Sony BDV-L800 User manual

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

BDV-L800

BDV-L800M

Blu-ray Disc/DVD Home Theatre System

Start here

Hello, this is your

quick start guide

BDV-L800

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

2

3

4

5

1

Connecting

your TV

Connecting

other devices

The on-screen

Easy Setup

Playing a disc and

using other functions

What’s in the box

Setting up

the speakers

EN

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

03

Here’s what’s

in the box

Dock for iPod/iPhone

(TDM-iP30)

Wireless transceivers (2) AC adapter AC power cord (mains lead)

FM wire antenna (aerial)

R6 (size AA) batteries (2)

or

Remote Subwoofer

Front speakers (2)

Main unit

Video cord Stand cover USB cable

(EZW-RT50)

Wall mounting brackets (2)

Speaker stands (2)/Screws (2)

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

04

Start by positioning the speakers

in a room according to the

coloured labels on the back.

1

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

05

For the supplied speakers, just

connect the speaker cords to the

corresponding colour on the rear

of the subwoofer.

Progress

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

06

Next, insert the wireless

transceivers into main unit and

subwoofer for an easy, cable-free

connection.

EZW-RT50 EZW-RT50

1

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

07

To enjoy high-quality video and

audio, the best method is to

connect via a High Speed HDMI

cable  (not supplied).

If your TV has an HDMI ARC jack, you do

not need a digital optical cord.

If your TV has no HDMI ARC jack, you need

a digital optical cord  (not supplied)

to enjoy TV sound through the system

speakers.





2

Progress

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

08

To connect your set-top box,

game console or digital satellite

receiver, simply connect with an

HDMI cable. 

For FM radio, connect the supplied

wire antenna (aerial) into the inner

socket and extend it for the best

reception. 

Alternatively, connect your own

external antenna (aerial).

You can also connect your iPod or

iPhone to the system and your TV

via the supplied dock. 

or





3

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

09

The system has built in Wi-Fi

to allow you to connect to the

internet and home network

services.

If you don’t have access to a

wireless network, you can also

connect with a LAN cable.

Network settings can be found in

the home menu - see p.15.

For further details about network

connections, visit:

http://support.sony-europe.com

To a broadband router

Progress

Sony BDV-L800/BDV-L800M [GB] 4-279-075-31 (1)

10

Once all of your devices are

connected, you can plug in the

AC adapter. The clamps can be

used to tidy the cables.

FM wire antenna (aerial)

AC adapter

3
