SMART SECURITY SYSTEM
WIFI Pan/tilt Network Camera
User Manual
Read and understand thoroughly this safety awareness & instruction before using
and keep it for future reference
SMART SECURITY SYSTEM
Quick Guide
1.
Get a general idea on this network camera
(1)Product Overview
LED Indicator: From Left to Right
1.Network indicator 2. Alarm indicator 3. Record indicator
4 alarm-arming indicator
Pls Check the indicator light whether working properly
Indicator
Lit stay-on
Lit flashing
Lit off
Network indicator
Network
connected
connecting
Un-connected
Alarm indicator
Having alarm
－
No alarm
Record indicator
－
Recording
Recording stopped
Alarm-arming
indicator
Arming
To-be armed
Disarming
SMART SECURITY SYSTEM
2.
Interface
①Network interface：Using wired network access to the Internet
②WIFI ant：For receiving WIFI signal；
③SD interface：Insert SD card to record picture /video；
SMART SECURITY SYSTEM
④Power supply interface；connect with power adaptor；
Pls connect the inputs (①○
2) in sequential order according to above
drawing
⑤Bracket: Installation Bracket
⑥Alarm ant Interface: For Receiving Alarm Signal
3.
App download
IOS clients can search and download 2cu from Apple APP store, Android
clients can search and download it from Google Play. Pls register your
account and password according to the instruction step by step
4.
Network connection
（1）Wired connection
After power on the network camera, connect the network
interfaces on camera and Router by one network cable,(pls make
sure to ON the DHCP on the router）， the Network indicator will
stay-ON after connecting it well
（2）WIFI connection
If there is no wired network, you can use the Infrared control
to SET the WIFI. Pls set as the following steps：1) Insert the
Infrared control into the earphone interface of the smart phone.
SMART SECURITY SYSTEM
2) point the Infrared control at the IR receiver on the network
camera. 3) Open APP 2cu>toolbox> Infrared control，then you
can see the up/down/left/right button. Press any one button ,if
the network camera can move around , means the Infrared
control works well . 4) Then press WIFI button on the same
screen, to select the WIFI device to be connected. Input the
WIFI password and Device password(the factory default
password is empty ). 5) Then press “SET “, if you can hear one
alert tone “ding”, means the network has connected with WIFI
successful .and then the network indicator will stay-on
5.
Add Device
（1）it can search all device in the same LAN and set the
visiting password
Open the APP 2cu toolbox , press “shake “，shake your mobile
left/right , then the APP will search the devices in the local area
SMART SECURITY SYSTEM
network , then press the device to be added , input the device name
and password . if the device is a new one had never set any
password, so the password you input will be the visiting password
for this device .
（2）add device manually
Press the in the bottom right corner to be in the contact
interface first , then click top right corner , then input the
device ID number and password as below picture
SMART SECURITY SYSTEM
6.
Device monitoring
（1）press Device Icon in contact interface：in the contact
interface ,just press the device Icon to start monitoring function；
（2）Press Number dial plate：Just input the device ID,and then
Press the monitoring icon,input the visiting password
To start monitoring
7.
Device Setting
SMART SECURITY SYSTEM
(1)Defense area settings & Alarm settings（optional function）
This device can support 8*8=64 wirelss detectors and 8 remote
controlling alarm system via learning code . The specific operation
of learning code as follows:
Click Contact name ->settings->Defense Area Settings，Press the
name of one Defense Area to view 8 small defense area. Then
trigger the wireless devices to learn code .
for example to set up a door sensor as No. 1 detector of the hall,
choose the hall, click No. 1 button, the learning code dialog box will
be popped up, then the door sensor will be triggered and APP will
remind that the learning is successful. The No.1 button will turn to
be light blue color. meanwhile, it will show “learning successful “
SMART SECURITY SYSTEM
Delete the code : click the defense area number which has learned code
and confirm to delete it .
Alarm settings:There are two way to Arm the alarm. 1: press the
ARM button on the Infrared controller which already learned code .
2: in APP 2cu , beside the Device name on the contact interface ,there is
one (disarm) button after press it ,it will become Arm
After ARM the alarm. the device will send the alert to APP 2CU.
meanwhile it will capture some picture send to the email box registered
Before arm the alarm, you need do detailed Alarm setting as below :
Click the Device name on the contact interface-> setting->Alarm setting
SMART SECURITY SYSTEM
Binding Account :Input the APP ID to the binding account. ( maximum 3
APP ID can be set).
Alarm Email : iput the email address to receive the ALARM message
from the device .
Motion Detection：Alarm will be triggered if device detects moving
objects in the video image
Buzzer：The device will start buzzer if any alarm appears
（2）Device update
Click device name ->setting-> Device update ：if have any new
version software ,it will remind the new software version
Number and ask user to confirm to update or cancel the updating
（3）Restore factory
Restore factory will clear all the settings: include WIFI information,
visiting password, Alarm signal, defense area setting etc.
Set as follow:
There is one reset hole on the bottom of the camera. Insert a clip
into the reset hole and keep for 3 seconds. Restore factory
successfully if the four indicators on the front brown panel are on
This manual suits for next models
