Simplicity 4535 Setup guide

Attachment

Illustrated

Parts List

Rev. 04/2007

500 N. Spring Street / PO Box 997

Port Washington, WI 53074-0997 USA

www.simplicitymfg.com

MANUFACTURING, INC.

. No. Descri

tion

Attachment

1695163 Catcher, Clean Sweep Twin, 38"

1734814

Part No.:

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Twin Catcher Assembly ....................................................................................................................................... 4

Twin Catcher Assembly

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

1695163

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695163 - Catcher

TP 400-4535-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

Twin Catcher Assembly

Footnotes

COVER ASSEMBLY, with Decal1 1732815SM 1

SCREW, 10 - 24 x 3/42 1960404SM 8

LATCH3 1733416ASM 1

NUT, 10 - 24, ESNA Lock4 1933896SM 8

EDGING, 13-1/8 Long5 1700864SM 2

BAG ASSEMBLY, Twin6 1732350SM 2

CAP7 024862MA 3

TUBE, "U"8 1733440SM 1

TUBE, Center9 054412E701MA 1

SCREW, 5/16 - 24, Curve10 006x93MA 2

LOCKWASHER, 5/1611 1917356SM 2

NUT, 5/16 - 24, Hex12 1920263SM 2

NUT, 1/4 - 20, Keps Lock13 1928372SM 4

SCREW, 1/4 - 20 x 1/214 004x26MA 5

PIN, Cover Hinge15 054407ZMA 1

HINGE, Cover16 054398E701MA 1

PIN, Hair17 1960074SM 1

CHANNEL ASSEMBLY18 1732867SM 1

PIN, Channel Mount19 1732565SM 1

MOUNT ASSEMBLY, Channel20 1732067ASM 1

PIN, Hair, 1/8 x 2-9/1621 1960033SM 1

BOLT, Shoulder, 5/16 - 1822 1728976SM 2

NUT, 5/16 - 18, Speed23 1960717SM 2

WASHER24 1960185SM 1

LATCH, Wire Form25 1704603SM 1

TUBE, Discharge26 1703769SM 1

SCREW, 5/16 - 18 x 3/427 1960122SM 1

WASHER28 1919326SM 1

SEAL, Rubber29 1732799SM 1

PLATE, Seal30 1732735ASM 1

BOLT, Carriage, 5/16 - 18 x 3/431 1931333SM 1

BOOT, 38"32 1732561SM 1

SCREW, 5/16 - 18 x 3/433 1960371SM 3

WASHER, Special34 1704341SM 1

NUT, 5/16 - 18, Centerlock Flange35 1935048SM 5

BRACKET, Boot Mount36 1704355ASM 1

BOLT, Carriage, 5/16 - 18 x 237 1931339SM 3

WINGNUT ASSEMBLY38 1733689SM 1

NUT, Whizlock, 5/16 - 1839 1927557SM 4

SPACER40 1674669SM 2

BAFFLE, 38"41 1703765ASM 1

BLADE, 38" Hi-Lift42 1704977SM 1

BOLT, Carriage, 5/16 - 18 x 1-3/443 1931338SM 5

NUT, 5/16 - 18 ESNA44 1960686SM 6

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695163 - Catcher

TP 400-4535-00-AT-SMA

Twin Catcher Assembly

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

1695163

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695163 - Catcher

TP 400-4535-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

Twin Catcher Assembly

Footnotes

BRACE STIFFENER48 1733432ASM 1

CAPSCREW, 5/16 - 18 x 3/449 1930591SM 1

DECAL, Cover Warning52 1732819SM 1

RIVET, Pop, 3/1653 1673320SM 18

WASHER, Rivet, 3/1654 1910531SM 12

SCREEN, Twin Cover55 1732488SM 1

FASTENERS, Push, 1/4 x 1/256 1732490SM 6

SCREEN SUPPORT, Twin57 1734384SM 1

INSTRUCTION MANUAL58 1733419 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695163 - Catcher

TP 400-4535-00-AT-SMA
