Singer QUANTUM STYLIST 9960 User manual

Feature Benefit

600 Built-in Stitch

Patterns provide more

than 1,000 Stitch

Functions

Fulfill your creative dreams with a large selection stitches including basic,

decorative and stretch stitches for clothing construction, quilting, home décor,

and crafting.

Alphanumeric Stitches Includes 4 standard fonts for letters and numbers

13 Fully Automatic

1-Step Buttonholes

Buttonhole sewing is a 1-step simple process providing reliable results every-

time. The sides of the buttonholes are sewn in the same direction to prevent

gaps in stitching or fabric distortion.

Exclusive Buttonhole

Underplate

Sandwiches fabric between lower plate and foot to ensure perfect buttonholes

on multiple layers of fabric.

Digital Information

Advisor

Stitch information including stitch pattern, length and width settings, and

recommended presser foot are displayed on the crystal clear LCD screen.

Programmable Needle

Up/Down

The needle can be programmed to stop in the highest position when your foot

is lifted from the controller, making it easier to remove fabric from the ma-

chine or program the needle to stop in the down position, which is ideal for

pivoting, appliquéing or quilting.

One-Touch Electronic

Automatic Thread Cutter

Press the thread cutter button and the machine automatically trims threads

when you are done sewing.

Electronic Auto Pilot Provides complete control over sewing speed for any project type.

Automatic Bobbin

Winding Clutch

Needle bar automatically disengages when winding the bobbin, making

bobbin winding safer.

Stitch Editing Capabilities Control the exact look of a stitch pattern with elongation and mirroring

capabilities.

Feature Benefit

7mm Stitch Width Most stitches can be set for a maximum width of 7mm creating attractive

satin and decorative stitches.

Slow Sewing Speed Option Allows you to sew at slower speeds for intricate work.

2 StayBright™ LED Lights Illuminates the work space and will last for 100,000 sewing hours.

Large Back-Lit LCD Screen

with Brightness Control

Provides clear and easy viewing of stitch functions including stitch width

and length, tension settings, and the recommended presser foot.

High Sewing Speed With a maximum sewing speed of 850 stitches-per-minute, projects can

be sewn quickly.

Extension Table Provides extra large sewing area for large projects including quilting.

Built-In Stretch Stitches Specially designed stitches that add strength and flexibility to seams,

especially useful when sewing on knitwear and super-stretch fabrics.

Adjustable Stitch Length Automatic settings for length can be overridden to personalize length

choice.

Adjustable Stitch Width Automatic settings for width can be overridden to personalize width

choice.

Feature Benefit

Six Second Threading

Threading the machine is so easy that you can have the entire

machine threaded, from the spool to the needle’s eye, in just six

seconds.

Automatic Locking

Stitch Function

Tie-off decorative and utility stitches with just a push of a button. This

feature ensures quality stitching and prevents unraveling.

Automatic Reverse Push the conveniently located Automatic Reverse Button to sew in

reverse and reinforce the stitch.

Horizontal Threading Allows for the thread to feed more evenly reducing poor stitch

formation and thread breakage.

Electronic Twin

Needle Control

Stitches are automatically adjusted for twin needle sewing with just the

touch of a button.

25 Needle Positions Needle position can be changed for individual projects like inserting

zippers or cording and topstitching.

Direct Button Stitch Selection Provides direct access to eight of the most popular stitches including

straight, zig-zag, blind hem and one buttonhole.

Error Warning An audible warning alerts the sewer if something is incorrect. The

audible warning can be deactivated, if desired.

Optimal Stitch Settings

Optimal settings for length and width are automatically set when

choosing a stitch. These settings can be overridden to personalize the

stitch pattern.

Stitch Reference Chart

This chart—located on the upper lid of the machine—allows you to

quickly choose the perfect stitch for your project – eliminating tedious

screen searching.

Mirror Imaging and

Elongation Function

With just a touch of a button select stitches can be mirror imaged,

adding even more stitch variety. Select the elongation button and a

variety of stitches can be made 2 to 5 times longer.

Feature Benefit

Automatic Tension

This system ensures stable stitch quality, whatever type of fabric is

being sewn. The tension can be adjusted using the tension adjustment

buttons, if desired.

Extra-High Presser Foot Lifter

The Presser Foot Lifter has two heights. The second offers more

clearance, which is needed when placing multiple layers of bulky fabric

under the presser foot.

Free Arm Provides easy access to cuffs, collars, pant hems and other difficult-to-

reach areas.

Box Feed The feed dogs move in a box motion ensuring perfect feeding through-

out the entire feed process.

Start/Stop Button

Unplug the foot control, press the Start button and the machine sews.

You are still in complete control over the speed - just slide the Speed

Limiting control to the desired speed.

Drop Feed Lower the feed dogs for free-motion embroidery, monograms and for

sewing buttons.

Warning Animation A picture appears on the LCD screen illustrating the probable error.

On Board Storage The accessories are conveniently stored in the removable sewing table,

providing easy access to accessories.

Snap-On Presser Feet Easily change snap-on presser feet without use of a screwdriver.

Optimum Power Control

A control system that senses when additional power is required to

maintain speed through thick or changing fabric conditions. This feature

is most useful when sewing through multiple (6-8) layers of fabric.

Heavy Duty Metal Frame

The internal skeleton of the sewing machine is constructed of heavy

duty metal. This rigid support holds all the mechanisms in perfect

alignment for skip-free sewing and overall durability.

Feature Benefit

DC Motor Provides instant start and stop with no coasting, for accurate and

precise stitch placement.

Automatic Needle Threader Makes threading the needle quick and painless.

Included Presser Feet

(Standard)

General Purpose (on the machine)

Zipper

Button Sewing

Satin Stitch

Buttonhole Foot and Underplate

Open Toe

Blind Hem

Overcasting

Narrow Hem

Cording

Straight Stitch/Quilting

Darning & Embroidery

Even Feed/Walking

Included Accessories

(Standard)

Extra Wide Extension Table

Needle Pack

4 Bobbins

Seam Ripper

Brush

Spool Pin with Felt Washer

Screwdriver (x2)

Spool Cap (x2)

Seam Guide

Quilting Bar

Value Added Accessories

NEW! Adjustable Bias Binder Foot

NEW! Single Welt Cording Foot

NEW! Braiding Guide

NEW! Braiding Foot

NEW! Clear Stitch-in-Ditch Foot

NEW! Fancy Trim Foot

NEW! Clearance Plate

Warranty Limited 25-year warranty including 5-year on electronic components

and 1-year on adjustments.
