Sony CFD-CD777L User manual

3-864-133-61(1)

1998 by Sony Corporation

CD Radio

Cassette-Corder

Operating Instructions

CFD-CD777S

CFD-CD777L

Introduction2

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Warning

Do not install the appliance in a confined

space, such as a bookcase or built-in cabinet.

The FUNCTION selector is located at the

front.

When you turn on the player, the OPR/BATT

indicator lights up.

Basic Operations

3Introduction

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

12 Dubbing

The CD Player

14 Using the display

15 Locating a specific track

16 Playing tracks repeatedly

(Repeat Play)

17 Creating your own program

(Program Play)

The Tape Player

19 Recording through a

microphone/Using as a PA

system

Setting Up

20 Hooking up the system

23 Connecting optional components

24 Adjusting the audio emphasis

(DYNAMIC SOUND SYSTEM)

Additional Information

25 Precautions

27 Troubleshooting

29 Maintenance

30 Specifications

Back cover

Index

BasicOperations4

Playing a CD

Basic Operations

For hookup instructions, see pages 20 – 22.

1Set FUNCTION to CD.

2Press 6PUSH OPEN/CLOSE

down to open the lid of the CD

compartment and place a CD

on the CD compartment.

3Close the lid of the CD

compartment.

With the label side up

142,3

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

BasicOperations

Basic Operations

Display

4Press ^((on the remote).

The player plays all the tracks

once.

Playing timeTrack number

Use these buttons for additional operations

To Do this

adjustthevolume Turn VOLUME.

stopplayback Press p.

pauseplayback Press ^.(ontheremote,

press P.)

Pressthebuttonagainto

resumeplayafterpause.

gotothenexttrack Press +.

gobacktotheprevioustrack Press =.

remove the CD Press 6PUSHOPEN/

CLOSE.

turnofftheplayer SetFUNCTIONtoTAPE•

CD/RADIO OFF.

Tip

During operation, the

level meter shows the

frequency level of the

sound.

Adjusting the volume

will not affect the level

meter.

VOLUME

^=, +

Level meter

FUNCTION 6PUSH OPEN/CLOSE

BasicOperations6

Listening to the radio

For hookup instructions, see pages 20 – 22.

1Set FUNCTION to RADIO.

2Set BAND to select the band you

want.

3Turn TUNING to tune in the

station you want.

For better SW reception, use FINE

TUNING.

CFD-CD777S CFD-CD777L

3123

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

SW2

SW1

BAND

TUNING

FINE TUNING

BasicOperations

Basic Operations

Use these buttons for additional operations

Tips

• During operation, the

level meter shows the

frequency level of the

sound.

Adjusting the volume

will not affect the level

meter.

• If the FM broadcast is

noisy, set ISS•FM

MODE at the rear to

“MONO”. Radio will

play in monaural.

To Do this

adjustthevolume Turn VOLUME.

turnofftheradio Set FUNCTION to TAPE•CD/

RADIO OFF.

To improve broadcast reception

Reorient the antenna for FM. Reorient the player itself

for MW or LW. For SW, extend the antenna vertically.

for FM for MW/LW

for SW

VOLUME Level meterFUNCTION

BasicOperations8

Playing a tape

For hookup instructions, see pages 20 – 22.

1Set FUNCTION to TAPE•CD/

RADIO OFF.

2Press p6 to open tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

3Press PLAY (.

The player starts playing.

With the side you want

to play facing you

32132

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

STOP/EJECT

PLAY

BasicOperations

Basic Operations

Use these buttons for additional operations

To Do this

adjustthevolume Turn VOLUME.

stopplayback Press p6.

fast-forwardorrewind Press )or 0.

thetape

pauseplayback Press P.

Pressthebuttonagainto

resumeplayafterpause.

playtheoppositesideof Press down DIRECTION

thetape(deckAonly) once.

DIRECTION ª·(reverse/

forward) indicators show the

tape direction of deck A.

ejectthecassette Press p6.

To select the direction of the tape (deck A only)

To play Set DIR MODE to

bothsidesofthetape

repeatedly

bothsidesofthetape

fromthefrontsideto

reversesideonly*

* If play begins from the reverse side, the tape stops at the

end of that side.

Note

During playback, do not

press ), 0or (on

the other deck as this

causes excessive wow

and flutter.

Tips

• During operation, the

level meter shows the

frequency level of the

sound.

Adjusting the volume

will not affect the level

meter.

• To play tapes in both

decks successively,

press (on deck B and

then press PLAY and P

on deck A as the same

time. When the tape

ends on deck B, the

playback starts

automatically on deck

DIRECTION

ª·

DIR MODE

0, )

Level meter

VOLUME

BasicOperations10

Recording on a tape

Display

For hookup instructions, see pages 20 – 22.

1Press p6 to open the tape

compartment on deck B and

insert a blank tape.

2Select the program source you

want to record.

To record from the CD player, set

FUNCTION to CD and insert a

CD (see page 4).

To record from the radio, set

FUNCTION to RADIO, and tune

in the station you want using

BAND and TUNING (see page 6).

To record from the built-in

microphone (MIC), set

FUNCTION to TAPE•CD/

RADIO OFF.

With the side you want to

record on facing you

STOP/EJECT

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

TAPE

RADIO

TV/

LINE IN

DUBBING

FUNCTION

CD/RADIO

OFF

2MIC
