Silvercrest SHAZ 22.2 B2 User manual

IAN 285615

CORDLESS HAND-HELD &

UPRIGHT VACUUM CLEANER SHAZ 22.2 B2

CORDLESS HAND-HELD &

UPRIGHT VACUUM CLEANER

Operating instructions

AKKU-HAND- UND

-BODENSTAUBSAUGER

Bedienungsanleitung

GB/IE/NI Operating instructions Page 1

DE/AT/CH Bedienungsanleitung Seite 17

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of

the device.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

r e

tzui

o p as

GB│IE│NI │ 1■

SHAZ 22.2 B2

Contents

Introduction ...................................................2

Intended use ..................................................2

Package contents ..............................................2

Appliance description ...........................................3

Technical data .................................................4

Important safety instructions.....................................4

Before ﬁrst use ................................................8

Fitting the wall bracket..........................................8

Charging the batteries ..........................................9

Attaching/removing accessories .................................10

Floor nozzle............................................................10

Large round brush/upholstery nozzle ........................................10

Small round brush ....................................................... 10

Crevice tool ............................................................ 10

Operation ...................................................11

ECO mode............................................................. 11

Cleaning.....................................................11

Emptying the dirt container and cleaning the ﬁlter ..............................11

Cleaning the ﬂoor brush .................................................. 12

Cleaning the appliance ...................................................13

Troubleshooting ..............................................13

Disposal .....................................................14

Disposal of the appliance .................................................14

Disposal of the packaging.................................................14

Kompernass Handels GmbH warranty............................15

Service................................................................ 16

Importer ............................................................... 16

■ 2 │ GB│IE│NI SHAZ 22.2 B2

Introduction

Congratulations on the purchase of your new appliance.

You have selected a high-quality product. The operating instructions are part

of this product. They contain important information about safety, usage and

disposal. Before using the product, please familiarise yourself with all operating

and safety instructions. Use the product only as described and for the range of

applications speciﬁed. Please also pass these operating instructions on to any

future owner.

Intended use

This appliance has been designed exclusively for vacuum cleaning dry surfaces

and dry residues in interior rooms. Do not vacuum people or animals with this

appliance. Any other usage or modiﬁcation of the appliance is deemed to be

improper and carries a signiﬁcant risk of accidents. The manufacturer accepts

no liability for damages that result from improper use of the appliance or are

caused by the incorrect operation of it. The appliance is not intended for

commercial use.

Package contents

The appliance is supplied with the following components as standard:

▯ Li-ion cordless handheld vacuum cleaner

▯ Floor brush, electric

▯ Large round brush (upholstery nozzle)

▯ Small round brush

▯ Crevice tool

▯ Suction pipe

▯ Wall bracket, including charger

▯ Assembly material (2 screws, 2 wall plugs) for wall bracket

▯ Mains adapter

▯ Operating instructions

NOTE

► Check the package for completeness and signs of visible damage.

► If the delivery is incomplete or damage has occurred as a result of

defective packaging or during transport, contact the Service hotline

(see section Service).

GB│IE│NI │ 3■

SHAZ 22.2 B2

Appliance description

1Connection for mains adapter (hand element)

2"ECO" button

3Indicator lamp (battery charge indicator)

4Hand element

5 Release button "PUSH" hand element

6 Suction pipe

7Release button "PUSH" suction pipe

8Floor nozzle

9Release switch ﬂoor nozzle

0 Floor brush

qOn/Oﬀ switch

wDust ﬁlter hand element

eDirt container lid

rRelease button "PUSH" dirt container

tDirt container

zFilter holder

uRelease button "MOVE"

iHEPA ﬁlter

oConnection for mains adapter, wall bracket

pSmall round brush

aLarge round brush (upholstery nozzle)

sCrevice tool

dAccessories holder for wall bracket

fWall bracket

gMains adapter

hBarrel plug

■ 4 │ GB│IE│NI SHAZ 22.2 B2

Technical data

Mains adapter g

Input voltage/current 100–240 V ~ (AC), 50/60 Hz, max. 0.8 A

Output voltage/current: 26.5 V (DC), 750 mA

Protection class II/ (double insulation)

Eﬃciency class 5

Protection type

IP 20: Protected against ingress of solid

foreign objects with a diameter of

≥ 12.5 mm.

