Sony Cyber-shot DSC-W210B User manual
1
Latvia
DSC-W210 This document was created on
Apr 24, 2009
http://www.sony.lv
Compact and stylish, with powerful, easy to use shooting functions
Variations
DSC-W210B DSC-W210P DSC-W210G
Features
Please be aware that the features/specifications can differ from country to country.
• 12.1 effective megapixels resolution for very high quality imaging and
detail-packed enlargements
• 4x optical zoom Carl Zeiss Vario-Tessar lens with 30mm wide angle for
panoramic landscapes and large group shots
• Enhanced Smile Shutter automatically fires shutter when subject smiles:
now easier to use with adjustable smile threshold
• Enhanced Face Detection with selectable adult/child priority, high-speed
subject tracking for clearer portraits
• Intelligent Scene Recognition simplifies shooting by choosing best settings
for difficult conditions such as twilight portraits and backlit scenes
• Large 2.7-inch (230K dot) Clear Photo LCD with wide viewing angle
• HD output for display on HD TV (requires optional cable). PhotoTV HD
enhances still image viewing on compatible BRAVIA TV
• SteadyShot image stabilization reduces image blur during handheld
shooting
Useful Links
http://www.sony.lv
2
• BIONZ processor for enhanced image quality, reduced image noise and
fast shooting response
• D-Range Optimizer with new Plus mode adjusts exposure and contrast in
high-contrast and backlit scenes
• HD Slideshow with music offers fun image display with effects and music
on LCD or connected HD TV
• Fun in-camera retouching functions including trim, red-eye correction and
artistic filters
• Picture Motion Browser software simplifies image management, searches
and viewing on PC
Technical
specifications
Lens
Optical Zoom 4x
Precision Digital Zoom Approx.8x(Total)
Smart Zoom up to 25x (with VGA)
F 2.8-5.8
Focal Length (f= mm) 5.35-21.4
Focal Length (f=35mm conversion) 29.7-118.8
Macro (cm) Wide: Approx. 4-infinity,
Tele: Approx.50-infinity
Filter Diameter (mm) 46 (with Lens Adapter)
Conversion Lens compatibility YES
NightShot NO
NightFraming NO
Carl Zeiss Vario-Tessar Lens YES
Image Sensory
CCD Type Super HAD CCD
Size (Inches) 1/2.3
Camera
Effective Pixels (Mega Pixels) Approx. 12.1M
Bionz Processor YES
Face Detection YES
Smile Shutter YES
A/D Conversion (DXP) (Bit) 14
Clear RAW NR YES
Auto Focus Method (Single) YES
Auto Focus Method (Monitoring) YES
Auto Focus Method (Intelligent) NO
Auto Focus Method (Continuous) NO
Auto Focus Area (Multi Point) YES
Auto Focus Area (Centre weighted) YES
Auto Focus Area (Spot) YES
3
Auto Focus Area (Flexible Spot) NO
Manual Focus NO
Focus Preset YES
Focus Preset (m) 0.5 / 1 / 3 / 7 / Unlimited
distance
Aperture Auto Mode YES
Aperture Priority Mode NO
Aperture Manual Mode NO
Shutter Speed Auto Mode (sec) 1/4-1/1600
NR Slow Shutter YES
Hand Shake Alert YES
Exposure Control +/- 2.0 EV, 1/ 3 EV step
White Balance Auto, Daylight, Cloudy,
Fluorescent1,
Fluorescent2,
Fluorescent3,
Incandescent, Flash
Automatic White Balance YES
Light Metering (Multi Pattern) YES
Light Metering (Centre weighted) YES
Light Metering (Spot) YES
Sharpness Setting NO
Saturation Setting NO
Contrast Setting NO
ISO Sensitivity (REI) YES (Auto, 100, 200, 400,
800, 1600, 3200)
Scene Selection Twilight, Twilight Portrait,
Twilight using a
tripod, Backlight, Backlight
Portrait, Portrait
AF Illuminator YES
Flash Mode Auto, Forced Flash, Slow
Syncro, No Flash
Distance limitations using Flash (m) 0.2-3.9 (wide), 0.5-1.9
(tele)
Pre-flash YES
Red-eye Reduction YES
Auto Daylight Synchronized Flash YES
Super SteadyShot
Super SteadyShot capability NO
SteadyShot capability YES
Optical SteadyShot capability NO
Auto Focus System
AF Illuminator YES
Built-In-Flash
Flash Mode
4
Auto, Forced Flash, Slow
Syncro, No Flash
Red-Eye Reduction YES
Auto Daylight Synchronized Flash YES
LCD/ Viewfinder
LCD Screen Size (inches) 2.7
LCD Total Dots Number 230.400
LCD Monitor Type TFT
Auto Bright Monitoring YES
LCD Field of View (%) 100
Optical Viewfinder NO
Electrical Viewfinder NO
LCD screen
LCD Field of View (%) 100
Recording
Recording Media Memory Stick™ Duo,
Memory Stick PRO Duo™.
