
When the [L.BRT] adjustment screen is displayed
press the UP ( ) or DOWN ( ) button to adjust
the light brightness.
OK
OK
AM
PM
OFF
ON
°C
°F
MODE
SPD
BRT
SAT SUN MON TUE WED THU FRI
L.SPD
AM
PM
OFF
ON
°C
°F
MODE
SPD
BRT
SAT SUN MON TUE WED THU FRI
:
CL 0 1
Light speed screen User colour screen
