FOOT PUMP

Warranty

All products manufactured by or for Sawyer Manufacturing Company are

guaranteed against defects due to faulty workmanship or materials for twelve

months from the date of purchase.

This guarantee is limited to the repair or replacement of any parts found to be

defecve, and no other liability, expressed, implied or conngent is assumed.

We appreciate your business!

Congratulaons on your new SAWYER product. We are proud to have

you as our customer and will strive to provide you with the best service

and reliability in the industry. This product is backed by our extensive

warranty and world-wide service network. To locate your nearest

distributor or service agency, please contact us at the phone number

and address listed on the boom of each page.

You are in good company!

Sawyer Manufacturing Company is the world leader in the design and

manufacture of pipeline and welding equipment since 1948. Sawyer

equipment has become a standard in the industry and connues to set

the benchmark for quality and durability.

This user operaon manual has been made to instruct you for the best

use and operaon of your Sawyer product. Your sasfacon with our

products is our main goal. Please read this enre manual carefully

nong all ps, notes and warnings. Safety always comes rst.

About Us

A. Hydraulic Hose Fing

B. Pneumac Air Fing

C. Pressure Relief Valve

D. Hydraulic Cylinder Foot Release

E. 10,000 PSI Hydraulic Hose

F. Hydraulic Foot Pump

WARNING: Moving parts can snag

and pull. Keep loose items clear.

! !

WARNING

WARNING: Refer to manufactures

sengs for safety sengs.

! !

WARNING

Refer to ENERPAC manual for maintenance of ENERPAC pump.

Tools Needed for Assembly*

Air HoseAir Compressor

*Not Included

Pneumatic

Foot Pump

Manual

Model 526-20

For Models 273-15, 273-25 &

273-55

Parts Diagram

Sawyer Manufacturing Company

7799 S. Regency Dr., Tulsa, OK 74131 USA

F918.834.0318

info@sawyermfg.com

P918.834.2550

sawyermfg.com

V1.2

FOOT PUMP

1. Install Hydraulic hose ng (A, Fig. 1) from foot pump to

strap and/or tensile machine.

2. Install air hose (Fig. 3) to pneumac air ng. (B, Fig. 2)

Note: Refer to the 15, 25 & 50 Ton Guided Bend and Tensile Tester manual

for installaon procedures.

Installaon

Operaon

CAUTION: Moving parts.

! !

CAUTION

CAUTION: Refer to air compressor

safety guidelines.

! !

CAUTION

1. Before Operaon, Release the Pressure Release Valve

(C, Fig. 4) by pulling up.

2. Press foot down on the foot pump (F, Fig. 5) to depress

traveling head.

3. Press foot down on the foot release (D, Fig. 6) to relieve

pressure from traveling head.

Note: Refer to the 15, 25 & 50 Ton Guided Bend and Tensile Tester manual

for operaon procedures.

Fig. 2

Fig. 1

Fig. 2

Fig. 4

Fig. 5
