Sony SPP-930 User manual
Operating Instructions
Manual de instrucciones
Manual de instruções
SPP-930
©1998 by Sony Corporation
ES
Cordless
Telephone
3-860-376-42 (1)
EN
P
2EN
WARNING
To prevent fire or shock hazard, do
not expose the unit to rain or
moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to qual
ified personnel only.
3EN
Table of contents
EN
Table of contents
Getting Started
4 Read this first
5Step 1: Checking the package
contents
6Step 2: Setting up the base unit
9Step 3: Preparing the battery pack
for the handset
Basics
12 Making calls
Redialing
14 Receiving calls
Advanced Features
15 Speed dialing
17 Setting the ringer type
18 Paging
Additional Information
19 Mounting the base unit on a wall
20 Notes on power sources
20 Maintenance
23 Specifications
24 Index
Getting Started
4EN
Read this first
Getting Started
Step 2 (page 6 to 8)
Next, do three things to set up the
base unit.
Step 3 (page 9 to 11)
Finally, insert the battery pack into the
handset, and place the handset on the
base unit to charge the battery pack.
About the cordless telephone
Each time you place the handset on the base unit, a random security
code is automatically assigned between the base unit and the handset.
(The IN USE lamp flashes during the initialization, then turns off when
the initialization is complete.) Only a handset which has this unique
security code can make calls through the base unit. This system
prevents the possibility of other cordless telephone handsets making
calls through your base unit.
Base unit
Handset
Step 1 (page 5)
First, unpack the phone and the supplied
accessories.
Before you use your phone, you must set it up. Here’s a quick
way to set up your phone: Step 1, 2 and 3.
That's it!
Getting Started
5EN
Getting Started
Telephone line cord Screws and caps (2) Wall bracket for base unit
Directory
Step 1
Base unit Handset
Rechargeable battery pack
(BP-T23)
AC power adaptor
(AC-T120)
Checking the package contents
Make sure you have received the following items in the package.
If anything is missing, contact your local Sony dealer.
Getting Started
6EN
Step 2
Away from a microwave oven
Away from a personal
computer
Away from noise sources, such as a window by
a street with heavy traffic
Away from heat sources, such as radiators,
airducts, and sunlight
Away from excessive
moisture, extremely low
temperatures, dust,
mechanical vibration, or
shock
Away from
television sets and
other electronic
equipment
Away from another cordless
telephone
CAUTION: The cordless telephone operates at a frequency that may cause interference to
nearby TVs and VCRs; the base unit should not be placed near or on top of a TV
or VCR; and if interference is experienced, moving the cordless telephone
farther away from the TV or VCR will often reduce or eliminate the interference.
Near a central location
and on a level surface
Setting up the base unit
Do the following steps:
• Choose the best location
• Connect the base unit
• Choose the dialing mode
Choosing the best location
Where you place the base unit affects the reception quality of the
handset.
Getting Started
7EN
Getting Started
1Connect the telephone line cord
to the LINE jack, and to a
telephone outlet.
2Connect the AC power adaptor
to the DC IN 9V jack, and to an
AC outlet.
3Raise the antenna vertically.
Route the cable.
3
2
To AC outlet
AC power adaptor
(supplied)
1
To telephone
outlet
To LINE
To DC IN 9 V
Connecting the base unit
If you want to hang the base unit on the wall, mount the unit first (see
page 19).
Telephone line cord
(supplied)
continued
Getting Started
8EN
Polarity of the plug
–
+
Step 2: Setting up the base unit (continued)
Modular
Center pair
If you aren’t sure of your dialing system
Make a trial call with the DIAL MODE switch set to TONE.
If the call connects, leave the switch as it is; otherwise, set to PULSE.
DIAL MODE switch
Notes
• Use only the supplied AC-T120 AC power adaptor.
Do not use any other AC power adaptor.
• Connect the AC power adaptor to a continuous power supply.
• Place the base unit close to the AC outlet so that you can easily
unplug the AC power adaptor.
Tips
• If your telephone outlet isn’t modular, contact your telephone service
company for assistance.
• If you have two phone lines on a single jack with the first phone line
connected to a center pair of wires, and you need to connect the second
phone line (outer pair of wires), contact your telephone company for
rewiring.
Choosing the dialing mode
For the telephone to work properly, select an appropriate dialing mode
(tone or pulse).
Getting Started
9EN
Getting Started
Step 3
1Slide open the battery compartment Iid of the
handset.
2Insert the battery pack (with contacts facing
down) into the battery compartment.
3Replace the battery compartment lid.
continued
Preparing the battery pack for the
handset
Insert the battery pack into the handset, then place the handset on the
base unit.
Inserting the battery pack
Getting Started
10EN
Step 3: Preparing the battery pack for the handset (continued)
Battery duration
A fully charged battery pack lasts for about:
• Seven hours when you use the handset continuously.
• Seven days when the handset is in standby mode.
Notes
• The battery pack gradually discharges over a long period of time, even if not
in use.
• The CHARGE lamp of the base unit is always lighted when the handset is
placed on the base unit, even if the battery pack has been fully charged.
When to charge the battery pack
As long as the handset is placed on the base unit after each call, the
battery pack recharges continuously.
CHARGE lamp
Charging the battery pack
Place the handset on the base unit.
The CHARGE lamp lights up. It takes about
10 hours to charge the battery pack.