Memory Stick PRO Duo™
High Speed(No Speed
Advantage), Memory Stick
PRO-HG Duo. Internal
memory (15MB)
Recording Format JPEG, MPEG1
Memory Stick Pro Interface Parallel
DCF (Design rule for Camera File System) YES
DPOF (Digital Print Order Format) YES
Burst Mode (shots) 100
Burst Interval (approximately sec) 0.6
Still Image size (12 Mega 4000 x 3000) YES
Still Image size (10 Mega 3648 x 2736) NO
Still Image size (8.0 Mega, 3264 x 2448) YES
Still Image size (5.0 Mega, 2592 x 1944) YES
Still Image size (3.1 Mega, 2048 x 1536) YES
Still Image size (VGA, 640 x 480) YES
Still Image size (16:9 mode, 1920 x 1080) YES
Still Image size (16:9 mode, 3648 x 2056) NO
Still Image size (16:9 mode, 4000 x 2248) YES
Still Image size (3:2 mode, 4000 x 2672) YES
Still Image size (3:2 mode 3648 x 2432) NO
Moving Image Size (MPEG VX Fine, 640x480, 30fps) YES
Moving Image Size (MPEG VX Standard, 640x480,
16.6fps)
YES
Moving Image Size (QVGA: 320x240 30fps) NO
Moving Image Size (QVGA: 320x240 8.3fps) YES
NO
5
Moving Image Size (1440x1080 30fps Fine
Approx.12Mbps)
Moving Image Size (1440x1080 30fps Standard
Approx.7Mbps)
NO
Moving Image Size (1280x720 30fps Fine
Approx.9Mbps)
NO
Moving Image Size (1280x720 30fps Standard
Approx.6Mbps)
NO
Moving Image Size (640x480 30fps Approx.3Mbps) NO
Playback/ Edit
HD (High Definition) Playback YES
Slideshow Playback YES
Slideshow with Music YES
Trimming YES
Resize NO
Playback Zoom YES
Divide (MPEG) NO
Cue & Review (MPEG) YES
Index Playback YES
Image Rotation YES
Auto Image Rotation YES
General
Battery Remaining Indicator YES
Histogram Indicator YES
Exposure Warning Indicator YES
Disk / Memory Stick remaining indicator YES
PTP (Picture Transfer Protocol) YES
Print Image Matching YES
PictBridge YES
Shop Front Mode YES
Start up time (approximately sec) 1.7
Menu Language English, French, German,
Spanish, Italian,
Portuguese, Dutch,
Russian, Swedish,
Norwegian, Danish,
Finnish, Polish, Czech,
Hungarian, Turkish,
Greek, Romanian,
Croatian
Bluetooth® Function NO
Jacks
Multi use Terminal with HD YES
Multi use Terminal YES
AV Out NO
Digital I/O (USB) NO
6
USB 2.0 Hi-Speed YES
Power/ Others
Battery System Lithium G
Supplied Battery NP-BG1
Stamina (battery life) with the supplied battery(s) in
normal shooting condition
430 shots, 215min (CIPA
standard with LCD screen
on)
Battery for Clock Manganese-Silicon
(MS614)
Weight (g) 117
Weight with Accessories (g) 146
Supplied Software Picture Motion Browser
Ver.4.2(Windows only) +
Music Transfer
Supplied Accessories Rechargeable battery
pack (NP-BG1), Battery
Charger, Multi Connector
Cable, Power Cord, Wrist
Strap, CD-ROM
Dimensions
Width (mm) 95.2
Height (mm) 56.5
Depth (mm) 21.8
Accessories
Photo printers
DPP-FP97 DPP-FP95 DPP-FP85
DPP-FP77 DPP-FP75 DPP-FP67
DPP-FP65 DPP-FP90 DPP-FP70
7
DPP-FP60 DPP-FP60BT DPP-FP35
DPP-FP55 DPP-FP50
Accessory Kits
ACC-CFG ACC-CBG ACC-CHFG
ACC-CMFG ACC-SHA
Cases
LCS-CSVA LCS-CSVB LCS-CSVC
LCS-TWA LCS-TWB LCS-TWC
LCS-TWD LCS-TWE LCS-TWF
LCS-TWG LCS-WG LCS-CSK
LCS-CSJ LCS-CSL LCS-CSN
8
LCM-WA LCS-CFR LCS-CP2
LCS-CSA LCS-CSD LCS-CSE
LCS-CSF LCS-CSG LCS-CST
LCS-CSQ LCS-SA LCS-WB
LCS-WE LCS-WF
Digital Photo Printers and Printing Packs
DPP-FP97 DPP-FP95 DPP-FP85
DPP-FP75 DPP-FP77 DPP-FP65
DPP-FP67 DPP-FP90 DPP-FP70
DPP-FP60 DPP-FP60BT DPP-FP35
9
DPP-FP55 DPP-FP50
GPS
GPS-CS3KA GPS-CS1KASP GPS-CS1KA
GPS-CS1
Batteries & Chargers
NP-FG1 NP-BG1 BC-TRG
Sports & Marine Packs
MPK-WE APK-WB VCT-MP1K
ACC-MP105
Docking Stations & Cables
VMC-MD2 VMC-MHC2
Lenses & Filters
VAD-WG
10
Tripods
VCT-R640 VCT-R100 VCT-1500L
VCT-MTK
Other Accessories
KK-CA PCK-L27 KK-LC3
Digital Photo Printers and Printing Packs
DPP-FP97 DPP-FP95 DPP-FP85
DPP-FP75 DPP-FP77 DPP-FP65
DPP-FP67 DPP-FP90 DPP-FP70
DPP-FP60 DPP-FP60BT DPP-FP35
DPP-FP55 DPP-FP50
GPS
