Sony HT-DDW760 User manual

HT-

DDW760

Basic Home Theater in a Box Package

Key Features

Silver Color Components (matches Sony WEGA® Televisions)

500 Watts Total System Power (400W Receiver + 100W Powered Sub)

STR-K760P Receiver: 80 Watts X 5

Powered 8" Subwoofer: 100W X 1 (6 ohm 100Hz 10%THD)

Dolby® Digital, dts®, Dolby® Pro Logic® II

Speaker Package Includes: Slim Center, Front/Rear Speakers, Powered Sub

Step

-

up

HT-

DDW760

Basic Home Theater in a Box Package

Sony Electronics Inc. •

16530 Via Esprillo

• San Diego, CA 92127 • 1-800-222-7669 • www.sony.com

Last Updated: 04/03/2006

Please visit the Dealer Network for current

information at www.sony.com/dn

Specifications

Receiver

Audio

Audio Power Output:

Receiver: 80W x5 (RMS

10%THD), Center Speaker: 100 Watts (RMS

10%THD), Front Speaker: 100W x2 (RMS 10%

THD), Subwoofer Speaker: 100W x1 (RMS 10%

THD)

Impedance:

75 ohms

Tuner

Audio

Tuner Frequency Range:

AM: 530

-

1,710 kHz,

FM: 87.5

-

108.0 MHz

Tuner Type: AM, FM

Front Speaker

Speaker

Speaker Type:

Enclosure

-Bass Reflex (Ported)

Speaker Dimensions:

4" x 6" x 5"

Center Speaker

Speaker

Speaker Type:

Enclosure

-Bass Reflex (Ported)

Speaker Dimensions:

8 7/8" x 4" x 5"

Subwoofer Speaker

Speaker

Speaker Type:

Enclosure

-Bass Reflex (Ported)

Speaker Dimensions:

8"

Audio

Impedance:

8 ohms

Frequency Range:

28

-

200 Hz

Dimensions

Weight:

14 lbs 6 oz. (6.5 kg)

Measurements:

17" x 5 3/4" x 11 7/8 "(430 x 145

x 301.5mm)

Supplied Accessories

Instruction Manual

Remote Commander

®

Remote Control (RM

-

U755)

Batteries AA x 2

AM Loop Antenna

FM Lead Antenna

Video Cable x 1

Long Speaker Cord x 2

Short Speaker Cord x 3

Foot Pads Speakers (20)

Foot Pad Subwoofer (4)

Optional Accessories

Floor Speaker Stands (1 pair) (WS-

FV11D)

Wall Mount Speaker Brackets (1 pair) (WS

-

WV10D)

©2006 Sony Electronics Inc.

Sony, Digital Cinema Sound, Remote Commander and WEGA are

trademarks of Sony. All other trademarks are property of their respective

owners. Dolby and Pro Logic are registered trademark of Dolby

Laboratories. dts is a trademark of DTS.

Features and specifications are subject to change without notice. Non-

metric weights and measures are approximate.
