Silvercrest 384214-2107 User manual
WET & DRY HAND-HELD VACUUM CLEANER
SAS 7.4 LI C2
HANDSTAUBSAUGER
NASS UND TROCKEN
Bedienungsanleitung
IAN 384214_2107
WET & DRY HAND-HELD
VACUUM CLEANER
Operating instructions
ΣΚΟΥΠΆΚΙ ΧΕΙΡΟΣ
ΥΓΡΏΝ/ΣΤΕΡΕΏΝ
Οδηүίες χρήσης
GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 15
DE/AT/CH Bedienungsanleitung Seite 31
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
4
2
q
0
8
7
6
5
3
9
1
GB│IE│NI│CY │ 1 ■
SAS 7.4 LI C2
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................3
Important safety instructions.....................................5
Prior to first use................................................7
Information about the batteries ..................................7
Installation of the wall bracket ...................................8
Charging .....................................................9
Operation ....................................................9
Cleaning.....................................................11
Disposal .....................................................12
Kompernass Handels GmbH warranty............................13
Service................................................................ 14
Importer ............................................................... 14
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 1IB_384214_SAS7.4LIC2_GB-IE-CY.indb 1 14.10.2021 13:48:2614.10.2021 13:48:26
■ 2 │ GB│IE│NI│CY SAS 7.4 LI C2
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of this
product. They contain important information on safety, usage and disposal. Before
using the product, familiarise yourself with all operating and safety instructions. Use
the product only as described and for the specified areas of application. Please also
pass on these operating instructions to any future owner.
Intended use
This handheld vacuum cleaner may only be used to vacuum dry or wet surfaces,
or dry or wet materials and liquids. Do not vacuum people or animals with this
appliance. Any other usage of or modification to the appliance is deemed to be
improper and carries a significant risk of accidents. The manufacturer accepts no
liability for damages that result from improper use of the appliance or are caused
by the incorrect operation of it. The appliance is not intended for commercial use.
Package contents
▯ Wet & dry hand-held vacuum cleaner
▯ Crevice tool
▯ Wet suction nozzle
▯ Wall bracket
▯ Mounting kit
▯ Mains adapter
▯ Operating instructions
Check the package contents for completeness directly after unpacking.
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 2IB_384214_SAS7.4LIC2_GB-IE-CY.indb 2 14.10.2021 13:48:2614.10.2021 13:48:26
GB│IE│NI│CY │ 3 ■
SAS 7.4 LI C2
Description of the appliance
1Wet suction nozzle
2Crevice nozzle
3Wall bracket
4Mains adapter
5Barrel plug
6On/off switch
7Charge indicator lamp (red/green)
8Release button
9Dust filter bag
0Dust filter
qDirt container
NOTE
► This appliance is supplied with non-charged batteries. The batteries must be
charged before first use.
Technical data
Appliance
Input voltage/current 9.6 V (DC) / 0.5 A
Polarity
(positive inside, negative outside)
Rechargeable batteries
Capacity 2000 mAh
Rechargeable battery 7.4 V (DC)
(2 x 3.7 V Lithium-ion rechargeable batteries)
Battery charging time Approx. 5 hours (with completely
discharged battery)
Running time with full charge Approx. 22 minutes
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 3IB_384214_SAS7.4LIC2_GB-IE-CY.indb 3 14.10.2021 13:48:3114.10.2021 13:48:31
■ 4 │ GB│IE│NI│CY SAS 7.4 LI C2
Mains adapter
Manufacturers
Zhejiang Mootree Electronic Technology
Co., Ltd.
No. 36-1 Tongji Street, Nanmingshan Street,
Liandu District, 323000 Lishui City,
Zhejiang, China
Commercial register number:
91331127MA2E1A6T1D
Importer:
KOMPERNASSHANDELSGMBH,
BURGSTRASSE 21, 44867 BOCHUM,
GERMANY,
Register court: AG Bochum
Register number: HRB 4598
Model SUK006A-096050
Input voltage
100‒240 V ~(
AC
)
Input AC frequency 50
‒
60 Hz
Output voltage 9.6 V (DC)
Output current 0.5 A
Output power 4.8 W
Average operating efficiency 79.6 %
No-load power consumption 0.05 W
Current consumption 0.2 A
Polarity
Protection class II / (double insulation)
Efficiency class 6 6
VI
Protection type IP20: Protection against solid objects with
a diameter of more than 12.5 mm
This mark confirms that the product complies with the product safety
requirements applicable in the UK.
NOTE
► No user action is required to switch the product between 50and 60Hz.
The product adapts automatically to either 50or 60Hz.
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 4IB_384214_SAS7.4LIC2_GB-IE-CY.indb 4 14.10.2021 13:48:3314.10.2021 13:48:33
GB│IE│NI│CY │ 5 ■
SAS 7.4 LI C2
Important safety instructions
DANGER! ELECTRIC SHOCK!
Do not charge or use the appliance outdoors.
► Never use the handheld vacuum cleaner if the cable, plug
or casing are damaged.
► To avoid risks, arrange to have damaged power cables and/or
plugs replaced as soon as possible by a qualified specialist.
► Have all repairs carried out by a specialist workshop. Under
no circumstances should you open the appliance yourself.
Repairs that are not carried out by a specialist workshop
could lead to physical injuries.
► Before switching on the appliance, make sure that the mains
voltage corresponds to the voltage indicated in the technical
data for the appliance.
► Never touch the mains adapter or the appliance with wet or
damp hands.
► Do not use the mains adapter with an extension cable;
connect the mains adapter directly to a power socket.
WARNING! RISK OF INJURY!
