SonoSite C1.9 PLUS User manual

C1.9 PLUS

Ultrasound System

Service Manual

ii C1.9 PLUS Ultrasound System Service Manual

P02287-03 01/2003

iii

Manufactured by

SonoSite, Inc.

21919 30th Drive SE

Bothell, WA 98021-3904

USA

Telephone: 1-888-482-9449 or +1-425-951-1200

Fax: +1-425-951-1201

SonoSite European Headquarters

Baystrait House, Station Road

Biggleswade SG18 8AL

Telephone: +44-1767-313-117

Fax: +44-1767-312-400

CAUTION:

`United States federal law restricts this device to sale by or on the order of a

physician.

“SiteCharge,” “SitePack,” “SiteStand,” and “SonoHeart,” are trademarks of SonoSite, Inc.

Non-SonoSite product names may be trademarks or registered trademarks of their respective

owners.

SonoSite products may be covered by one or more of the following U.S. patents: 4454884, 4462408,

4469106, 4474184, 4475376, 4515017, 4534357, 4542653, 4543960, 4552607, 4561807, 4566035,

4567895, 4581636, 4591355, 4603702, (4607642), 4644795, 4670339, 4773140, 4817618,

4883059, 4887306, 5016641, 5050610, 5095910, 5099847, 5123415, 5158088, 5197477, 5207225,

5215094, 5226420, 5226422, 5233994, 5255682, (5275167), 5287753, 5305756, 5353354,

5365929, 5381795, 5386830, 5390674, 5402793, (5,423,220), 5438994, 5450851, 5456257,

5471989, 5471990, 5474073, 5476097, 5479930, 5482045, 5482047, 5485842, 5492134, 5517994,

5529070, 5546946, 5555887, 5603323, 5606972, 5617863, (5634465), 5634466, 5636631,

5645066, 5648942, 5669385, (5706819), 5715823, 5718229, 5720291, 5722412, 5752517,

5762067, 5782769, 5800356, 5817024, 5833613, 5846200, 5860924, 5893363, 5916168, 5951478,

6036643, 6102863, 6104126, 6113547, 6117085, 6142946, 6203498 B1, D0280762, D0285484,

D0286325, D0300241, D0306343, D0328095, D0369307, D0379231. Other patents pending.

iv C1.9 PLUS Ultrasound System Service Manual

Table of Contents

CHAPTER 1Introduction 1

1.1 About the System......................................................................1

1.2 Audience ...................................................................................2

1.3 Conventions Used in This Manual............................................2

1.4 About the System Software ......................................................2

1.5 Software Licensing ...................................................................3

CHAPTER 2Safety 5

2.1 Electrical Safety ........................................................................5

2.1.1 Equipment Protection .........................................................7

2.2 Battery Safety............................................................................8

2.3 Biological Safety.......................................................................9

2.4 Labeling Symbols .....................................................................9

CHAPTER 3System Overview 11

3.1 Theory of Operation................................................................11

3.1.1 Transducer ........................................................................12

3.1.2 Acquisition Subsystem .....................................................12

3.1.3 Processing Subsystem ......................................................12

3.1.4 Display Subsystem ...........................................................12

3.1.5 Control Subsystem ...........................................................12

3.1.6 User Interface Subsystem.................................................12

3.1.7 Power Subsystem .............................................................13

3.2 Components ............................................................................13

3.3 Controls...................................................................................14

3.4 Accessories .............................................................................15

3.4.1 Battery Pack .....................................................................15

3.4.1.1 Battery Charge Indicators ............................................15

3.4.2 External Power .................................................................16

3.4.2.1 External System Connections ......................................16

3.4.3 Power Adapter..................................................................17

3.5 System Specifications .............................................................17

3.5.1 Physical Dimensions ........................................................17

3.5.2 Monitor.............................................................................17

3.5.3 Transducers ......................................................................18

3.5.4 Imaging Modes.................................................................18

vi C1.9 PLUS Ultrasound System Service Manual

3.5.5 Image Storage...................................................................18

3.5.6 Temperature, Pressure, and Humidity Limits ..................18

3.5.6.1 System Operating .........................................................18

3.5.6.2 System Shipping/Storage ............................................18

3.5.6.3 Battery Operating.........................................................18

3.5.6.4 Battery Shipping/Storage .............................................18

3.5.6.5 Transducers Operating .................................................18

3.5.6.6 Transducers Shipping/Storage .....................................19

3.5.7 Electrical...........................................................................19

3.6 Battery.....................................................................................19

3.7 Safety Requirements ...............................................................19

3.7.1 Meets Electromechanical Safety Standards .....................19

3.7.2 Meets EMC/EMI Standards .............................................20

3.7.3 Meets Airborne Equipment Standards (without ECG Cable

Attached) ..........................................................................20

