Sony SEL20F28 User manual

Superior Image Quality

Three aspherical lens elements correct distortions and aberrations. In particular, image quality in peripheral areas has

been dramatically improved compared to previous lenses. The high resolution and excellent contrast assures richly

detailed images free of distortion, making the lens an outstanding choice for a wide range of subjects such as casual

snapshots to majestic landscapes.

Compact length

Measuring a mere 13/16 inches (20.4mm) the lens is 2mm shorter than the SEL16F28

High Quality Exterior

The aluminum alloy lens barrel is inlaid into a molded-plastic component for a lightweight yet durable construction and

features beautiful laser engraving of the product name and focal length for a stylish nish. The control ring allows for easy

operation while the lens exudes a stylish appeal.

Circular Aperture

The SEL20F28 features seven aperture blades that form a near circle. This result in a pleasing defocused circular eect on

the background of your image when the aperture is set wide open. The same type of internal stepping motor used for the

focus drive is used for aperture actuation as well, that result in a smooth, low-noise aperture operation ideally suited to

movie shooting.

Handy Focal Length

With a 20mm focal length (35mm equivalent 30mm) and a bright maximum aperture of F2.8, the SEL20F28 is ideal for a

variety of subjects from landscapes, interiors to casual snapshots.

Specications

Optics/Lens

Aperture (Max.) f/2.8

Aperture (Min.) f/16

Focal Length (35mm equivalent) 30mm

Filter Diameter 49mm

Lens Groups-Elements 6 groups, 6 elements

AF for Movie Capture Yes

Minimum Focus Distance 7.8" (0.2m)

Aperture Blade 7 blades (Circular aperture)

Aspheric Elements 3 aspheric surface

Dimensions (Max. Diameter x Length) 2-1/2 x 13/16" (62.6 x 20.4 mm)

Direct Manual Focus Yes

Exterior Finish Metal

Focus Ring in AF Mode No rotation

Internal Motor Yes (Stepping motor)

Lens Weight 2.4 oz (69g)

Low Noise During Movie Capture Excellent

Maximum Magnication 0.12x (APS-C)

Mount Material Metal

Non-rotating Focusing Ring No rotation

Weights and Measurements

SEL20F28 Alpha E-mount 20mm F2.8

Dimensions (Approx.) 2-1/2 x 13/16" (62.6 x 20.4 mm)

Weight (Approx.) 2.4 oz (69g)

Weight(Approx) (Main unit only) 2.4 oz (69g)

Service and Warranty Information

Limited Warranty Term 1 Year Parts & Labor

Accessories

Supplied Accessories Lens cap

Lens rear cap
