Sony VPL-ES2 User manual

The Sony® VPL-ES2 mobile projector delivers

superior image performance and automatic

one-touch operation for home theater or

business use. Sony’s original high brightness

LCD panel displays HDTV and up to XGA

resolution images. Compact, stylish design

combined with TV and PC inputs provide the

flexibility you need for work or play.

VPL-ES2

Ultra Portable & Stylish Design

Compact and stylish design is perfect for set-up in a

home theater setting or on the road for the mobile

professional.

Automatic One-Touch Set-Up

Take the hassle out of set up with Sony’s unique

automatic Lens, Tilt, Input Search, Keystone and Pixel

adjustments with the touch of a button.

HDTV Compatible & Up To XGA

Resolution Images

HD compatible inputs are perfect for home theater use.

Also, Computer, DVD, VCR’s and Camcorders inputs are

provided to connect to all of your favorite toys. SVGA

computer resolution provides the ideal level of image

performance to match today’s PC’s.

High-Brightness LCD Panel

Sony’s original virtual light system with the all new super

high aperture liquid crystal panel and newly developed

high brightness lamp with 1500 ANSI lumens.

TV & PC Inputs

Flexible input options provide Component, Composite

and S-Video for television sources and VGA input for PC

connection.

Model

VPL-ES2

Model Number

VPL-ES2

ANSI Luminance

1500 (high), 1300 (standard)

Projection System

3 LCD panels,

1 lens projection system

LCD Panel Type

0.62-inch p-Si TFT LCD panel with

Micro Lens Array, 2,359,296 pixels

(786,432 pixels x 3)

Projection Lens

1.2 times zoom lens

Lamp Type

185W (high mode 3000 hrs life), 157W

(standard mode 4000 hrs life) UHP lamp

Noise Level

36db (high)/ 34db (standard)

Screen Size Coverage (diagonally)

40 to 300 inches

Video Resolution

750 lines

PC Native Resolution

800 x 600

Audio

1 watt (mono)

USB

Up (B type female)

Audio Inputs

2-Component (Y/R-Y/B-Y, HD15),

Composite (RCA), S-Video

Input Acceptable

Up to XGA resolution, Composite,

Component

PC Inputs

HD-15

Audio Inputs

Stereo Mini Jack

Automatic Setup

Yes

Tilt Adjust

Powered

Auto Sensing Input

Yes

Auto Keystone Adjustment

Yes

Auto Pixel Adjustment

Yes

Kensington Security Lock

Yes

Power Management: Max. Watts

220W

Power Management: Standby

Dimensions (W x H x D)

11.3" x 2.8" x 9.0"

Weight

Approx. 5 lbs., 15 oz.

Safety Regulations

UL, cUL, FCC Class B,

IC Class B, NEMKO, CE (LVD),

CE (EMC), C-Tick, CCC

Limited Warranty

2 years parts and labor

Extended Warranty

Optional 2 year extension

Supplied Accessories

Remote Commander®

(RMPJ2) Unit, Monitor Cable,

USB Cable: A type to B type,

Soft Case, AA size Battery (2),

Air Filter, AC Power Cord,

Operation Manual,

Quick Reference Sheet,

CD-ROM (Application Software),

Security Label

Optional Accessories

Lamp: LMP-C150

Hand Carry Case: VLC-U20TH

Ceiling Mount: PSSEC1US

Features and specifications are subject to change

without notice. All trademarks referenced herein are

trademarks of Sony or their respective owners.

www.sony.com

VPL-ES2

Sony Electronics Inc.

16765 West Bernardo Drive

San Diego, CA 92127
