TAP-9000ES

DESCRIPTION:

DIMENSIONS

(WHD):

WEIGHT:

POWER

REQUIREMENTS:

POWER

CONSUMPTION:

FRONT VIEW

SIDE VIEW

Multi Channel

Pre Amplifier

17" x 4 7/8" x 15 1/4 "

120VAC

60Hz

20

Watts

Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.

4 7/8"

1/2"2 " 12 " 2 "

17"

4 1/4"

1/2"

Approx 22 lbs

NOTE:

WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING

OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE

RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL

MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES IN

THE DESIGN OR MANUFACTURE OF ENCLOSURES .

5/8"

RMP-9000 REMOTE COMMANDER

Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com

BACK VIEW

2 " 2 "

15 1/4"

8 3/8 "1 1/4 " 1/2 "

ES

INPUT 1 INPUT 2 BYPASS 5.2 CH

BYPASS 2CH

PRE OUT

IR

SENSOR

L

R

FRONT REAR CENTER

WOOFER

L

R

FRONT REAR CENTER

WOOFER

L

R

FRONT REAR CENTER

WOOFER

L

R

L

R

FRONT REAR CENTER

WOOFER

CTRL A1

TO POWER AMP

AC
