Singer QUANTUM QUILTER 7350 Operation instructions

RIBBING APPLICATION

ELASTIC APPLICATION

NARROW CASING

BLINDHEM

BARTACK BUTTONHOLE

BUTTON SEWING-ATTACHING A BUTTON

COUCHING I

COUCHING II

SCALLOPED EDGE

BOBBIN WORK

SHELLEDGING

WING NEEDLE WORK

ROLLED AND WHIPPED EDGE

LACE INSERTION

TWIN NEEDLE PINTUCKS

FAGOTING

FAUX TATTED/CROCHETED EDGING

APPLIQUE WITH BLANKET STITCH

APPLIQUE WITH BLINDHEM STITCH

CRAZY QUILTING

CREATE TRIPLE STRAIGHT STITCH

BLANKET STITCH EDGING

NOTE: “QQ” will appear when the technique or

step applies only to the Quantum Quilter.

RIBBING APPLICATION

The Overedge Stretch Stitch joins and finishes stretch seams in one step.

This is ideal for applying ribbing in T-shirts and sweatshirts.

Machine Setup

Stitch: Overedge Stretch Stitch P

Presser Foot: Overcasting Foot E

Stitch Length: S

Stitch Width: 6 or 7

Needle: Yellow Band 90/14

Materials

Medium to heavy weight knit fabric - 6” x 6” square

Ribbing - 3” x 6”

Procedure

Cut a curve in the knit fabric to resemble a neckline.

Fold ribbing in half lengthwise.

Starting at the left side of the knit curve, place ribbing on front side of curve.

Match all 3 cut edges and place under the foot.

Line up fabric edges with quide on foot E and stitch the length of the seam.

Stretch ribbing slightly to fit the cut edge of the knit.

When finished, lift foot and pull threads and fabric straight back behind foot and

trim.

NOTE:

The overdege stretch stitch makes sewing seams in knits look as though

they were finished on a serger. This stitch is stronger and more

durable than overlock stitching.

ELASTIC APPLICATION

Using stitches with built-in stretch, elastic can be applied directly to the fabric

without having thread breakage when stretching the elastic.

Machine Setup

Stitch: Multi-Zigzag Stitch F (for sample)

Honeycomb Stitch F

Presser Foot: General Purpose Foot C

Stitch Length: 1.5

Stitch Width: 7

Needle: Yellow Band 90/14

Materials

Nylon Tricot 4” x 8”

3/8” wide elastic - 7” strip

Procedure

Position elastic on fabric, end of elastic extending slightly beyond side of fabric,

and keep elastic even with 5/8” seam line.

Hold elastic in front of and behind foot, and stretch slightly while sewing.

Trim top of fabric even with top edge of elastic.

Draw a line 5/8” away from top edge of tricot wrong side.

Position one end of elastic slightly off drawn line on tricot.

Lower presser foot and press needle up/down button to hold elastic in place

(QQ). [For 7350, manually lower needle into elastic.]

Start stitching and hold elastic separately while stitching down center of elastic,

pull slightly on elastic to create gathering.

Trim 5/8” edge flush with elastic edge.

NARROW CASING

Create a narrow casing for application of narrow ribbons, braids or elastic with the

Closed Zigzag Stitch, Zigzag Stitch, or Blanket Stitch.

Machine Setup

Stitch: Closed Zigzag Stitch E (for sample)

Zigzag Stitch (alternative)

Blanket Stitch (alternative)

Presser Foot: General Purpose Foot C

Stitch Length: S

Stitch Width: 5

Materials

Batiste or other medium to lightweight base fabric

1/8” wide ribbon

Procedure

Position ribbon end on right side of fabric.

Stitch over the ribbon using the Closed Zigzag Stitch, being careful that the

needle does not penetrate the ribbon on either edge.

Note:

Substitute narrow elastic for ribbon to make easy casings. Elastic can be easily

adjusted to fit area. Perfect for gathered areas on children’s clothes.

BLINDHEM

Provides a fast way to finish hems securely.

