Sony CFD-930L User manual

3-861-412-33(1)

CD Radio

Cassette-Corder

1998 by Sony Corporation

CFD-V25

CFD-V34

CFD-V34L

CFD-V37

CFD-V37L

CFD-930L

Operating Instructions page 2EN

Manual de instrucciones página 2ES ES

Introduction2EN

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Information

For customers in Europe

Notice for customers in the United

Kingdom

A moulded plug complying with BS 1363 is

fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to

be replaced, same rating fuse approved by

ASTA or BSI to BS 1362, (i.e. marked with

or mark) must be used.

If the plug supplied with this equipment has

a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never

use the plug without the fuse cover. If you

should lose the fuse cover, please contact

your nearest Sony service station.

This Compact Disc player is classified as

a CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is

located on the bottom exterior.

WARNING

Do not install the appliance in a confined

space, such as a bookcase or built-in cabinet.

About this manual

The instructions in this manual are for the

CFD-V25, CFD-V34, CFD-V34L, CFD-V37,

CFD-V37L and CFD-930L. Before you start

reading, check your model number. The

CFD-V34L is the model used for illustration

purpose.

Note

The name of the switch to turn on/off this

player is indicated as below:

“OPERATE”: CFD-V34L/V37L/930L

“POWER”: CFD-V25/V34/V37

3EN

Introduction

Basic Operations

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

The CD Player

12 Using the display

13 Locating a specific track

14 Playing tracks repeatedly

(Repeat Play)

15 Playing tracks in random order

(Shuffle Play)

16 Creating your own program

(Program Play)

Setting Up

18 Choosing the power sources

20 Adjusting the sound emphasis

(TONE/MEGA BASS)

Additional Information

21 Precautions

23 Troubleshooting

25 Maintenance

26 Specifications

28 Index

Basic Operations4EN

Playing a CD

Basic Operations

Connect the supplied AC power cord (see page 18).

1Press 6PUSH OPEN/CLOSE

down to open the CD

compartment and place a CD on

the CD compartment.

2Close the CD compartment.

3Press ^(direct power-on).

The player plays all the tracks

once.

Display

Track number

3 1,2

With the label side up

Playing time

Basic Operations

5EN

6PUSH OPEN/CLOSE

VOL +/–

Use these buttons for additional operations

=/+

To Press

Adjust the volume VOL +/–

Stop playback p

Pause playback ^

Press again to resume play

after pause.

Go to the next track +

Go back to the previous track =

Remove the CD 6PUSH OPEN/CLOSE

Turn on/off the player OPERATE (or POWER, see

page 2)

Tip

Next time you want to

listen to a CD, just press

^. The player turns on

automatically and starts

playing the CD.

OPERATE

(or POWER)

Basic Operations6EN

Listening to the radio

Connect the supplied AC power cord (see page 18).

1CFD-V25/V34/V37: Press FM or

AM (direct power-on).

CFD-V34L/V37L/930L: Press

RADIO (direct power-on).

2CFD-V34L/V37L/930L only: Select

the band.

3Turn TUNING to tune in a radio

station.

If the received FM stereo is too

weak, the reception becomes

monaural.

Display

CFD-V25/V34/V37

CFD-V34L/V37L/930L

Basic Operations

7EN

Use these buttons for additional operations

To Press

Adjust the volume VOL +/–

Turn on/off the radio OPERATE (or POWER, see

page 2)

To improve broadcast reception

Reorient the antenna for FM. Reorient the player itself

for AM or MW/LW.

For FM For AM/MW/LW

VOL +/–

Tip

CFD-V34L/V37L/930L

only:

To receive an FM stereo

program

Set the FM MODE

selector at the rear to

STEREO. If the FM

broadcast is noisy, set

the selector to MONO

and the radio will play

in monaural.

OPERATE

(or POWER)

Basic Operations8EN

Playing a tape

Connect the supplied AC power cord (see page 18).

1Press p6 to open the tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

2Press (.

The player turns on (direct

power-on) and starts playing.

With the side you want

to play facing upward

Display

Basic Operations

9EN

Use these buttons for additional operations

0/)

To Press

Adjust the volume VOL +/–

Stop playback p6

Fast-forward or rewind the tape )or 0

Pause playback P

Press the button again to

resume play after pause.

Eject the cassette p6

Turn on/off the player OPERATE (or POWER,

see page 2)

OPERATE

(or POWER)

VOL +/–

Tip

Next time you want to

listen to a tape, just

press (. The player

turns on automatically

and starts playing the

tape.

Basic Operations10EN

Connect the supplied AC power cord (see page 18).

1Press p6 to open the tape

compartment and insert a blank

tape. Use TYPE I (normal) tape

only.

2Select the program source you

want to record.

To record from the CD player,

press CD and insert a CD (see

page 4).

To record from the radio, press

FM or AM (CFD-V25/V34/V37)

or RADIO (CFD-V34L/V37L/

930L) and tune in the station you

want (see page 6).

Recording on a tape

Display

With the side you want to

record on facing upward

CFD-V25/V34/V37

CFD-V34L/V37L/930L
