smart home SH - CT4R User manual
MODEL: SH - CT4R
by Bkav
www.smarthome.bkav.com
UGCT4R/V2.0/0615
893604393UGCT4R
Mfr Code:
Copyright © 2015 Bkav SmartHome Co., Ltd. All rights reserved.
Bkav SmartHome technology company limited
USER GUIDE
4-CHANNEL CONTROLLER
SH - CT4R
Electric shock may cause injuries or threats to life.
Before installing, repairing or cleaning the device,
you should check whether the device’s power is
disconnected.
This work should be done by technicians or
Customer Contact Center to avoid electric related
accidents.
Environmental regulations must be complied when
discarding or recycling the device or its wrapping.
Thank you for choosing 4-channel controller SH - CT4R
of Bkav SmartHome. By selecting Bkav SmartHome’s
products, you will get the best warranty service and
installation support from our technicians.
This document gives useful information during installation
and usage time. You should read and keep the manual
carefully in case of need.
1
Warning
Usage notice
Copyright © 2015 Bkav SmartHome Co., Ltd. All rights reserved.
4-channel controller SH - CT4R is the product of Bkav
SmartHome and has been registered regarding design,
utility solutions and quality certification. All violations such as
copies of design and product idea are subject to the current
copyright law of the Socialist Republic of Vietnam.
2
Usage notice
Safety instruction
Introduction
General introduction
Product package
Specifications
Wiring diagram
Installation instruction
Device usage
Function of direct control
Use remote control SH - RM6
Contact
1
4
5
5
6
7
8
9
12
13
13
16
3
Table of contents
Warning
Do not use voltage which is different from the one
stated in the device’s specifications.
Disconnect the device’s power prior to any
installation, disassembly or repair.
Do not leave the device in high-temperature
environment.
Do not disassemble the device if not necessary.
Do not clean the device with corrosive chemicals.
Safety instruction should be complied during the
device usage.
4Safety instruction
General introduction
Touch switch SH - CT4R supports turn-on/off of 4 power
channels and remote control SH - RM6 (*).
With the capacitive touch technology, anti-scratch Gorilla
Glass, remote control support, unibody aluminum, the device
will make your house more convenient and luxurious.
The device is designed to easily replace traditional switches
without making many changes of houses’ infrastructure.
The device is suitable to control lights, automatic curtains
and venetian blinds, etc.
(*) Remote control SH - RM6 is sold separately, not
included in the device. You can purchase to use.
5
Introduction
Product package
Touch-screen
control panel
Power circuit
box
Receptacle box
Remote control
SH - RM6
(additional purchase)
User guide
(book)
Signal connecting
cable and set
of screws
6
MODEL: SH - CT4R
by Bkav
SET
Specifications
Operating voltage:
Power rating:
100-240V 50/60Hz
97 x 93 x 8.6 mm
120 gram
5A max
Operating temperature:
Dimensions:
Weight:
60ºC max