3.7.4 Meets ECG Standard........................................................20

CHAPTER 4Setup and Operation 21

4.1 Connecting and Removing Transducers .................................21

4.2 Turning the System On and Off..............................................22

4.3 Installing and Removing the Battery ......................................23

4.4 Using AC Power .....................................................................24

4.5 Upgrading the System Software .............................................25

4.6 Obtaining A License Key .......................................................26

4.6.1 Installing A License Key..................................................26

4.6.1.1 Displaying the System Information Screen .................28

4.7 Checking and Charging the Battery........................................28

CHAPTER 5Cleaning and Disinfecting 31

5.1 Universal Precautions .............................................................31

5.2 Receipt of Suspected Contaminated Materials .......................31

5.3 Recommended Disinfectants ..................................................32

CHAPTER 6Troubleshooting 33

6.1 System and Subsystem Diagnosis...........................................33

6.2 System Repair .........................................................................33

6.3 Test Equipment .......................................................................33

vii

6.4 Failures....................................................................................34

6.4.1 Display..............................................................................34

6.4.2 Control Panel....................................................................34

6.4.3 Trackball...........................................................................34

6.4.4 Main PCBA ......................................................................34

6.4.5 Clearing the Main PCBA Failure .....................................35

6.4.6 Battery ..............................................................................35

CHAPTER 7Replacement Procedures 43

7.1 Display Subassembly Replacement ........................................43

7.1.1 Required Parts ..................................................................43

7.1.2 Required Tools and Materials ..........................................43

7.1.3 Removing the Display Subassembly................................44

7.1.4 Replacing the Display Subassembly ................................46

7.2 Control Panel Subassembly Replacement ..............................48

7.2.1 Required Parts ..................................................................48

7.2.2 Required Tools .................................................................48

7.2.3 Removing the Control Panel Subassembly ......................49

7.2.4 Replacing the Control Panel Subassembly.......................51

7.3 Trackball .................................................................................52

7.3.1 Required Parts ..................................................................52

7.3.2 Required Tools .................................................................52

7.3.3 Removing the Trackball ...................................................52

7.3.4 Replacing the Trackball....................................................55

7.4 Main PCBA Subassembly Replacement.................................57

7.4.1 Required Parts ..................................................................57

7.4.2 Required Tools .................................................................58

7.4.3 Removing the Main PCBA Subassembly ........................58

7.4.4 Replacing the Main PCBA Subassembly.........................59

7.5 Transducers .............................................................................62

7.6 AC Power Adapter..................................................................62

7.7 OEM Peripherals.....................................................................63

7.7.1 External Monitor (Sony) ..................................................63

7.7.2 VCR (Sony)......................................................................63

7.7.3 Printer (Sony) ...................................................................63

viii C1.9 PLUS Ultrasound System Service Manual

CHAPTER 8Performance Tests 65

8.1 Overview.................................................................................65

8.2 Test Equipment:......................................................................65

8.3 Setting Up Performance Tests ................................................66

8.3.1 Scan Reference Orientation..............................................66

8.4 Testing 2D Performance .........................................................66

8.4.1 2D Image Quality .............................................................66

8.4.2 Axial Measurement Accuracy..........................................67

8.4.3 Lateral Measurement Accuracy .......................................67

8.4.4 Penetration........................................................................68

8.5 Additional Performance Tests ................................................68

8.5.1 CPD ..................................................................................68

8.5.2 PowerMap DCPD.............................................................69

8.5.3 M-mode Imaging..............................................................69

8.5.4 Tissue Harmonic Imaging ................................................70

8.5.5 Pulsed Wave (PW) Doppler Imaging...............................70

8.5.6 ECG Monitoring...............................................................70

8.5.7 Image Quality Verification Test.......................................71

8.5.8 Image Review...................................................................71

8.5.9 Printer ...............................................................................71

8.5.10 Battery Charging ..............................................................71

8.5.11 Video Output ...................................................................71

8.6 Returning Products to SonoSite..............................................72

8.6.1 Contacting SonoSite Technical Support ..........................72

8.6.2 Shipping Instructions........................................................72

APPENDIX AParts List 73

APPENDIX BService Event Report 85

Index 87

Chapter 1: Introduction 1

CHAPTER 1Introduction

Before servicing the SonoSite ultrasound system, please read the information in this

manual. This text applies to SonoSite ultrasound system products manufactured after

April 27, 2001. Please find service information about products manufactured before

April 27, 2001 in C1.51 Ultrasound System Service Manual (P00715) and C1.75

Ultrasound System Service Manual (P01118).

1.1 About the System

The SonoSite system has various configurations and features. All are described in

this manual but not every option may apply to your system. System features are

dependent on your system configuration, transducer and exam type.

The SonoSite system is a portable, software-controlled, ultrasound system. It has an

all-digital architecture. It is used to acquire and display high-resolution, real-time,

2D, Color Power Doppler (CPD), PowerMap™(PM) Directional Color Power

Doppler (DCPD), Tissue Harmonic Imaging (THI), M-mode and Pulsed Wave (PW)

Doppler ultrasound images. The system has electrocardiography (ECG), cine

review, image zoom, labeling, biopsy, measurements and calculations, serial port

connection for image transfer, image storage and review, printing and recording

capabilities. The system setup also has a selection to support optical character

recognition (OCR) of the English character set for time, date, patient name, and

patient identification. The OCR screen characters are optimized for use with the ALI

NewPORT DICOM image capture station peripheral available from ALI. For more

information about the ALI NewPORT 2.1, refer to the ALI NewPORT 2.1 Image

Capture Station User’s Guide.

