Smeg SCU45VCS1 User manual

Instructions for Use

Combi Steam oven

Consignes d’utilisation

Four à vapeur Combi

1631028

Table of Contents

INSTRUCTIONS FOR THE USER: these provide recommendations for

use, a description of the controls and the correct procedures for cleaning

and maintaining the appliance

INSTRUCTIONS FOR THE INSTALLER: these are intended for the

qualified engineer who is to install, commission and test the appliance

1PRECAUTIONS FOR USE..............................................................................11

2GET TO KNOW YOUR OVEN.........................................................................12

3ACCESSORIES AVAILABLE ..........................................................................12

4BEFORE INSTALLATION ...............................................................................13

5DESCRIPTION OF FRONT PANEL CONTROLS ...........................................13

6USING THE OVEN..........................................................................................15

7WATER FEEDING...........................................................................................16

8SELECTING THE FUNCTION.........................................................................17

9RECOMMENDED COOKING TABLES: COOKING WITH STEAM.................28

10 COOKING WITH THE GRILL..........................................................................33

11 COOKING WITH HOT AIR..............................................................................34

12 CARE AND MAINTENANCE...........................................................................36

13 OVEN CLEANING...........................................................................................39

14 EXTRAORDINARY MAINTENANCE...............................................................40

15 DISPOSAL INSTRUCTIONS - OUR ENVIRONMENT POLICY......................42

16 BEFORE INSTALLATION ...............................................................................44

17 POSITIONING THE OVEN..............................................................................48

Grounding Instructions

This appliance must be connected to a

grounded, metallic, permanent wiring

system, or an equipment grounding

conductor should be run with the circuit

conductors and connected to the

equipment grounding terminal or lead on

the appliance.

Warning! IMPROPER USE OF THE

GROUNDING CAN RESULT IN A RISK OF

ELECTRICAL SHOCK.

Please refer to the Installation

Instructions for further information.

Safety Information

Carefully read the instructions before

installing and using the equipment. The

manufacturer is not liable for improper

installation and use of the equipment that

may cause injuries and damage. Always

keep the instructions at hand, so they can

be easily referred to during use.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed

including the following:

1. Proper Installation –Be sure your

appliance is properly installed and

grounded by a qualified technician.

2. Never Use Your Appliance for Warming

or Heating the Room.

3. Do Not Leave Children Alone –Children

should not be left alone or unattended in

area where appliance is in use. They

should never be allowed to sit or stand on

any part of the appliance.

4. Wear Proper Apparel –Loose-fitting or

hanging garments should never be worn

while using the appliance.

5. User Servicing –Do not repair or replace

any part of the appliance unless

specifically recommended in the manual.

Safety Information

All other servicing should be referred to a

qualified technician.

6. Storage in or on Appliance –Flammable

materials should not be stored in an oven

7. Do Not Use Water on Grease Fires –

Smother fire or flame or use dry chemical

or foam-type extinguisher.

8. Use Only Dry Potholders –Moist or damp

potholders on hot surfaces may result in

burns from steam. Do not let potholder

touch hot heating elements. Do not use a

towel or other bulky cloth.

9. Use Care When Opening Door –Let hot

air or steam escape before removing or

replacing food.

10. Do Not Heat Unopened Food Containers

–Build-up of pressure may cause

container to burst and result in injury.

11. Keep Oven Vent Ducts Unobstructed.

12. Placement of Oven Racks –Always place

oven racks in desired location while oven

is cool. If rack must be moved while oven

is hot, do not let potholder contact hot

heating element in oven.

13. DO NOT TOUCH HEATING ELEMENTS

OR INTERIOR SURFACES OF OVEN –

Heating elements may be hot even

though they are dark in color. Interior

Safety Information

surfaces of an oven become hot enough

to cause burns. During and after use, do

not touch, or let clothing or other

flammable materials contact heating

elements or interior surfaces of oven

until they have had sufficient time to

cool.

This Steam Oven is for household use

Safety Information

Safety of children and vulnerable adults

WARNING! Risk of choking, injury or

permanent disability.

This appliance can be used by children aged 8

years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they are given

supervision or instructions concerning how to

use the appliance in a safe way and

understand the hazards involved.

Children should not play with the appliance.

Keep packaging materials away from children.

Risk of suffocation!

Keep children away from the appliance during

operation or when cooling.

Cleaning and maintenance should not be done

by children without supervision

Warnings on general safety

During installation, follow the instructions

supplied separately.

Only qualified personnel can install the

appliance and replace the cable.

WARNING: The appliance and its

accessible parts become hot during use. Care

should be taken to avoid touching heating

elements. Children less than 8 years of age

Safety Information

shall be kept away unless continuously

supervised.

During use the appliance becomes hot. Care

should be taken to avoid touching heating

elements inside the oven.

WARNING: Accessible parts may become

hot during use. Young children should be kept

away.

Do not use steam cleaners to clean the

appliance.

Do not use abrasive detergents or metal

scrapers to clean the appliance.

The electric connection is made via an

omnipolar switch, which is suitable for the

intensity to be tolerated and which has a

minimum gap of 3mm between its contacts,

which will ensure disconnection in case of

emergency or when cleaning the crockery

warmer. If a plug is used for the electric

connection, then it must be accessible after

installation.

The connection should include correct

earthing, in compliance with current norms.

Disconnect the appliance from the power

supply before carrying out any maintenance

operation

Safety Information

WARNING!

Before connecting the appliance compare the power data (voltage and frequency)

indicated on the characteristics plate with those of the power supply in question. If

these data do not match there may be problems. In case of doubt, contact an

electrician.

WARNING!

If the electrical wire plug is removed, the appliance must be installed and connected

by a technician. Contact a qualified electrician who knows and respects current

safety standards. The manufacturer cannot be held responsible for damage

resulting from fitting or connecting errors.

WARNING!

The electrical safety of the appliance can only be guaranteed if it is earthed. The

manufacturer cannot be held responsible for damage resulting from the absence of

or defects in the installation’s protection system (e.g. electrical shock).

WARNING!

Only use the appliance once it has been fitted into its built-in position. Only in this

manner can it be guaranteed that users cannot access the electrical components.

WARNING!

Never open up the appliance’s frame. Possible contacts with electrical conducting

parts or changes to electrical or mechanical components may represent a danger to

users’ safety and prejudice the correct working of the appliance.

WARNING!

Repairs and maintenance, especially of parts carrying electrical current, must only

be done by technicians authorised by the manufacturer. The manufacturer and

retailers do not accept responsibility for any damaged caused to people, animals or

property as a result of repairs and maintenance carried out by non-authorised

personnel.

Safety Information

WARNING!

Repairs undertaken during the guarantee period must only be done by technicians

authorised by the manufacturer. If this is not the case then any damage resulting

from the repair in question is excluded from the guarantee

WARNING!

The appliance must be disconnected from the electrical current when installation

and repair work is being done. To disconnect the appliance from the current, one of

the following conditions must apply:

•The switchboard fuses / circuit breakers must be disconnected.

•The plug should be removed from the socket. To remove the plug from the

socket do not pull on the electric cable but rather pull out the plug itself

directly.
