Sony XS-V1632 Marketing User manual

Design and Specifications subject to change without notice.

XS-V1632

3-Way Speaker

2002 SONY MOBILE

PRODUCT GUIDE

Specifications

Speaker Coaxial 3-way:

Woofer 5.8 cm (6 /4 in.) cone type

Midrange 3.5 cm ( 7/ 6 in.) balance dome type

Tweeter . cm (7/ 6 in.) dome type

Maximum input power 200 watts

Rated input power 50 watts

Impedance 4 ohms

Sensitivity 90 dB/W/m

Frequency response 30-25,000 Hz

Mass Approx. 7 5g ( lb. 9 oz.) per speaker

Parts

Part No. Description

-825-063- SPEAKER ( 6cm) (L)

-825-063-2 SPEAKER ( 6cm) (R)

3-240- 4- MANUAL, INSTRUCTION (ENGLISH, FRENCH, SPANISH, TRADITIONAL CHINESE)

3-240-639-0 PLATE, TOP

X-338 -853- NET ASSY, GRILLE (x2)

-574-3 8-7 CORD (WITH TERMINAL) (L) (WHITE)

-574-3 8-8 CORD (WITH TERMINAL) (R) (GRAY)

3-240- 89-0 SCREW (+P4 X 35), SPECIAL (x8)

3-392-870-0 NUT, SPEED (x8)

 6- /2 HOP Woofer Cone

 Balanced Drive Midrange

 Dome Tweeter

 New Xplod® design

 200W max input power (50W RMS)

 Flexible mounting options

 4W Voice Coil

 Indicates step-up

-

Dimensions

2002 SONY MOBILE

PRODUCT GUIDE

XS-V1632

3-Way Speaker

Design and Specifications subject to change without notice.

Unit: mm (in.)

28.7 (1 3/16)ø142 (5 5/8)14 (9/16)

44.5

(1 13/16)

ø80 (3 1/4)

ø126 (5)

ø158 (6 1/4)

ø4.5 (3/16)

4×5

(3/16 ×7/32)

ø169 (6 3/4)

163 (6

1

/

2

)
