Simplicity 4564 Setup guide

Attachment

Illustrated

Parts List

Rev. 04/2007

500 N. Spring Street / PO Box 997

Port Washington, WI 53074-0997 USA

www.simplicitymfg.com

MANUFACTURING, INC.

. No. Descri

tion

Attachment

1694693 Catcher, Turbo Clean Sweep Twin

1734848

Part No.:

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Cover & Bag Group - Twin ................................................................................................................................... 4

Hitch Group .......................................................................................................................................................... 6

Tube Group .......................................................................................................................................................... 8

Cover & Bag Group - Twin

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

983952

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

Cover & Bag Group - Twin

Footnotes

TUBE ASSEMBLY Support (Incl. Ref. Nos. 2, 3, 4, 5, 6, 8, 9 & 11)1 1704615SM 1

RIVET, Pop2 1960381SM 7

SUPPORT, Tube3 1704075SM 1

SEAL, Cover4 1704135SM 1

BRACKET, Seal5 1704508SM 3

SCREW, Round Head, #8-32 x 7/86 1960399SM 1

LOCKNUT, Flange, 1/4-207 1930642SM 5

WASHER8 1960096SM 2

STRAP, Tube Support9 1704507SM 1

SCREW, Taptite, 1/4-20 x 3/810 1929000SM 2

NUT, Hex, Lock, #8-3211 1960077SM 2

CARRIAGE BOLT, 1/4-20 x 5/812 1960252SM 5

CROSS ASSEMBLY13 1727129ASM 1

CAPSCREW, Hex Head, 3/8-16 x 7/814 1921966SM 4

NUT, Hex, Whizlock, 3/8-1615 1928352SM 4

CLIP, Hairpin16 1960221SM 2

SCREEN17 1703700SM 1

NUT, Hex, 5/16-1818 1917372SM 4

LOCKWASHER, 5/1619 1917356SM 4

CLAMP20 1672023ASM 2

HANGER21 1703807ASM 2

CARRIAGE BOLT, 5/16-18 x 3/422 1931333SM 4

HOOP, Bag23 1703855ASM 2

BAG, Grass24 1703764SM 2

TUBE CLIP, Grass Bag25 1675707SM 2

SEAL, Clip26 1704057SM 1

SCREW, Truss Head, #10-32 x 1/227 1930531SM 2

RIVET, Pop28 1675043SM 4

HANDLE, Latch29 1703853SM 1

NUT, Hex, #10-3230 1928919SM 2

PIN, Round Head31 2860367SM 2

WASHER32 1910531SM 4

CLIP, Canoe33 1667248SM 6

DECAL, Safety34 1732820SM 1

COVER35 1704056SM 1

WINDOW36 1704180SM 2

NUT, Speed37 1933886SM 1

CABLE, Double Loop38 1705876SM 1

WASHER, 1/439 1921319SM 1

SCREW, Self-tapping, #10-12 x 5/840 1960400SM 1

COVER ASSEMBLY (Incl. Ref. Nos. 17, 26, 28, 32, 37, 38, 39 & 40)41 1704056SM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA

Hitch Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986032

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

Hitch Group

Footnotes

CAPSCREW, Hex Head, 1/2-13 x 2-1/21 1960462SM 4

WASHER2 1924361SM 4

SPACER3 1668662SM 4

LOCKNUT, Hex, 1/2-134 1960355SM 4

NUT, Hex, 3/8-165 1916950SM 6

LOCKWASHER, 3/86 1916965SM 6

SUPPORT, Upright7 1707526ASM 1

CAPSCREW, Hex Head, 3/8-16 x 18 1921210SM 6

BRACKET, Lower Hitch9 1703744ASM 1

SUPPORT, Side Hitch10 1723067ASM 2

CAPSCREW, Hex Head, 3/8-16 x 1-1/411 1920415SM 6

PLATE, Side12 1723044ASM 2

CLIP, Hair Pin13 1960033SM 2

CARRIAGE BOLT, 3/8-16 x 3/414 1931348SM 4

CLAMP, Hitch15 1723065SM 1

CLAMP, Plate16 1723064ASM 1

NUT, Hex, 5/16-1817 1917372SM 2

LOCKWASHER18 1917356SM 2

PIN, Round Head, Drilled19 1729281SM 2

SPACER20 1960236SM 2

CARRIAGE BOLT, 5/16-18 x 1-1/421 1960223SM 2

SUPPORT, Upright22 1707526ASM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA

Tube Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

T986032

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

Tube Group

Footnotes

NUT, Hex Nylock, #10-321 1933896SM 2

WASHER2 1960096SM 6

ELBOW, Upper4 1704283SM 1

SCREW, Truss Head, #10-32 x 1/25 1960404SM 2

RIVET6 2810542SM 2

CLIP, Spring7 1705063SM 1

TUBE & SPRING ASSEMBLY (Incl. Ref. Nos. 2, 6, & 7)8 1707712SM 1

CARRIAGE BOLT, 1/4-20 x 5/89 1960252SM 1

NUT, Hex Flange Lock, 1/4-2010 1930641SM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694693 - Catcher

TP 400-4564-00-AT-SMA
