Sony XS-L1536 User manual
Design and Specifications subject to change without notice.
XS-L1536
15” Component Subwoofer
2002 SONY MOBILE
PRODUCT GUIDE
Impedance 4WVas (Lit.) 204.1
d (mm) 40 Vas (Cu.ft) 6.1
d (inch) 1 .4 Mms (g) 248.5
Rdc (W) .2 Lvc (mH) 1.
Fs (Hz) 2 .0 Xmax (mm) 4
Qts 0.42 Xmax (inch) 0.16
Qes 0.46 BL (Tm) 16.1
Qms 5.66 Enclosure vol. (Net) (1.4 cu.ft)
Recommended Enclosure: Sealed type
Specifications
Speaker Woofer 8 cm (15 in.), cone type
Maximum input power 1,000 watts
Rated input power 50 watts
Impedance 4 ohms
Sensitivity 89 dB/W/m
Frequency response 18 1,500 Hz
Mass Approx. 7.6 kg (16 lb. 12 oz.) per speaker
Supplied accessory Parts for installation
15 Polypropylene Cone
1000W max input power ( 50W RMS)
Santoprene Rubber Surround
Dual Damper Suspension
Gold-plated Binding Posts
Small sealed/ported enclosure optimized
4W Voice Coil
Indicates step-up
Thiele/Small Parameters
Dimensions
2002 SONY MOBILE
PRODUCT GUIDE
XS-L1536
15” Component Subwoofer
Design and Specifications subject to change without notice.
Unit: mm (in.)
8 - ø5.5
ø 70 (14 5/8)175 (7)
ø 9 (15 1/2)
ø 51 (1 7/8)