Currently, the system supports the following broadband transducers:

• C60/5-2 MHz 60-mm curved array

• C15/4-2 MHz 15-mm micro-curved array

• C11/7-4 MHz 11-mm micro-curved array

• ICT/7-4 MHz 11-mm intracavitary

• L38/10-5 MHz 38-mm linear array

2 C1.9 PLUS Ultrasound System Service Manual

System accessories include a SiteStand®mobile docking station and accessories,

SiteCharge™dual battery charger, a power adapter, a battery, ECG cable, video and

printer cables, SiteLink image manager software, SiteStand®basket, Basic Stand,

CRT Stand, ScanPack quick access carrier, and SitePack™protective carry pack.

System peripherals include medical grade (conforming to the requirements of

EN60601-1) and non-medical (commercial) grade products. System medical grade

peripherals include an external color monitor, video printers, and VCRs. System

non-medical grade peripherals include a digital video recorder, a battery charger, a

lithium-ion battery, printer, and a handheld monitor. Use of peripherals is covered in

the manufacturers’ instructions, which accompany each peripheral. System setup

instructions for the use of peripherals are covered in Chapter 3 in the SonoSite

Ultasound System User Guide.

1.2 Audience

The intended audience of this manual is properly trained field and in-house service

personnel.

1.3 Conventions Used in This Manual

These conventions are used in this user guide:

• Warnings and cautions are identified with the arrow symbol.

• Control names and references to display elements are presented in bold-face

type.

• Operating instructions are introduced with a statement in bold-face type that

ends with a colon. For example: To read this user guide:

• When the steps in the operating instructions must be performed in a specific

order, the steps are numbered.

• Bulleted lists present information in list format, but they do not imply a

sequence.

• Screen display text is shown in Arial 10 pt. For example: Successful upgrade.

• The left side of the system is to your left as you face the system. The system

handle is at the top of the system, the battery compartment is at the bottom of the

system.

• Note: A note cites information that is a general rule for a procedure, gives an

exception to a rule, or provides noncritical information of general interest.

1.4 About the System Software

Your SonoSite system contains software that controls its operation. From time to

time, SonoSite may provide new software for use with your system. This software is

provided using a software update module or a transducer. This software may be

either required or optional. A single module or transducer can be used to update one

or more systems.

When the new software is required, you must install it if you wish to use the new

software features (e.g., new transducer). If you choose not to install it, you must

Table of contents

Other SonoSite Medical Equipment manuals

SonoSite

SonoSite iViz User manual

SonoSite

SonoSite PowerPack User manual

SonoSite

SonoSite M-Turbo User manual

SonoSite

SonoSite Mobile Docking System M Series User manual

SonoSite

SonoSite Basic Stand User manual

SonoSite

SonoSite PowerPack User manual

SonoSite

SonoSite iLook User manual

SonoSite

SonoSite Lite II User manual

SonoSite

SonoSite iLook User manual

SonoSite

SonoSite titan User manual

SonoSite

SonoSite S-Cath User manual

SonoSite

SonoSite SiteStand Mobile Docking Station User manual

SonoSite

SonoSite M-Turbo User manual

SonoSite

SonoSite NanoMaxx User manual

SonoSite

SonoSite M-Turbo User manual

SonoSite

SonoSite M-Turbo User manual

SonoSite

SonoSite V-UNIVERSAL STAND User manual

SonoSite

SonoSite titan Owner's manual

SonoSite

SonoSite S Series User manual

Popular Medical Equipment manuals by other brands

TekTone

TekTone Tek-CARE160 Installation and operation manual

NeuroMetrix

NeuroMetrix Quell 2.0 user manual

AMT

AMT XLR8 Quick reference guide

Medipost-Nutristoma

Medipost-Nutristoma MD300K2 instruction manual

EDAN

EDAN SONOTRAX Pro user manual

Restorative Therapies

Restorative Therapies RT300 Service guide

Gendex

Gendex Expert DC installation manual

Dexcowin

Dexcowin ADX4000W user manual

Libelium

Libelium MySignals user manual

Acelity

Acelity V.A.C.ULTA 4 user manual

Caputron

Caputron ActivaDose II tDCS quick start guide

FujiFilm

FujiFilm Sonart Features

Plinth 2000

Plinth 2000 93CDT Service manual

GE SENOGRAPHE 800T Operator's manual

GE Definium 5000 Operator's manual

Kanmed

Kanmed GE-1380 user manual

Huntleigh

Huntleigh FD1 Instructions for use

Stryker

Stryker SPR Plus Operation manual
