Singer 8770 CURVY Owner's manual

Feature Benefit

Electronic Sewing

Machine with Push-Button

Stitch Selection

With just a simple push of a button you have selected the stitch and the

optimum settings for length, width, balance, pressure and tension.

Exclusive

SwiftSmart™

Threading System Digital technology makes threading a cinch! Just guide the thread directly

from the spool to the needle area through a single groove and thread the

needle by simply pressing the threading lever for truly one-touch threading!

Exclusive

Drop & Sew™

Bobbin System

There’s no longer any need to raise the bobbin thread before sewing. Just

drop and sew!

3 StayBright™ LED Lights

Not just one but three lamps illuminate the sewing surface for optimal

viewing. The long-lasting bulbs (100,000 hours) stay cool regardless how

long the machine is operated.

225 Built-in Stitches

A large variety of stitches for clothing construction, quilting, heirloom, crafts,

home decorating and decorative sewing.

6 Fully Automatic

1-step Buttonholes

Buttonhole sewing is a one-step simple process, providing reliable results

every time. Each side of the buttonhole is sewn in the same direction,

creating beautifully balanced buttonholes.

3-Step Infinite

Length Bar-Tack

Buttonholes

There are no size limitations with this buttonhole. This is ideal when sewing

non-traditional sized buttonholes.

Exclusive

Buttonhole Underplate

This system sandwiches fabric between a lower plate and the foot to ensure

perfect buttonholes on multiple layers of fabric. It makes creating buttonholes

possible in places that conventional buttonhole devices cannot easily reach.

Built-In Alphanumeric

Stitches

Personalize projects by adding a monogram, name or phrase with the built-In

block style alphabet and numeric stitches.

Model 8770

Feature Benefit

LCD Screen The LCD provides clear and easy viewing of stitch patterns including

stitch width and length.

Built-In Stretch Stitches Specially designed stitches that add strength and flexibility to seams,

especially useful when sewing on knitwear and super-stretch fabrics.

Hand-Look Quilt Stitch

This stitch is designed to look like hand sewing for topstitching or

quilting. The Hand-Look Quilt Stitch is especially valuable to quilters,

crafters and heirloom seamstresses.

Adjustable Stitch Length Automatic settings for length can be overridden to personalize length

choice.

Adjustable Stitch Width Automatic settings for width can be overridden to personalize width

choice.

Center Zigzag Taper When tapering with the zigzag stitch, the stitch tapers to the center, not

the left or right. This provides a more attractive look when tapering into

or out from a point.

Automatic Tacking

Stitch Function

Tie-off decorative stitches with just a push of a button. With 4 tiny

tacking stitches the start and end of the pattern is reinforced. This

ensures quality stitching and prevents unraveling.

Automatic Tie-Off Function This function reinforces the start and end of seams for stronger

stitching.

Automatic Reverse

Push the conveniently located Automatic Reverse Button to sew in

reverse and reinforce the stitch.

7mm Stitch Width

Many stitches can be set for a maximum width of 7mm for satin and

decorative stitches.

Programmable Needle

Up and Down Select whether the needle is up or down when the machine stops. It’s

beneficial to have the needle stop in the down position when

appliquéing, quilting or pivoting fabric.

Feature Benefit

Electronic Twin Needle Control Stitches are automatically adjusted for twin needle sewing with just the

touch of a button.

13 Needle Positions Needle position can be changed for individual projects like inserting

zippers, cording and topstitching.

20-Space Memory A memory bank holds full names and simple phrases.

Editing Capabilities Easily edit monograms or phrases using the built-in alphabet.

Mirror Image

Stitches can be mirror imaged with just a touch of a button.

Continuous Pattern

Individual stitches can be sewn together as a pattern with just a touch

of the button.

Error Messaging

4 audible and visual warning messages alert the sewer making for

trouble-free sewing.

Pattern Override Memory Select a pattern, override the width and/or length and the machine will

remember those changes for future use.

Sewing Speed With a maximum sewing speed of 750 stitches-per-minute, projects

can be sewn quickly.

Automatic Tension This system ensures stable stitch quality, whatever type of fabric is

being used.

Automatic Presser Foot

Pressure Control The amount of pressure exerted on the fabric by the presser foot

against the feed dogs is automatic. Sew from the lightest weight tricots

to the heaviest denim, without making presser foot adjustments.

Extra-High Presser Foot Lifter Offers more clearance, which is needed when placing multiple layers

of bulky fabric under the presser foot.

Free Arm Provides professional results and easy access to cuffs, collars, pant

hems and other difficult-to-reach areas.

Feature Benefit

Top Loading Jam-Proof

Bobbin System with Clear Cover

This mechanism incorporates a magnet-type vertical axis rotating hook

that ensures smooth, quiet, thread jam-resistant sewing. The bobbin

case floats above the hook, precluding thread jams.

Automatic Bobbin Winding Clutch Needle bar automatically disengages when winding the bobbin, making

bobbin winding safer.

6-Segment Feeding System

This is a specially designed feed dog that ensures the fabric is picked

up and supported from the front of the presser foot to the rear. This

makes for much more accurate fabric feeding.

Box Feed

This is a feed dog motion that moves the feed dogs in a box motion,

rather than the historic arc motion. Box motion assures perfect feeding

throughout the entire feed process, as the feed dogs are always in

perfect and equal contact with the fabric and presser foot.

Drop Feed

A conveniently located lever, easily and effortlessly moved, will lower

the feed dogs for free-motion embroidery, monograms and for sewing

buttons.

Heavy Duty Metal Frame

The internal skeleton of the sewing machine. This rigid support holds all

the mechanisms in perfect alignment for perfect, skip-free sewing.

Direct Drive The needle bar is geared straight from the motor, rather than from a

drive bar across the machine. This makes the machine more powerful

and durable.

On Board Storage Have easy access to accessories while sewing.

Snap-On Presser Feet Easily change presser feet without a screwdriver.

Thread Cutter Located on the machine for precise thread cutting, eliminating the extra

step of cutting thread with scissors.

Feature Benefit

Optimum Power Control

A control system that senses when additional power is required to

maintain speed through thick or changing fabric conditions. This feature

is most useful when sewing through multiple (6-8) layers of fabric.

DC Motor Provides instant start up and stop with no casting, for accurate and

precise stitch placement.

Electronic Foot Controller Guarantees consistent sewing speed with no jump starts.

Dust Cover Keeps the sewing machine free of dust and debris while not in use.

Accessories

Auxiliary Spool Pin

General Purpose Foot (on machine)

Satin Special Purpose Foot

Zipper Foot

Blind Hem Foot

Small, Medium and Large Thread Spool Caps (3)

Screwdriver for Needle Plate

Buttonhole Foot with Exclusive Underplate

4 Standard Bobbins

Needles, Lint Brush and Seam Ripper

Portable and

Cabinet Mountable Machine has a built-in carry handle, making it easy to transport the

machine. Machine can be mounted into a cabinet.

Warranty Limited 25-year warranty, including 5 years on electronic components

and 1 year on adjustments.

SINGER®, Curvy™and SwiftSmart™are exclusive trademarks of The Singer Company Limited or its affiliates.
