Sony PXW-X400 Installation guide

QUICK MANUAL

The PXW-X400

INDHOLDSFORTEGNELSE

•Kamera & Medie 03 - 06

•Indlæsning af TV 2 standard settings 07

•PXW-X400 knapper og tilslutning 08 - 20

•Viewfinder 21 - 26

•Menu struktur 27 - 37

•Personlig opsætning 38 - 44

•Status oversigt 45 - 48

•Media restore 49

•Thumbnail 50 - 53

•Ingest in-house 54 - 57

•Ingest stand-alone 58

•Fremtiden med PXW-X400 kameraet 59

PXW-X400

3-CMOS EXMOR™ 2/3” SENSOR

ENG KAMERA

XAVC & MPEG HD422

PXW-X200

3-CMOS EXMOR™ ½” SENSOR

VJ KAMERA

XAVC & MPEG HD422

PXW-X70

1-CMOS EXMOR™ 1” TYPE SENSOR

ALTERNATIV KAMERA

XAVC & MPEG HD422*

*OPTION UPGRADE

TV 2 DANMARK SONY KAMERA LINE UP

SXS CARD 32Gb

•KAPACITET : 32 Gb

•LÆSE HASTIGHED : UP TO 3,5 Gbps

•5 ÅRS GARANTI

•OPTAGE TID: OP TIL 60 MIN VED 50 Mbps

OPTAGE MEDIE

NUVÆRENDE FORMAT :

CODEC : XDCAM 50 HD (HD422 50)

CONTAINER : MXF OP-1a

COMPRESSION : 50 MBIT/S 4:2:2 8 BITS

RESOLUTION : 1920x1080

FREQUENCY : 50/I

OPTAGE FORMAT PÅ TV 2 DANMARK

VÆGT

OMKRING 3,6

(KUN

KAMERA, UDEN OPTIK, VIEWFINDER OG MIKROFON)

DIMENSIONER

(LxBxH)

332 x 124

x 269 mm (KUN KAMERA)

STRØM

V CC

STRØM

FORBRUG

OMKRING 24 W

(MED VIEWFINDER, OPTIK OG MIKROFON

UNDER OPTAGELSE

)

DRIFT TEMPERATUR

CA. FRA

0 °C TIL 40 °C (SONY ANVISNING)

OPBEVARINGS

TEMPERATUR

CA.

FRA -20 °C TIL 60 °C (SONY ANVISNING)

TEKNISKE SPECIFIKATIONER

INDLÆS ALL FILES SETTINGS

INDLÆS TV 2 STANDARD SETTINGS

For at indlæse TV 2 Standard settings vælges,

MENU –FILE –ALL FILE –LOAD SD CARD –

01 TV 2 STD - EXECUTE

Nu er alle settings i kameraet sat til det er valgt som standard

settings på TV 2

INDLÆS TV 2 STANDARD SETTINGS

ONLINE BUTTON = OFF

FOR FUTURE USE!!!

ND FILTER WHEEL

ON/OFF POWER SWITCH

ASSIGNABLE 1 (BUTTON) =

ELECTRICAL CC

ASSIGNABLE 2 (SWITCH) =

PICTURE CACHE RECORD

ALARM LEVEL CONTROL WHEEL

MONITOR LEVEL CONTROL WHEEL

MENU BROWSER BUTTON

GAIN SWITCH: L/M/H

OUTPUT SELECT SWITCH: BARS/CAM

WHITE MEMORY SWITCH: PRESET/A/B

MONITOR TRACK SELECTOR SWITCH

ASSIGNABLE 0 (SWITCH) =

AUTO WHITE HOLD (ATW HOLD)

MULTIBLE MONITOR TRACK SELECTOR SWITCH

MENU SWITCH AND

CANCEL/ESCAPE SWITCH

FRONT VENSTRE SIDE

ASSIGNABLE BUTTON 4 & 5 (ON HANDLE)

ASSIGNABLE 4 (BUTTON) = REC

ASSIGNABLE 5 (BUTTON) = MARKER

ASSIGNABLE 3 (BUTTON) =

AUTO WHITE (ATW)

FRONT AF KAMERA (1)

12 PIN LENS CONNECTOR SHUTTER SELECTOR SWITCH: ON SELECT/OFF

AUTOMATIC WHITE/BLACK BALANCE SWITCH:

UP: WHITE BALANCE MEMORY

Down: BLACK BALANCE MEMORY

MICROPHONE LEVEL CONTROL: TRACK 1

PROTECTION FLAP FOR MIC LEVEL Control (PUSH TO THE SIDE)

RECORD BUTTON: REC ON/OFF

FRONT AF KAMERA (2)

12 PIN LENS CONNECTOR

ND FILTER WHEEL

1: CLEAR

2: 1/4ND

3: 1/16ND

4: 1/64ND

2/3" CMOS SENSOR

B4 LENS MOUNT
