SMC Networks 8028L2 User manual

INSTALLATION GUIDE

TigerSwitchTM 10/100/1000

28-Port Gigabit Ethernet Switch

SMC8028L2

20 Mason

Irvine, CA 92618

Phone: (949) 679-8000

TigerSwitch 10/100/1000

Installation Guide

From SMC's Tiger line of feature-rich workgroup LAN solutions

Janurary 2010

Pub. # 150200000155A

E012010-MW-R01

20 Mason

Irvine, CA 92618

Phone: (949) 679-8000

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and

reliable. However, no responsibility is assumed by SMC for its use, nor for any

infringements of patents or other rights of third parties which may result from its use. No

license is granted by implication or otherwise under any patent or patent rights of SMC.

SMC reserves the right to change specifications at any time without notice.

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are

trademarks of SMC Networks, Inc. Other product and company names are trademarks or

registered trademarks of their respective holders.

ARRANTY

AND

RODUCT

EGISTRATION

To register SMC products and to review the detailed warranty statement,

please refer to the Support Section of the SMC Website at http://

www.smc.com.

– 5 –

COMPLIANCES AND SAFETY

STATEMENTS

FCC - CLASS A

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the

interference at his own expense.

You are cautioned that changes or modifications not expressly approved by the

party responsible for compliance could void your authority to operate the

equipment.

You may use unshielded twisted-pair (UTP) for RJ-45 connections - Category 3

or better for 10 Mbps connections, Category 5 or better for 100 Mbps

connections, Category 5, 5e, or 6 for 1000 Mbps connections. For fiber optic

connections, you may use 50/125 or 62.5/125 micron multimode fiber or 9/125

micron single-mode fiber.

OMPLIANCES

AND

AFETY

TATEMENTS

– 6 –

CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)

This information technology equipment complies with the requirements of the

Council Directive 89/336/EEC on the Approximation of the laws of the Member

States relating to Electromagnetic Compatibility and 73/23/EEC for electrical

equipment used within certain voltage limits and the Amendment Directive 93/

68/EEC. For the evaluation of the compliance with these Directives, the following

standards were applied:

RFI Emission: ◆Limit class A according to EN 55022

◆Limit class A for harmonic current emission according to EN 61000-3-

◆Limitation of voltage fluctuation and flicker in low-voltage supply

system according to EN 61000-3-3

Immunity: ◆Product family standard according to EN 55024

◆Electrostatic Discharge according to EN 61000-4-2

◆Radio-frequency electromagnetic field according to EN 61000-4-3

◆Electrical fast transient/burst according to EN 61000-4-4

◆Surge immunity test according to EN 61000-4-5

◆Immunity to conducted disturbances, Induced by radio-frequency

fields: EN 61000-4-6

◆Power frequency magnetic field immunity test according to EN 61000-

4-8

◆Voltage dips, short interruptions and voltage variations immunity test

according to EN 61000-4-11

LVD: ◆EN 60950-1:2001

OMPLIANCES

AND

AFETY

TATEMENTS

– 7 –

SAFETY COMPLIANCE

Warning: Fiber Optic Port Safety

Avertissment: Ports pour fibres optiques - sécurité sur le plan optique

Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit

PSE ALARM

本製品に同梱いたしております電源コードセットは、

本製品専用です。本電源コードセットは、本製品以外の

製品並びに他の用途でご使用いただくことは出来ません。

製品本体に同梱された電源コードセットを利用し、他製品

の電源コードセットを使用しないで下さい。

When using a fiber optic port, never look at the transmit

laser while it is powered on. Also, never look directly at the

fiber TX port and fiber cable ends when they are powered

on.

Ne regardez jamais le laser tant qu'il est sous tension. Ne

regardez jamais directement le port TX (Transmission) à

fibres optiques et les embouts de câbles à fibres optiques

tant qu'ils sont sous tension.

Niemals ein Übertragungslaser betrachten, während dieses

eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß

und auf die Faserkabelenden schauen, während diese

eingeschaltet sind.

CLASS I

LASER DEVICE

DISPOSITIF LASER

DE CLASSE I

LASERGER

DER KLASSE I

ÄT

OMPLIANCES

AND

AFETY

TATEMENTS

– 8 –

POWER CORD SAFETY

Please read the following safety information carefully before installing

the switch:

WARNING:

Installation and removal of the unit must be carried out by qualified

personnel only.

◆The unit must be connected to an earthed (grounded) outlet to comply with

international safety standards.

◆Do not connect the unit to an A.C. outlet (power supply) without an earth

(ground) connection.

◆The appliance coupler (the connector to the unit and not the wall plug) must

have a configuration for mating with an EN 60320/IEC 320 appliance inlet.

◆The socket outlet must be near to the unit and easily accessible. You can

only remove power from the unit by disconnecting the power cord from the

outlet.

◆This unit operates under SELV (Safety Extra Low Voltage) conditions

according to IEC 60950. The conditions are only maintained if the

equipment to which it is connected also operates under SELV conditions.

France and Peru only

This unit cannot be powered from IT†supplies. If your supplies are of IT type,

this unit must be powered by 230 V (2P+T) via an isolation transformer ratio

1:1, with the secondary connection point labelled Neutral, connected directly to

earth (ground).

†Impédance à la terre

MPORTANT

Before making connections, make sure you have the correct cord

set. Check it (read the label on the cable) against the following:
