SMART-AVI HDX-ULT User manual

4K-ready PoE Cat5e/6

HDBaseT HD Extender

POE CAT5E/6 EXTENDER

FOR HDMI, RS-232, AND

IR CONTROL WATCH AND

COMMAND 1080P/4K HDTV

FROM 450 FT AWAY

Quick Start Guide

VIDEO

Format HDMI 1.3 and HDCP compliant

Input Interface (TX) (1) HDMI 19-pin (female)

Output Interface (RX) (1) HDMI 19-pin (female)

HDTV Resolutions 480p, 720p, 1080i,

1080p/60Hz/48bit, 4K/30Hz

Audio Format HDMI Digital Audio

Input Cable Length Up to 20 ft

Output Cable Length Up to 20 ft

Signal Type 38 KHz

Interface 3.5 mm Jack Socket (Female)

RS-232

Interface 3-pin terminal block

SYSTEM

Input Interface (TX) (1) RJ-45

Output Interface (RX) (1) RJ-45

OTHER

Power External 100-240 VAC/12V3A @30W

Dimensions 5”W x 1.125”H x 4.125”D

Weight 0.6 lbs

Approvals UL, CE, ROHS Compliant

Operating Temp. 32-104°F (0-40 °C)

Storage Temp. -4-140°F (-20-60 °C)

Humidity Up to 85% (non-condensing)

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

HDX-ULT

WHAT’S IN THE BOX

PART NO. Q-TY DESCRIPTION

HDX-ULT-TX 1 HDMI, IR, POE CAT5e/6

Transmitter

HDX-ULT-RX 1 HDMI, IR, POE CAT5e/6

Receiver

Power Supply 2 PS12V3A

Quick Start Guide 1

OVEVIEW

The HDX-Ultimate uses only one CAT5e cable to extend

4K HDMI signals hundreds of feet from their source. The

Ultimate’s HDBaseT technology is HDTV-ready and PoE,

ensuring peak performance even when transmitting

ultra-high quality picture resolution. The HDX-Ultimate is

a crucial extender for any system, and works in tandem with

SmartAVI matrixes for robust routing congurations. Control

and extend setups up to 300 ft per side, and 450 ft when

both are powered. Plus, with RS-232 and IR remote control,

taking command is convenient and easy every time!

Whether it’s for a home entertainment system or a

commercial installation, the HDX-Ultimate delivers exibility

and control. Don’t let the distance bring your system down:

let the HDX-Ultimate extend your reach today!

FEATURES

• Supports POE: Can be powered by TX or RX

• CAT6 extends signals over 450

• Powered over Ethernet (PoE)

• (1) HDMI output for HDTV support

• Supports 1080p/60fps and 4K/30Hz resoluon

• Up to 10.2 Gbps ultra-high bandwidth

• HDCP compliant; EDID learning

• Bi-direconal IR and RS-232 control

• LED status indicators

• Rack oponal

1. Turn off the computer, display, and speakers.

2. Connect the HDMI cable to your computer and to the HDX-Ultimate-TX.

3. Connect the display to the HDMI connector on the HDX-Ultimate-RX.

4. Connect the HDX-Ultimate TX and RX units via Cat5e/6 cable.

** Connect optional RS-232 devices to HDX-Ultimate-TX and HDX-Ultimate-RX. **

5. Connect the power cord and power on either the HDX-Ultimate-TX or the HDX-Ultimate-RX.

6. The connection and power indicator lights should illuminate.

7. Power on the computer, display, speakers and optional RS-232 devices.

HARDWARE INSTALLATION

HDX-ULT-TX FRONT

HDX-ULT-RX FRONT

HDX-ULT-TX BACK

HDX-ULT-RX BACK

HDMI IN

HDMI OUT

AUDIO IN

AUDIO OUT

RS232

CAT5/6

HDX-ULT-TX

450 ft

SmartAVI WEB

Controller

HDX-ULT-TX

SmartAVI WEB

Controller
