Smartparts SPDPF70E User manual
USER MANUAL
Digital Picture Frame
SP-DPF70E / SPDPF70EW
Warning：
Please turn off the power when inserting or removing a memory card to avoid
damaging the unit or the card.
Safety precaution
1) Use only the supplied 12V DC power adapter.
2) Turn off power before cleaning. Use only a soft cloth to clean the unit. Do not
use liquid cleaners.
3) Avoid exposing the unit to extreme heat.
Contents
Introduction................................................................................................... 1
Features.......................................................................................................... 1
Packaging Check List................................................................................... 2
Specifications................................................................................................. 2
Product Diagram........................................................................................... 3
Using Your Frame .........................................................................................5
Warranty………………………………………........................................... 7
Troubleshooting......................................................................................….. 8
Introduction
Your new digital picture frame lets you view digital pictures from memory
cards easily and quickly.
No computer or printer is needed.
Includes convenient slide show mode, which starts automatically when the
frame is turned on.
Supports many popular memory card types.
Easy to take with you to share photos with family and friends anywhere.
A step beyond the traditional photo frame. View tens or even hundreds of
digital photos without the need to pay for printing.
1. Features:
•7 inch TFT LCD screen
•Supports Secure Digital (SD), Multimedia Card (MMC) Memory Stick
(MS) and xD memory card formats
•View the pictures from memory cards directly
•Supports rotation of photos for proper display of vertical pictures.
•Resolution: 480x234 pixels
•Supports high resolution photos
•Automatic start of slide show
•Key holes for wall mounting
•Removable stand allows frame to be displayed vertically or horizontally
1
Introduction
2, Packaging Check List
* SPDPF70E or SPDPF70EW
Digital Picture Frame 1 piece
* Stand 1 piece
* User Manual 1 piece
* Power Adapter 1 piece
3,Specifications
Panel Size 7 inches
Resolution 480 x 234
Brightness 350 cd/m2
Contrast 300
Viewing Angle 60/60/50/40 (CR=10)
Response Time 30ms
Screen Size Mode 16 : 9
Picture Rotation 270 degrees
File Format Type JPEG
Max. Photo Size 10 megapixels
Power Requirement 12V DC
Power Consumption 6W
Operating Temperature -20~65 degrees centigrade
Storage Temperature -30~75 degrees centigrade
ProductDiagram
a. Top view
1. Play/Pause and On/Off
2. Previous
3. Next
4. Rotate
5. Mode
42 31 5
2 3
b. Side view
The removable stand can be connected to use your Digital Picture Frame vertically
or horizontally.
Using Your Digital Picture Frame
Install the stand for tabletop display, or mount to a wall. Connect theAC adapter.
Insert a memory card in the digital picture frame (with the card’s electrical contacts
toward the back of the unit). If the power is off, press the PLAY/PAUSE button
to turn the frame on. A slide show will begin automatically. To turn the
frame off, press and hold the PLAY/PAUSE button for about three seconds.
To pause the slide show, press the PLAY/PAUSE button briefly. The word
Pause will appear on the screen briefly, and the slide show will be stopped. The
current photo will remain on the screen until another button is pressed, at which
time the slide show will resume.
To display the next or previous picture, press the Next button or the Previous
button .
The speed of the slide show is automatic. Photos will remain on the screen for
about 5 to 20 seconds, depending on the size of the files. Larger files will take
longer to load.
The Rotate button allows photos to be turned for proper viewing.
2
3
1
1. Memory card slot
2. Power input jack
3. Stand
4 5
ViewingModes
The MODE button allows the user to adjust how the pictures are displayed on
the screen.
The modes function as follows:
NORMAL
This mode will cause your pictures to fit on the screen with no stretching or
cropping of the images. Photos with a typical 4:3 or 3:2 width-to-height ratio will
have black sections on the left and right sides of the screen.
CROP
This mode will cause your pictures to be enlarged to the full width of the screen,
without stretching them. As a result, the top and bottom of most pictures will not
be visible.
File Savin
g
:
Photos must be saved in the JPG format in order to be viewed on the digital picture
frame. Nearly all digital cameras will save in this format by default. Photos that
have been saved with certain image editing programs can fail to display properly.
Please refer to our web site (www.smartpartsproducts.com) for additional
information.
Warranty
Smartparts, Inc. warrants its products against defects in material and workmanship
for a period of 90 days from the date of purchase.
TechnicalNotes:
1. Your digital picture frame is a sophisticated electronic device. Do not drop or
subject the unit to jarring or strong vibrations.
2. Avoid placing the digital photo frame in areas of high humidity or where it
might be subjected to splashing.
4. The LCD panel is made of plastic and can be easily damaged. Avoid sharp
objects.
5. Use only a soft dry cloth to clean the screen
6 7
Questions / Troubleshooting Guide
1. Question: What kind of photos does this device support?
Answer: The frame will display digital photos that are stored in the JPEG
format, which is the standard format for nearly all digital cameras. Some
cameras allow images to be stored as TIFF or RAW files as well as JPEG.
Only the JPEG format is compatible with the frame. Photos of up to 10
million pixels can be displayed.
2. Question: What should I do if the system does not respond when the power
is turned on?
Answer: Please make sure the unit is properly connected to a power source.
Then turn it off, re-connect the power and turn it on again.
3. Question: Why is the memory card not recognized?
Answer: The memory card might be inserted backwards or is not pushed in
far enough. After inserting the memory card in the right direction, if the card
still cannot be read, please turn off the unit and then power it on again.
For additional support, please visit our web site at
www.smartpartsproducts.com.
8
