Sony KP-41S4 User manual

R/D/D/D-L/G/S/I

23/ 3

Quick Start Guide

Thank you for purchasing this Sony product.

After following this step by step guide you

will be able to:

Insert Batteries into the Remote Control.

Connect the Aerial to your projection TV.

Select the language of the menu screens.

Tune your projection TV.

View TV Programmes.

Checking the

Accessories Supplied

Remote Control

Batteries

1Connecting the Aerial

and VCR 3

SONY©KP-41S4

KP-41S5

4-205-195-01 (1)

S®

Ecological Paper - Totally Chlorine Free

Projection TV

RM-862

a/Å

´/´

;

MDP2 TV

VIDEO

3VTR 1

( u)

pPr

PROGR

≥

;

REC

…/ Ú/;

Inserting Batteries into

the Remote Control

The Scart lead is optional.

If you use this optional connection

it can improve the picture and sound quality

when using VCR.

If you do not use a SCART lead, after

automatically tuning the projection TV refer to

the «Presetting Channels Manually» option in

page 10 of the instruction manual, to tune in the

TV to the output of your VCR. Also refer to your

VCR instruction manual to find out how to find

the output channel of your VCR.

R/D/D/D-L/G/S/I

23/ 3

OUT IN

VCR

Connecting cables are not supplied.

Switching on the

projection TV

Your television stations are now stored in your television’s memory.

Selecting the language of

the menu screens

This projection TV set works with menu screens. By following the

instructions below, you can select the desired language of the menu screens.

Press the MENU button on the

remote commander.

The LANGUAGE menu appears on

the screen.

Push the joystick to blue or green to

select the language you want.

Press the joystick to confirm your

selection. Finally press the MENU

button to restore the normal TV

picture.

Automatically Tuning the TV

You need to tune the projection TV to receive channels

(TV Broadcast).

By following the instructions below, this projection TV

automatically searches and stores all available channels for you.

Connect the projection

TV plug to the mains

socket (220-240V AC,

50Hz).

Push in the On/Off

switch on the front

of the TV.

RM-862

a/Å

´/´

;

MDP2 TV

VIDEO

3VTR 1

( u)

pPr

PROGR

≥

;REC

…/ Ú/;

LANGUAGE

3 3 3

MONO

L/G/S/I R/D/D/D

PROGR

1 Press on the mark on the front

panel of the projection TV to reveal

the front connectors.

2 Press and hold the button on

the projection TV until the AUTO

PROGRAMME menu is displayed

and the projection TV automatically

searches and stores the channels

(TV Broadcast).

This procedure could take some

minutes.

Please be patient and do not press

any button while the automatic

tuning is in progress. Otherwise

the automatic tuning will not be

completed.

After all available channels are stored,

the normal TV picture is shown and

your projection TV is ready for use.

• Channels are automatically

stored as follows:

Programme 1 BBC1

Programme 2 BBC2

Programme 3 ITV

Programme 4 CH4 or S4C

• You can sort the programme

positions to have them appear

on screen in the order you

like. For details, see “Sorting

Programme Positions” on

page 11 of the instruction

manual.



SYSPROG

C26

CHAN

- - - - -

LABEL



AUTO PROGRAMME
