Sony PMC-D40L User manual

3-867-143-11(1)

1999 by Sony Corporation

Operating Instructions page 2GB

Bedienungsanleitung Seite 2DE DE

Personal

Component

System

PMC-D40L

Introduction2GB

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Information

This Compact Disc player is classified as a

CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is

located at the rear.

Warning

Do not install the appliance in a confined

space, such as a bookcase or built-in cabinet.

Notice for customers in the United

Kingdom

A moulded plug complying with BS 1363 is

fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to

be replaced, same rating fuse approved by

ASTA or BSI to BS 1362, (i.e. marked with

or mark) must be used.

If the plug supplied with this equipment has

a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never

use the plug without the fuse cover. If you

should lose the fuse cover, please contact

your nearest Sony service station.

CAUTION

You can use this player on AC power

source only. You cannot use it on

batteries.

When you use this player for the first

time, or when you have not used it

for a long time, leave it connected to

AC power source for about one hour

to charge the built-in backup battery

for the clock, timer, preset radio

stations, etc. You can use the player

during charging. The player will

charge the battery automatically as

long as it is connected to a power

source.

When you disconnect the AC power

cord after charging, be sure to turn

the power off first. Once fully

charged, the backup battery will last

for about 30 minutes without being

connected to any power sources.

If the stored data are erased, reenter

them when you use the player again.

Basic Operations

3GB

Introduction

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

The CD Player

12 Using the display

13 Locating a specific track

14 Playing tracks repeatedly

(Repeat Play)

15 Creating your own program

(Program Play)

The Radio

17 Presetting radio stations

18 Playing preset radio stations

The Tape Player

19 Finding the beginning of a track

The Timer

20 Setting the clock

21 Waking up to music

23 Falling asleep to music

24 Timer-recording radio programs

Setting Up

26 Hooking up the system

30 Connecting optional components

32 Selecting the audio emphasis

(Sound Mode/MEGA BASS)

Additional Information

33 Precautions

35 Troubleshooting

38 Maintenance

39 Specifications

40 Index

Basic Operations4GB

Playing a CD

Basic Operations

For hookup instructions, see pages 26 - 29.

1Press 6OPEN/CLOSE down to

open the CD compartment and

place the CD on the CD

compartment.

2Close the lid of the CD

compartment.

3Press (on the CD section

(direct power-on).

The player plays all the tracks

once.

31,2

With the label side up

Display

Basic Operations

5GB

Tip

Next time you want to

listen to a CD, just

press (. The player

turns on automatically

and starts playing the

CD.

To Press

Adjust the volume VOLUME +/–

Stop playback p

Pause playback P

Press again to resume play

after pause.

Go to the next track +

Go back to the previous track =

Remove the CD 6OPEN/CLOSE

Turn on/off the player OPERATE

Use these buttons for additional operations

6OPEN/CLOSE

=/+

VOLUME +/–

OPERATE Pp

Basic Operations6GB

Listening to the radio

For hookup instructions, see pages 26 - 29.

1Press BAND until the band you

want appears in the display

(direct power-on).

2Hold down TUNE +/– until the

frequency digits begin to change

in the display.

The player automatically scans

the radio frequencies and stops

when it finds a clear station.

If you can't tune in a station,

press the button once at a time.

Display

Indicates an FM

stereo broadcast.

Basic Operations

7GB

Use these buttons for additional operations

Tips

• If the FM broadcast is

noisy, press PLAY

MODE/MONO/ST/

ISS on the player until

“Mono” appears in the

display and the radio

will play in monaural.

• Next time you want to

listen to the radio, just

press BAND. The

player turns on

automatically and

starts playing the

previous station.

To Press

Adjust the volume VOLUME +/–

Turn on/off the radio OPERATE

To improve broadcast reception

Connect the supplied FM lead aerial. If the FM

broadcast is still noisy, disconnect the FM lead aerial

and connect the FM outdoor aerial (not supplied) (see

pages 28 and 29).

MW/LW

Reorient the MW/LW loop aerial (supplied) (see page

28).

PLAY MODE

MONO/ST/ISS

VOLUME +/–

OPERATE

Basic Operations8GB

Playing a tape

For hookup instructions, see pages 26 - 29.

1Press 6PUSH to open the tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

2Press (on the TAPE section.

The player turns on (direct

power-on) and starts playing.

With the side you want

to play facing forward

Display

Tape counter

Basic Operations

9GB

To Press

Adjust the volume VOLUME +/–

Stop playback p

Play the reverse side 9

Fast-forward or rewind the tape )or 0

Eject the cassette 6PUSH

Turn on/off the player OPERATE

To select the direction of the tape

Press DIR MODE repeatedly.

To play Display shows

One side of the tape

Both sides of the tape

from the front side to reverse

side only

Both sides of the tape repeatedly

Tips

• Press COUNTER

RESET on the remote

to reset the counter to

“000” (on the remote

only).

• Next time you want to

listen to a tape, just

press (or 9. The

player turns on

automatically and

starts playing the tape.

Use these buttons for additional operations

VOLUME +/–

0/)

6PUSH

DIR MODE

OPERATE 9p

Basic Operations10GB

Recording on a tape

For hookup instructions, see pages 26 - 29.

1Press 6PUSH to open the tape

compartment and insert a blank

tape. Use TYPE I (normal) tape

only.

2Select the program source you

want to record.

To record from the CD player,

insert a CD (see page 4) and press

pon the CD section.

To record from the radio, press

BAND and tune in the station

you want (see page 6).

With the side you want to

record on facing forward

Display

331
