Sima SL-10L User manual
To replace the batteries:
1. Make sure that the power
switch is in the OFF position.
2. Press in on both sides of the
SL-10L case as illustrated by
the two arrows in Fig. C to
release the internal tabs. The
tab can be seen in Fig. D.
3. Pull the case apart gently.
Note: The case is still joined
at the bottom.
4. To separate the bottom, work
the case back and forth until
it is freed from the shoe
mount.
5. Replace the batteries.
6. Snap the case back together.
Fig. C
Fig. D
90 Day Limited Warranty
Sima Products warrants this product against
defects in materials and workmanship for a period
of 90 days from the date of retail purchase. During
the warranty period, the product will be repaired or
replaced, at Sima’s option. You can register your
product online at www.simacorp.com
Conditions
Ship your unit, freight pre-paid, including
reasonable proof of date and place of purchase
and description of problem to:
Attn: Customer Service
c/o Sima Products
Bldg. #5
140 Pennsylvania Ave.
Oakmont, PA 15139
This warranty is void if any defects are caused by abuse,
misuse, negligence or unauthorized repairs. All liability for
incidental or consequential damages is specifically
excluded. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This
warranty gives you specific legal right and you may also
have other rights which vary from state to state.
LED
Video Light for Digital
Cameras & Camcorders
Powerful White LED Technology
Model SL-10L
Register online at www.simacorp.com
Fig. A
Introduction
The Sima LED Universal Video Light
Model SL-10L can be mounted on the
accessory shoe of any camcorder by
sliding it into place and tightening the
mounting screw. If your camcorder
does not have a shoe mount, the Sima
Video Bracket, (Model SVB-1) can
provide a mounting platform.
Batteries:
The SL-10L comes with two
rechargeable AAA NiMH batteries. The
batteries come pre-installed from the
manufacturer. Prior to use, the
batteries must be charged 8 to 10 hrs.
Use the supplied AC adapter/charger
to charge the batteries.
Note: Because of the long
lifetime of NiMH batteries, they
should not need to be replaced. In
case of replacement please refer
to (Fig.C) & (Fig.D).
To charge the batteries:
1. Insert the jack on the power cord into the
power input jack on the side of the SL-10L
(Fig. A). Red LED indicator light, located
below the power jack, will turn on.
2. Plug AC transformer into standard 120 VAC
wall outlet.
3. Batteries must
charge 8 to 10
hours before
fully charged.
Note: indicator
light will not turn
off when
charging is
complete.
4. Fully charged
batteries will provide approx. 60 to 90
minutes continuous run time.
Note: Light does not work with AC adapter
plugged in unit’s power jack.
Warning! Do not overcharge. Unplug after 8-
10 hours charging.
Special Notes:
The SL-10L video light can also be operated
with two standard AAA alkaline batteries.
Running time will be less than when using the
rechargeable NiMH batteries included with
your unit. If using non-rechargeable
batteries, do not use AC charger. Supplying
current to non-rechargeable batteries can
cause them to leak or explode and may
damage the unit.
Warning! Never charge alkaline batteries.
Damage to AC charger or light can occur.
Operation:
Turn light on by sliding
the on/off switch up to
the ON position as shown
in Fig. B
Fig. B
Specifications:
LEDs: ~6000K Color Balanced
Power: 2 AAA NiMH batteries
Run Time: 60 to 90 Minutes
depending on battery usage.
Battery Type: 600 mA hour NiMH
Charger: 120V AC input; 3V DC
output
Weight: 1.9oz (with batteries).
Size: 2.35” x 1.5” x 1”
© 2005/2006 Sima Products Corporation
P/N 21736 Made in China
