Sony HDR-AS100V User manual

HDR-AS100V

4-543-590-11(2)

Digital HD Video Camera Recorder

This handbook includes operation manual for the additional functions.

Please refer to the “Operating Guide” (paper) and the “Handbook” (PDF) for other functions.

Handbook (Additional functions)

2GB

Table of contents

Setting items ···························································································································3

Live Streaming

About Live Streaming·············································································································4

Preparing Live Streaming ·······································································································5

Performing Live Streaming ····································································································6

Restrictions ·····························································································································8

Error messages························································································································9

New functions in still image shooting

Still image mode switching···································································································11

Still image shooting interval·································································································13

SELF-TIMER ·······················································································································14

Estimated number of recordable photos ···············································································15

3GB

The new functions are shown with an asterisk (*).

Click the item of the new functions to jump to the corresponding page.

• The display panel displays only English, French and Brazilian Portuguese. Other languages are not

available.

Setting items

List of modes

Display Modes

MOVIE Movie Mode

PHOTO Photo Mode

INTVL Interval Photo Recording Mode

* LIVE Live Streaming Mode

VMODE Image Quality Setting Mode

SETUP Setup Mode

PLAY Play Mode

PwOFF Power off

Items you can set in SETUP Items you can set in CONFG

Display Items Display Items

STEDY SteadyShot Wi-Fi Wi-Fi Remote Control

FLIP Flip GPS GPS Log

SCENE Scene PLANE Airplane Mode

LAPSE Interval Photo Recording USBPw USB Power Supply

COLOR Color Setting A.OFF Auto Power Off

PRO XAVC S™ BEEP Beep

TC/UB Time Code/User Bit DATE Date & Time Setting

IR-RC IR-Remote Controller DST Daylight Saving Time

(Summer Time) Setting

* DRIVE Still image mode switching LANG Language Setting

* FPS Still image shooting interval V.SYS Switching NTSC/PAL

* SELF SELF-TIMER RESET Resetting the Settings

CONFG Configuration Settings FORMT Format

Notes

4GB

Live Streaming

Live Streaming is a function to stream real-time video to a video streaming site such as

USTREAM, and can be accomplished by using this camera with a Wi-Fi router or smartphone

capable of tethering.

You can also send messages to your registered SNS (Facebook, Twitter, etc.) to announce that

you have started Live Streaming of video.*

* Registration to a video streaming site or SNS is required.

To perform Live Streaming, the following preparations are

required.

• User registration to USTREAM

• A smartphone (capable of tethering) or a Wi-Fi network environment

* For the tethering settings of your smartphone or the Wi-Fi network settings of your router, refer to the

instructions manual of your smartphone or your Wi-Fi router. For more details about the Wi-Fi network

settings, consult the network service provider.

About Live Streaming

Wi-Fi 3G/LTE

Tethering mode

Comments

from viewers

USTREAM

Viewers

5GB

Using the dedicated application, “Network Setting Tool,” configure the network settings and

You can download the dedicated application from the following support site.

http://www.sony.net/nst/

What you can do with network setting

You can set the following with the Live Steaming Settings of your camera.

• Network settings

You can set the Wi-Fi network to which your camera connects to.

– Network SSID, password

• Streaming settings

You can set the streaming method and information of videos.

– Streaming site, channel, image quality and the saving settings of the streaming site

– Title and description of streaming video

• SNS settings

By configuring this setting, you can post a comment through social network services when starting

streaming video.

– Connection settings for Twitter or Facebook

– Comments you post

• Your personal information (information required when logging in to USTREAM, Twitter or Facebook) is

set in the camera. Be sure to reset the camera when you transfer or dispose of it.

Preparing Live Streaming

Notes

“Network Setting Tool”

Input the USTREAM account and

information of the “Network Setting Tool.”

USB

OAuth authentication

Obtaining channel ID

zAbout USTREAM

USTREAM is a video sharing site through which you can stream and view videos with the

Live Streaming function of this camera.

For details of USTREAM, see the following site.

http://www.ustream.tv/

6GB

You can start Live Streaming after the preparation is complete.

When Live Streaming for the first time, it is recommended that you rehearse streaming in a

prepared environment after setting up with a computer in advance.

