SDM-M51D
SERVICE MANUAL
US Model
Canadian Model
AEP Model
SPECIFICATIONS
LCD panel
Input signal format
Resolution
Video input connector
Input signal levels
Audio output
Headphones jack
Audio in jack
Panel type: a-Si TFT Active Matrix
Picture size: 15.1 inch
RGB operating frequency*
Horizontal: 28-64 kHz
Vertical: 48-75 Hz
Horizontal: Max. 1024 dots
Vertical: Max. 768 lines
Analog RGB: HD15
Digital/Analog RGB: DVI-I 29 pins
Analog RGB video signal:
0.7 Vp-p, 75Ω, positive
SYNC signal:
TTL level, 2.2kΩ,
Positive or negative
(Separate horizontal and vertical,
or composite sync)
0.3 Vp-p, 75Ω, negative
(Sync on green)
Digital RGB video signal:
TMDS(singlelink)
1W x 2
Stereo minijack
Accepts impedance of 16-48 Ω
Stereo minijack
Accepts impedance of 47 kΩ
Accepts level 0.5 Vrms
Power requirements 100-240 V, 50-60 Hz,
0.4 - 0.2A (including AC adapter)
Power consumption Max. 22W (including AC adapter)
Operating temperature 5-35 ℃
Dimensions (width/height/depth)
Display(upright):
Approx. 387 x 345 x 180 mm
(15¼x13⅝x 7⅛inches)
(withstand)
Approx. 387 x 296 x 48 mm
(15¼x11¾x1
15/16 inches)
(withoutstand)
Mass Approx. 4.6 kg (10 1b 14 oz) (with
stand)
Plug&Play DDC2B
* Recommended horizontal and vertical timing condition
• Horizontal sync width duty should be more than 4.8% of total
horizontal time or 0.8 μs, whichever is larger.
• Horizontal blanking width should be more than 2.5 μsec.
• Vertical blanking width should be more than 450μsec.
Design and specifications are subject to change without notice.
TFT LCD COLOR COMPUTER DISPLAY
