SMC Networks 8506T User manual

SMC8506T

EZ Switch 1000

Unmanaged Layer 2 plus Gigabit Switch

The SMC family of EZ Switch 1000 Gigabit Ethernet

Switches (SMC8504T SMC8506T) is the perfect

solution for bottlenecks at the core of a network.

Bottlenecks are the inevitable result of data-intensive

applications and the proliferation of new users. SMC’s

EZ Switch 1000 provides a seamless migration to

higher-speed networking while solving bandwidth

issues. It is designed to allow simultaneous transmission

of multiple packets via an internal high-speed data

channel.

In addition, the SMC8506T offers one module slot for

2 Ethernet Gigabit ports to uplink to server or network

backbone. These gigabit switches are designed for Plug

and Play installation, allowing the network

administrator to simply connect the network and power

cables while the switching/ bridging functions begin

automatically. Equipped with advanced features such

as port trunking, priority queues, VLANs for security

and traffic prioritization, the SMC8506T is a perfect

choice to fulfill today’s diverse networking needs.

All SMC products are backed by a limited lifetime

warranty.

Features and Benefits

High Performance & Functionality

lAuto MDI/MDI-X on each port to simplify cabling

and integration into a network

lProvide a module slot for 2-port 10/100/1000BASE-T

or 1000BASE-SX options

lFeatures Store-and-Forward mode with wire-speed

filtering and forwarding rates

lIEEE802.3x compliant full-duplex flow control, HOL

blocking prevention

lAutomatic Source Address Learning and Aging to

ensure superior delivery of data

lSupport to handle Jumbo Packets up to 1536 bytes

packet

lBroadcast storm control and CRC Filtering

eliminates erroneous packets to optimise the network

bandwidth

lLED indicators for simple diagnostics and management

Flexible System Management

lAdvanced functions include changing port

configurations, port-base VLAN (not support port-base

VLAN overlap), tagged-base QoS (not support port-

base QoS), trunking, Port Mirroring etc.

Compatibility

lIIEEEEEE802.3z, 802.3u, 802.3ab, 802.3x

EZ Switch™ 1000

SMC8506T

Data Sheet

Product Model No. Description

EZ Switch 1000 SMC8506T 6 + 2-Port Unmanaged

Layer 2 + Gigabit Switch

SMC8500GT 2-Port 10/100/1000BASE-T

Gigabit Module

SMC8500SX 2-Port 1000BASE-SX

Gigabit Module

Specifications

Physical Characteristics

Ports

l6-Port auto-MDIX 10/100/1000Mbps RJ-45

auto-sensing ports

Net ork Media:

l100BASE-TX, UTP/STP category 3 or 5 cable

l1000BASE-T, UTP/STP Category 3 or 5 cable

l1000BASE-TX, UTP/STP category 5 cable, 4 pairs

l1000BASE-SX, Multi-mode 62.5/125_m fibre optic

cable Connector: SC

LED Indicators

lSystem - Power OK, Smart LED

Individual Port (Copper)

lLink1000, Link100, Link10, FDX/COL, TX, RX, LEDs

Individual Port (Fibre)

lLink, Activity LEDs

For arding Method

lStore and Forward

Frame Size

lJumbo packets up to 1536 bytes

MAC Address

l24k

Dimension

l433mm (L) x 200mm (W) x 44mm (H)

l17.05 in x 7.87 x 1.73 in

Temperature

lOperating - 0 to 40ºF

lStorage - -20 to 70ºF

Humidity

lOperating - 10% to 90% RH

lStorage - 5% to 90% RH

Input Po er Requirement

100 - 240VAC, 50 - 60Hz,

lAuto-sensing

SMC Netw rks Eur pe

Head Office

Edificio Conata II

Fructuós Gelabert 6-8 20,4a

08970 - Sant Joan Despi

Barcelona

Spain

Telephone

+34 93 477 4920

Facsimile

+34 93 477 3774

SMC Netw rks

Spain

Calle Josefa Valcarcel, 8

28027 - Madrid

Spain

Telephone

+34 91 320 2884

Facsimile

+34 91 320 8438

SMC Netw rks

N rthern Eur pe

Ground Floor, Exa House

Alexandra Court

Denmark Street

Wokingham

Berkshire, RG40 2SL

United Kingdom

Telephone

+44 (0)118 974 8700

Facsimile

+44 (0)118 974 8701

SMC Netw rks

N rdic

Vallingbyplan 26, 2 tr

SE-162 65 Vallingby

Sweden

Telephone

+46 (0) 8 687 0700

Facsimile

+46 (0) 8 87 62 62

SMC Netw rks

S uth Africa

Zonneblom Building

16th Road

Constantia Square

Midrand

South Africa

Telephone

+27 (0) 83 292 40 43

Facsimile

+27 (0) 11 805 80 60

SMC Netw rks

S uthern Eur pe

2 - 8 rue des Bourets

92150 Suresnes

France

Telephone

+33 (0) 1 41 38 32 32

Facsimile

+33 (0) 1 41 38 01 58

SMC Netw rks

Central Eur pe

Freischützstr. 81

D-81927 Munich

Germany

Telephone

+49 (0) 89 92861-0

Facsimile

+49 (0) 89 92861-230

SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.

Layer 2+ Features

(configurable thru RS-232 DB-9 console connection)

l8 groups of VLANs (port-based)

lMaximum 8 groups of trunks

lPort Aging time control

lPort enabled/disabled

lPort Mirroring

lIEEE802.1P priority queues

lMAC Address filtering

lPassword Access to configuration

Standards C nf rmance

Safety & EMI:

lFCC Part 15 Class A

lCE

lC-Tick

lVCCI

lCUL

lTUV

Standards

lIIEEEEEE802.3z, 802.3u, 802.3ab, 802.3x

Warranry

lLimited Lifetime

.smc.com .smc-europe.com

EZ Switch™ 1000

SMC8506T

Data Sheet
