Simplex IDNet 4010 User manual

Features

Individual addressable manual fire alarm

callpoints with:

•Power and data supplied via IDNet addressable

communications using a single wire pair

•Enhanced aesthetics

•Designed for fast and easy installation

•Designed for EMI compatibility

•Surface or flush mounting options

•Test key allows the callpoint to be tested without

breaking the glass

•Requires a special key to open the callpoint

Compatible with Simplex Model series

4010 and 4100U

Description

These addressable manual callpoints, with compact

communications module, are easily installed to satisfy

demanding applications. An integral individual

addressable module (IAM) monitors status and

communicates changes to the connected control panel via

IDNet communications.

Specifications

Power and

Communications IDNet, 1 address per callpoint

Address Means DIPswitch, 8 position

Device Type KACPUL

Wire Connections Spade terminals

Storage and Operating

Temperature Range 14°F to 131°F (-10° C to 55° C)

Humidity Range Up to 95% RH non-condensing

Ingress Protection IP24D

Color Red, RAL3001

Material PC/ABS

Dimensions 3-5/8” H x 3-1/2” W x 1-1/16” D

(93 mm x 89 mm x 28 mm)

Operation

– This product is not presently agency listed. Contact your local Simplex product supplier for

the latest status.

IDNet Addressable Manual Callpoint

Operation

Activation of the Simplex callpoint requires the glass

element to be broken. Completing the action operates a

micro-switch whose condition is signaled back to the

control panel.

Callpoint reset requires the use of a special key

(supplied with the callpoint) to remove the front cover

which allows the glass element to be replaced.

Callpoint testing is performed by inserting the key

fully into the bottom of the housing and pulling down,

this releases the bottom of the housing and break glass

element. To reset the callpoint, the bottom of the housing

is pushed upwards until it locks in position. (See

illustration below.)

Callpoint Testing

IDNet™ I/O Devices

IDNet Communicating Devices,

Internal Addressable Manual Callpoint

A0001-0006-3 3/2009

Application Reference

Refer to NFPA 72, the National Fire Alarm Code, and all

applicable local codes for complete requirements for

manual callpoints. The following summarizes the basic

requirements:

1. Callpoints shall be located in the normal path of exit

and distributed in the protected area such that they

are unobstructed and readily accessible.

2. Mounting shall be with the operable part not less than

3-1/2 ft (1.1 m) and not more than 4-1/2 ft (1.37 m)

above floor level.

3. At least one callpoint shall be provided on each floor.

Additional callpoints shall be provided to obtain a

travel distance not more than 200 ft (61m) to the

nearest callpoint from any part of the building.

4. When manual callpoint coverage appears limited in

any way, additional callpoints should be installed.

2 A0001-0006-3 3/2009

Addressable Manual Callpoints with Internal IAM

Model Description

4099-9701 English callpoint with LED

4099-9702 English callpoint, no LED

4099-9703 English/Arabic callpoint with LED

4099-9704 English/Hebrew callpoint with LED

CN4099-9032 Chinese callpoint with LED

Accessories

Model Description

515.001.021 Surface mount backbox for Simplex internal callpoints, 32 mm deep, 1-1/4”

4099-9706 Callpoint replacement glass, package of 10

Note: The callpoint fits directly to a UK switch/socket

box. A minimum box depth of 25 mm is recommended.

515.001.021 PC/ABS Backbox for surface mounting

Product Selection

Mounting Information

3 A0001-0006-3 3/2009

Setting the Callpoint Address

Replacing the Break Glass Element

Tyco is a registered trademark of Tyco International Services GmbH and is used under license. Simplex, the Simplex logo, and IDNet are trademarks of Tyco International Ltd.

and its affiliates and are used under license. NFPA 72 and National Fire Alarm Code are trademarks of the National Fire Protection Association (NFPA).
