9. High Current Filter(Switched) Outlets: These
outlets have a special filter circuit designed to
handle high current components like power
amplifiers or Active Speakers
10. Gold-Plated Ground Post: Provides a
connection point for any ungrounded
components.
11. Thermal Circuit Breaker: Protects the
PMX-6600 from power overload.
12. Breaker Open: When this LED is on the
thermal circuit breaker has tripped due to an
overload. Before resetting the breaker, find
the reason for the overload.
13. Ultra-High Current AC Power Cable: Integral
high power, heavy duty AC cable to maximize
power transfer to high current components
such as amplifiers.
REMOTE Mode: These require a 12 volt triggering
device such as that typically found in most power
receivers and audio pre-amp processors
WARNING: If the “BYPASS" switch is not engaged,
All “Switched" outlets will not supply power until a
12V trigger is present!
16. Voltage Meter: Three-character LED displays the
line voltage at the source.
18. Unswitched Convenience Outlets: These are
"always on” filtered power outlets
19. USB Charger: Two 5V/1A convenience chargers
for portable electronic devices.
Note: For best performance were commend plugging
analog components into the analog outlets and
digital to digital. It will not harmony components if
they are plugged into any other outlet
14. Bypass/Remote Switch: The PMX-6600 has
two power-on/off modes, one is through the
Power On/Off Switch on the front panel, and
the other one is through the external 12V
trigger. (Once the PMX-6600 is powered on
by “REMOTE” mode, then the Power On /Off
Switch on the front panel will not functional)
BYPASS Mode: For those who do not wish to
utilize the 12V triggering, aconvenient bypass
switch is located adjacent to the input and
output jacks. By switch to the “BYPASS"
position, the 2xUSB Chargers and 12 xRear
Panel Mounted Outlets (3 Zones) will be
operated when the front panel power on/off
switch is engaged.
15. Remote Turn On/Off: 3.5mm (1/8”) mono
mini-plug. Connect to aremote trigger device that
used aDC output to trigger is startup/shutdown
sequence. DC IN 2~30V
(Trigger In): Allows source components to
control and turn on the switched outlets into
operation of PMX-6600 DC OUT 12V (Trigger Out):
Provides 12V signal to control source
equipment or another PMX-6600 device for
sequencing of equipment.
17. Amperage Meter: Three-character LED displays
the amperage usedbyequipmentpluggedinto-
the PMX-6600.
