Sony ICD-BX132 User manual

Easy to use, the ICD-BX132 delivers. Combining simplicity and capability the

ICDBX132 oers: extra-long recording time, add and overwrite functions for

corrections and additions to your recordings, and digital pitch control for

playback for powerful recording capability in the palm of your hand.

Convenient recording

Complete with a large LCD display and front controls, the ICD-BX132 is easy to use while capably

capturing moments as they occur.

Built-in 2 GB ash memory1

2 GB of available internal ash memory provides ample space for recording life’s important

moments-up to 2,087 hours in fact.1

Mono Microphone

Capture thoughts, dictations and other details with great clarity via

the built-in microphone. Via an external microphone (available separately). stereo recordings

can also be made when necessary.

Automatic Record level

The recorder automatically adjusts recording levels for optimum results.

Noise Cut

Noise Cut reduces ambient noise during recording for clearer speech playback.

Low Cut

When activated, Low Cut lter helps reduce the eect of wind noise in your recordings.

Digital Pitch Control

Digital Pitch Control enables the recording to be played at a faster or slower rate without

changing the recording’s pitch.

Alarm Playback

Set a future date and time and the recording will automatically be played.

Easy Search

Rewinds or fast forwards in short increments making it easier to locate a segment in a long

recording for review.

Add/Overwrite

Did you forget a thought or mis-speak? With Add/Overwrite capability, adding to or overwriting

recordings during playback is quick and easy.

Battery Operated

Two AAA batteries (supplied) will deliver up to 20 hours of recording time so you will never miss a

beat.2

Specications

Audio

Format(s)

Supported

Recording -

MP3 les:

Bit Rate: 2 kbps - 192 kbps, VBR

File Extension: .mp3

Playback -

MP3

ICD-BX132 Digital Flash Voice Recorder

Frequency Range

MP3 192k (SHQ): 75 - 15,000 Hz

MP3 128k (HQ): 75 Hz - 15,000 Hz

MP3 48k (Mono) (SP): 75 Hz - 10,000 Hz

MP3 2k (Mono) (LP): 100 Hz - 3,000 Hz

Microphone Built-in, unidirectional microphone

Recording System Digital, Monaural Recording

Audio Features

Microphone

Sensitivity Feature Yes (Hi/Lo)

Recording

Features

4 Modes:

SHQ (192kbps): Super High- Quality monaural mode

HQ (128kbps): High-Quality monaural mode

SP (48kbps): Standard Play monaural mode

HVXC (2kbps): Long Play monaural mode

Convenience

Message Folder(s)

5 Pre-Programmed at factory (5 Maximum)

99 Maximum les per folder

495 Maximum les

Convenience Features

Erase/Protect Yes

Message Folder(s) 5 folders

On-Screen Clock Yes

Safety Lock Hold Function

Search Features Cue/Review, Easy Search

General

Recording and

Playback Times

SHQ - MP3 (192 kbps): 21 hrs 40 min; Max 13hrs battery

life

HQ - MP3 (128 kbps): 32 hrs 35 min; Max 15 hrs battery

life

SP - MP3 (48 kbps MONO): Max 86 hrs 55 min; Max 16

hrs

LP - MP3 (2 kbps MONO): Max 2087 hrs; Max 20 hrs

Recording Media Built-In Flash Memory 2GB³

Type of Use Ultra Portable Voice Recorder

Inputs and Outputs

Headphone

Output(s) 1 (Minijack, Stereo)

Microphone Input 1 (Minijack, Stereo)

Memory

Memory Size 2 GB = 2,147,483,648 bytes

Available: 1.75 GB (1,879,048,192 bytes)

Power

Battery Life

(Approx) Up to 20 hours

Battery Type Alkaline "AAA" x 2

Output Power 300 mW

Power

Requirements Two LR03 (size AAA) alkaline batteries: 3.0 V DC

Speaker

Dimensions Approx. 1 1/8 in. (28 mm) diameter

Weights and Measurements

Dimensions

(Approx.) 1.5" x 4.5" x 0.84" (37.5 x 114 x 20.9mm) not including

projecting parts and controls

Dimensions

(Approx) Depth 0.84" (20.9 mm)

Dimensions

(Approx) Height 4.5" (114 mm)

1. 1 GB equals 1073741824 bytes, a portion of which is used for data management

functions.

2. Actual battery life will vary based on network, product settings, usage patterns, battery,

and environmental conditions. Actual storage capacity may vary based on product

settings, usage patterns, operating environment and battery condition.

written permission is prohibited. Sony and the Sony make.believe logo are trademarks

of Sony. All other trademarks are trademarks of their respective owners. Features and

specications are subject to change without notice. Non-metric weights and measures are

approximate and may vary. /Updated: March 27, 2013

Dimensions

(Approx) Width 1.5" (37.5 mm)

Weight (Approx.) 3 3/5 oz. (73 g) Including two LR03 alkaline batteries

Accessories

Supplied

Accessories

IC Recorder (1)

LR03 (size AAA) alkaline batteries (2)

Quick Start Guide (1)