► Do not change any accessories while the appliance is
switched on.
► Do not use the handheld vacuum cleaner for vacuuming up
sharp objects or glass shards.
► Never vacuum up burning matches, glowing ashes or
cigarette butts.
► Do not use the handheld vacuum cleaner for vacuuming up
chemical products, stone dust, gypsum, cement or similar
particles.
► This appliance is not suitable for use with inflammable and
explosive substances or chemical and aggressive liquids.
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 5IB_384214_SAS7.4LIC2_GB-IE-CY.indb 5 14.10.2021 13:48:3614.10.2021 13:48:36
■ 6 │ GB│IE│NI│CY SAS 7.4 LI C2
WARNING! RISK OF INJURY!
► Always store the appliance indoors. To prevent accidents,
keep the appliance in a dry location when not in use.
► Under extreme conditions, leaks in the battery cells may
occur. In the event that battery fluid comes into contact with
skin or eyes, the affected area must be rinsed off with water
immediately. Contact a physician.
► This appliance may be used by children aged 8 years and
above and by persons with limited physical, sensory or
mental capabilities or lack of experience and knowledge,
provided that they are under supervision or have been
told how to use the appliance safely and are aware of the
potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance tasks may not be carried
out by children unless they are supervised.
► Take special care when using the handheld vacuum cleaner
on stairs.
CAUTION! PROPERTY DAMAGE!
► Use only accessories recommended by the manufacturer.
► The mains adapter may not be used for other purposes. Never
carry the wall bracket or the mains adapter by the cable. Do
not pull on the cable when you want to move the appliance.
► Always grip the power plug to disconnect the appliance
from the power supply.
► Always be sure to keep the handheld vacuum cleaner away
from heating elements, ovens or other heated appliances
and surfaces.
► Make sure that the ventilation slits are never obstructed.
A blocked ventilation circuit can result in overheating and
damage to the appliance.
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 6IB_384214_SAS7.4LIC2_GB-IE-CY.indb 6 14.10.2021 13:48:3614.10.2021 13:48:36
GB│IE│NI│CY │ 7 ■
SAS 7.4 LI C2
CAUTION! PROPERTY DAMAGE!
►
UN 34811
Tel. ____________
The appliance is equipped with or supplied with
a lithium-ion battery. Do not throw the batteries
into a fire and do not subject them to high
temperatures. There is a risk of explosion!
► Do not use the handheld vacuum cleaner without the dust
filter inserted.
► Do not use the mains adapter for a different product and do
not attempt to charge this appliance with a different mains
adapter. Use only the mains adapter supplied with this appliance.
► Never attempt to recharge non-rechargeable batteries.
► The batteries in this appliance cannot be replaced.
Prior to first use
■ Remove all packaging materials from the appliance.
■ Press the dust filter bag 9and the dust filter 0a little way into the dirt
container q. They might have loosened during transport and thus not be
positioned correctly inside the dirt container q.
■ Place the dirt container qon the motor unit:
–Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
–Press the release button 8 and push the dirt container qonto the motor
unit at the same time.
–Let go of the release button 8so that the restraint engages in the
recess. The dirt container qis now firmly seated on the motor unit.
Information about the batteries
■ This handheld vacuum cleaner is powered by rechargeable lithium-ion batteries.
Before using the handheld vacuum cleaner for the first time, the batteries must be
charged. The charge indicator lamp 7lights up red during charging. As soon
as the batteries are fully charged, the charge indicator lamp 7lights up green.
■ For care of the batteries, we recommend the following: once the batteries
have been charged, disconnect the mains adapter 4from the mains socket.
Do not plug the mains adapter 4back into the mains socket until the
charge indicator lamp 7flashes green.
■ If the handheld vacuum cleaner is deep-discharged, the charge indicator
lamp 7flashes alternately red and green (approx. 1 minute). In this case,
switch off the appliance and start charging.
IB_384214_SAS7.4LIC2_GB-IE-CY.indb 7IB_384214_SAS7.4LIC2_GB-IE-CY.indb 7 14.10.2021 13:48:3614.10.2021 13:48:36
This manual suits for next models
1
Table of contents
Languages:
Other Silvercrest Vacuum Cleaner manuals
Silvercrest
Silvercrest SFR 3.7 D3 Technical specifications
Silvercrest
Silvercrest 353618 2010 User manual
Silvercrest
Silvercrest SHSS 16 A1 User manual
Silvercrest
Silvercrest 365241 2101 User manual
Silvercrest
Silvercrest SHS 12.0 A1 User manual
Silvercrest
Silvercrest SHS 12.0 A1 User manual
Silvercrest
Silvercrest 89291 User manual
Silvercrest
Silvercrest SAS 7.4 LI C2 User manual
Silvercrest
Silvercrest SHSS 12 C2 User manual
Silvercrest
Silvercrest SAS 7.4 LI D3 Product information sheet
Silvercrest
Silvercrest SAS 7.4 LI D3 Product information sheet
Silvercrest
Silvercrest SAS 7.2 A2 User manual
Silvercrest
Silvercrest SFR 3.7 D3 Technical specifications
Silvercrest
Silvercrest SAS 7.4 LI B1 User manual
Silvercrest
Silvercrest SHSS 12 C2 User manual
Silvercrest
Silvercrest SHSS 18 B1 How to use
Silvercrest
Silvercrest 337627 1910 User manual
Silvercrest
Silvercrest SFR 3.7 D6 Technical specifications
Silvercrest
Silvercrest SAS 7.4 LI C1 User manual
Silvercrest
Silvercrest SAST 18 A1 User manual