Polarity (positive inside, negative outside)

Type designation ZD024D265075BS

Appliance

Input voltage/current 26.5 V (DC), 750 mA

Polarity (positive inside,

negative outside)

Batteries

Capacity 2500 mAh

Rechargeable battery 22.2 V (DC) (6 x 3.7 V lithium-ion

battery)

Important safety instructions

DANGER – ELECTRIC SHOCK!

► Do not charge or use the appliance outdoors or in damp

rooms.

► Never use the appliance if the cable, plug or casing are

damaged.

► To avoid risks, arrange to have damaged mains adapters

and/or plugs replaced as soon as possible by a qualiﬁed

specialist.

► Have all repairs carried out by a specialist workshop. Under

no circumstances should you open the appliance yourself.

Repairs that are not carried out by a specialist workshop

could lead to physical injuries.

GB│IE│NI │ 5■

SHAZ 22.2 B2

DANGER – ELECTRIC SHOCK!

► Before switching on the appliance, make sure that the mains

voltage corresponds to the voltage indicated in the technical

data for the appliance.

► Never touch the mains adapter or the appliance with wet or

damp hands.

► Protect the appliance from moisture and liquids.

► Do not use the mains adapter with an extension cable;

connect the mains adapter directly to a power socket.

WARNING! RISK OF INJURY!

► Always switch oﬀ the appliance and pull the mains adapter

out of the power socket before emptying the dirt container,

cleaning the nozzles or changing attachments.

► Do not use the appliance for vacuuming up sharp objects

or broken glass.

► Do not use the appliance for vacuuming up liquids.

► Do not use the appliance for vacuuming up burning matches,

glowing embers or cigarette butts.

► Do not use the appliance for vacuuming up chemical

products, stone dust, gypsum, cement or similar particles.

► This appliance is not suitable for use with inﬂammable and

explosive substances or chemical and aggressive liquids.

► Always store the appliance indoors. To prevent accidents,

keep the appliance in a dry location when not in use.

► Under extreme conditions, the battery cells may leak.

In the event that battery ﬂuid comes into contact with skin

or eyes, the aﬀected area must be rinsed oﬀ with water

immediately. Contact a physician.

■ 6 │ GB│IE│NI SHAZ 22.2 B2

WARNING! RISK OF INJURY!

► This appliance may be used by children aged 8 years and

above and by persons with limited physical, sensory or

mental capabilities or lack of experience and knowledge,

provided that they are under supervision or have been told

how to use the appliance safely and are aware of the

potential risks.

► Do not allow children to use the appliance as a toy.

► Cleaning and user maintenance tasks may not be carried

out by children unless they are supervised.

► Take special care when using the appliance on the stairs.

► Never hold the nozzles near body parts or animals during

use and never insert your ﬁngers in the nozzles. You could

be injured or become stuck. Switch the appliance oﬀ imme-

diately if the appliance sucks onto any body part or object.

► Keep your hair, loose clothing, ﬁngers and other body parts

away from the suction opening or the moving parts, e.g. the

rotating ﬂoor brush.

► Do not use any fragrances or perfumed products on the

ﬁlters in this appliance. The chemicals contained in these

products have been demonstrated to be inﬂammable and

can cause a ﬁre in the appliance.

CAUTION! PROPERTY DAMAGE!

► Use only accessories recommended by the manufacturer.

► The mains adapter may not be used for other purposes.

Never carry the wall bracket or the mains adapter by the cable.

► Always pull directly on the mains adapter itself (not the cable)

to disconnect the appliance from the power supply.

► Do not place the appliance next to radiators, ovens or other

heated devices or surfaces.

GB│IE│NI │ 7■

SHAZ 22.2 B2

CAUTION! PROPERTY DAMAGE!

► Make sure that the ventilation slits are never obstructed.

A blocked ventilation circuit can result in overheating and

damage to the appliance.

► This appliance contains rechargeable batteries. Do not

throw the batteries into a ﬁre and do not subject them to

high temperatures. There is a risk of an explosion.

► Do not use the appliance without the ﬁlter inserted.

► Do not use the mains adapter for a diﬀerent product and do

not attempt to charge this appliance with a diﬀerent charger.

Use only the mains adapter supplied with this appliance.

► The batteries in this appliance cannot be removed and

replaced.

► Do not vacuum over any cables, fringed materials, etc. as

these can get caught up in the rotating ﬂoor brush and be

damaged.
