HDCAM-SR Workflow Guide

Designed for creative professionals working in commercial and television post, Autodesk® solutions empower editors and

artists with high-performance, integrated creative toolsets built for finishing. Autodesk Flame® Premium and Autodesk Smoke®

for Mac OS® X software both support the same efficient workflow with Sony’s HDCAM-SR VTR - on both mono- or stereoscopic

3D projects - so artists can focus on doing what they do best: delivering impressive, high-quality content fast.

To capture material recorded at double-speed:

1. Ensure that the HDCAM-SR is connected to the AJA card using a dual-link.

2. Set the HDCAM-SR VTR to 422DBL.

3. From the Device Name box, select the HDCAM SR VTR.

4. From the Tape Type box, select 2x-DOUBLE.

5. Capture the clip.

Autodesk Media & Entertainment Creative Finishing Solutions:

Autodesk Smoke for Mac OS X, Autodesk Flame Premium

Supported Workflow

Double-speed transfer

1080/50p and 1080/60p

Stereoscopic 3D

DATA mode (DPX file transfer)

Applicable HDCAM-SR VTR

SRW-5800

SRW-5100

SRW-5800 with HKSR-5803HQ

SRW-5100 with HKSR-5103

SRW-5800 with HKSR-5804

Image courtesy of McRay Corporation

©2010 Sony Corporation. All rights reserved.

HDCAM-SR Workflow Guide

To capture material recorded on 3D (stereoscopic) tapes:

1. Ensure that the HDCAM-SR is connected to the AJA card using a dual-link.

2. Set the HDCAM-SR VTR to 422 3D.

3. From the Device Name box, select the HDCAM SR VTR.

4. From the Tape Type box, select 2x-STEREO.

5. Capture the clip.

6. In the applications, stereo material can be played back and displayed as:

• Left or right eye

• Anaglyph

• Interlaced (left and right eye)

• Dual Output (active and passive projector systems, Flame Premium only)

7. Stereo material can be output as:

• Right eye Dual stream (left and right eye with HDCAM SR only)

• Single stream (side-by-side, top/bottom, Flame Premium only)

• Anaglyph

• Interlaced

Contact

Autodesk

10 Duke Street

Montreal, QC H3C 2L7

Canada

Phone 514-393-1616

Fax 514-393-0110

Websites www.autodesk.com/smokeformac

www.autodesk.com/flamepremium

MK10800V1OHB10DEC ATD

Image courtesy of James Lima