1Press the NEXT button to display [LIVE].

2Press the REC button to start streaming.

The display panel changes from [PREP] (preparing stream) to [ONAIR] (streaming) and the

REC lamp (page 7) lights red.

3Press the REC button again to stop streaming.

Performing Live Streaming

ttg

Setting

display

zAbout memory cards in the camera

You can record video that is Live Streaming into a memory card in the camera. When a

memory card is inserted in the camera, the video is recorded while streaming*.

If the memory card becomes full, recording stops automatically without stopping video

streaming.

When no memory card is inserted in the camera, only the video streaming is performed.

* The image format/quality of video recorded during streaming is MP4/HQ mode.

7GB

Display during Live Streaming

• There may be time lag of 10 - 20 seconds between the start of Live Streaming on your camera and video

streaming on the video streaming site.

REC lamp indicator during Live Streaming

If you select Live Streaming mode, you can see the

streaming status for Live Streaming with the REC lamp on

the camera.

Display Streaming status

Preparing to connect to the video streaming site.

Starts streaming.

Displays the number of viewers

Notes

REC lamp Status Streaming status

Off Before streaming

On Streaming

Slow-blinking

(Blinks about once per second) There are viewers.

Fast-blinking

(Blinks rapidly about 3 times per

second)

Streaming error

REC lamp

8GB

Restrictions for USTREAM

There are some restrictions for video streaming on USTREAM. For details, see the USTREAM site.

Restrictions on GPS and Wi-Fi functions during Live

Streaming

The GPS function is disabled automatically during Live Streaming.

Also, you cannot monitor images using a smartphone or the Live-View Remote during Live Streaming.

Network connection

Use a smartphone capable of tethering or Wi-Fi router for Live Streaming. However, proper operation with

all smartphones or Wi-Fi routers is not guaranteed. Public wireless LANs cannot be used as connections for

Live Streaming.

Simultaneous Live Streaming with multiple cameras

You cannot live stream videos simultaneously using the same account on more than 1 camera. You need to

connect using another account.

Effects due to wireless communication conditions

When connected using the tethering function of a smartphone or via a Wi-Fi router, images and sounds may

be interrupted, or the communication may be cut off due to wireless communication conditions.

Connection for Live Streaming

The communication time you can use for Live Streaming is limited according to the contract of your

smartphone or Wi-Fi router. Confirm it in advance.

Continuous streaming time

Continuous Live Streaming using this camera is limited to about 13 hours.

Restrictions of network connections

In some countries, you cannot connect to Live Streaming sites. Use this function in accordance with the

laws of that country.

Restrictions

9GB

If any trouble occurs when connecting for Live Streaming, the following messages appear.

Follow the instructions to resolve the problem.

Setting

NoSET

Set the necessary settings for USTREAM using “Network Setting Tool.”

Auth

CHANL

• The channel set by “Network Setting Tool” is incorrect.

• This message also displays if other media starts streaming on the same channel while streaming from

your camera is performed.

• Set the channel again.

DATE

Set the date and time again on your camera.

APErr

Access point has been found but is not connected.

Check the password of the access point and connect again.

Network

PREP

The network is temporarily unavailable.

Netwk

• The saving settings of video cannot be saved to USTREAM because an error has occurred on the

network.

• Some other network error has occurred.

• Confirm the setting of the access point or the security of the access point using “Network Setting

Tool.”

NO AP

Access point cannot be found. Confirm the setting of the access point using “Network Setting Tool.”

Error messages

10GB

Network Service

ERROR

An unknown error has occurred on USTREAM. Wait a moment and then try confirming the connection

again.

LIMIT

The total time of saved video on USTREAM has reached the limit. Stop streaming video.

TWErr

Twitter post error.

Check the network or log in to Twitter again.

FBErr

Facebook post error.

Check the network or log in to Facebook again.

The camera

ERROR

Turn the power off and then on again.

HEAT

• The camera temperature has risen. The power may turn off automatically, or you may be unable to

record images. Leave the camera in a cool location until the temperature goes down.

• If you record images for an extended period, the camera temperature rises. In this case, stop recording

images.
