1.INDEX
2.Packing
Many thanks for choosing SR-230 beam moving head.
Thedesign&production are passed through the full quality
control to ensure the fineness ability.
This manual covers important information about install-
ation&operation of this projector.Please rsad this user manual
carefully before installing or operating this projector.Please do
follow the safety instruction.list as below carefully and keep this
manual in a safety place for future reference.
Note:As part of our ongoing commitment to continuos products
development,company will keep the right to improve this products,
the information in this menu may be changed in the future,the
company reserve the right to change the data without any advise.
2.1 The packing of the series of products is paper carton,the
flycase can order.
2.2 To open the carton
First please open the carton and take out the relative accessories,
Take out the projector from the polybad and put it on a very smooth
& horizontal surface place for the next operation.
Attention:Do not press the plastics parts to avoid any damage and
distortion.
2.3 Packing list
The following parts are packed
together with the projector:
Attachment
DMX cable 1pc
User manual 1pc
Moutnting Bracket 2pc
6.TECHNICAL PARAMETER
BULB: 7 R230W (8000 K color temperature, 2000 hours)
POWER CONSUMPTION: 230 V 50 HZ 380 VA
OPTICAL DEVICE: three lens group,0°-3°zoom
ELECTRONIC FOCUS: 20 meters, 50000 LUX
2 KINDS OF CHANNEL MODE: 16 international standard
DMX512 channel
LEVEL SCANNING: 540°(16 bit precision scan)
VERTICAL SCAN: 280°(16 bit precision scan)
COLOR WHEEL: 14 inserted color and white light with
two-way rotating and rainbow effect
ROTATING GOBO WHEEL: 17 inserted rotation gobos
and white circle with design jitter and arbitrary position
-ing function
2PRISM: 16 prisms with positive and negative rotation
and prism location function.
SHUT: Double pole shut up to 13 times per second,
random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
Electronic ballast : make the product more light and bright.
Lamp more stable environmental
protection and more energy saving
SWITCHING POWER SUPPLY : AC100 ~ 240 V, 50/60 HZ
FIXTURE DIMENSION: L430ЎW330ЎH510(mm)
PACKING DIMENSION: L460ЎW385ЎH565(mm)
NET WEIGHT: 16.5KG
GROSS WEIGHT: 19KG