Machine Setup 1 (for raw edge finish)

Stitch: Zigzag Stitch B

Presser Foot: Overcast Foot E

Stitch Length: 1.0

Stitch Width: 5

Needle: Red Band 80/11

Machine Setup 2 (to baste the fold)

Stitch: Straight Stitch A

Presser Foot: General Purpose C

Stitch Length: 4

Stitch Width: 0 (Center Needle Position)

Tension Dial: 2

Machine Setup 3 (to create the hem)

Stitch: Blindhem Stitch C

Presser Foot: Blindhem Foot F

Stitch Length: 2.5-3.5

Stitch Width: 3.4

Tension Dial: 2

Materials

Medium weight linen or shirting-type fabric

60-80 weight thread

Procedure

Fold under 1” and baste in place.

Position sample with wrong side facing up, and turn the hem back to the right

side, creating a soft fold at the top edge of the hem. The bulk of the fabric is to

the left of the foot.

Begin stitching – making sure the forward stitches fall near the ¼” fold, and the

needle swing just bites into the fold, catching only 2 or 3 threads.

Note:

Use stitch D for hemming fabrics with light stretch.

BARTACK BUTTONHOLE

Provides a sturdy utilitarian buttonhole.

Machine Setup

Stitch: Buttonhole Stitch

Presser Foot: Buttonhole Foot

Stitch Length: 0-1 Buttonhole Symbol

Stitch Width: 5 (adjust to personal preference)

Materials

Shirting fabric

Button to establish length of buttonholes

Interfacing or tear-away stabilizer

Procedure

Place button in buttonhole foot to establish length.

Fold fabric in half crosswise, with interfacing between layers.

Place fabric under the foot in marked location.

Lower presser foot.

Lower Buttonhole Lever, and press toward back.

Begin sewing buttonhole.

Note:

Reset foot after each buttonhole by pushing the buttonhole lever toward

the back of the machine.

BUTTON SEWING - ATTACHING A 2 OR 4 HOLE BUTTON

Easily attaches buttons using the basic Zigzag Stitch.

Machine Setup

Stitch: Zigzag Stitch B

Presser Foot: Button Sewing Foot

Stitch Width: Determined by button (usually 3mm)

Feed Dogs: Down Position

Materials

Shirting

One 2-hole button

Procedure

Fold fabric in half and place under foot.

Position the button on the fabric so that the holes in the button are between the

toes of the foot.

Lower the presser foot to hold the button in place.

Turn the hand wheel towards front of machine and into the right or left hole.

Adjust the stitch width dial to fine tune the swing of the needle into the other

hole.

Recheck the swing of the needle into the other hole and then use foot control to

stitch 5-6 stitches.

Before removing the button and fabric from the machine, dial to straight stitch.

Leave width at current setting and stitch in place for three stitches. This forms a

tie-off on the back side to secure button.

Apply a liquid fray-preventer on the backside of fabric on the knots. Trim

threads after they dry, being careful not to cut thread knots.

Note:

- Remember to raise the feed dogs. Use the needle up/down button twice to

bring up feed dogs easily (QQ).

- You can also use the button sewing foot for attaching curtain rings, snaps and

hook and eye closures.

COUCHING I

Couching is the process of applying cords, pearls, braids, ribbons, or other trims

to the right side of the fabric.

Machine Setup

Stitch: Zigzag B or Decorative Stitch E

Presser Foot: General Purpose Foot C

Stitch Length: 3 or 4

Stitch Width: Adjust according to trim width

Material

Monofilament Thread

String Pearls

Felt or Stabilized Woven Fabric

Procedure

Lay pearls or other couching trim on top of fabric.

Stitch, adjusting width to ensure the stitch slightly encases trim.

COUCHING II

Machine Setup

Stitch: H

Presser Foot: General Purpose Foot C

Stitch Length: 4

Stitch Width: 7

Material

Felt or Stabilized Fabric

2 strands 1/8” wide ribbon (satin or grosgrain works best)

Decorative thread to coordinate or contrast with ribbon

Procedure

Lay ribbon, braid, or other trim on fabric.

Stitch ribbon in place, taking care to avoid piercing the trim with the needle.
