Siemens HiPath 8000 User manual

Communication for the open minded

Siemens Enterprise Communications

www.siemens-enterprise.com

Documentation

HiPath 8000

OpenStage 40

Quick Reference Guide

oi.book Seite 1 Dienstag, 19. Juli 2011 12:39 12

Using Your Telephone

Function Keys and Audio Keys

5-way navigator

Programmable sensor keys on the display

rActivate/deactivate

forwarding

NService/Applications menu

OVoicemails/Call lists

pTurn microphone on/off

oTurn headset on/off

,Redial

sEnd (disconnect) call

nTurn speaker on/off

+Depending on situation,

-set volumes for

ringer or speaker

Press mkey:

- Scroll upwards

Press lkey:

- Scroll downwards

Press gkey:

- Call up the context menu

- Go down a level

Press hkey:

- Cancel function

- Delete character

left of cursor

- Go up a level

Press ikey:

- Confirm input

- Perform action

Keys

Label

S inactive

R lit

T flashing

Peter

Mirea, Ch.

oi.book Seite 2 Dienstag, 19. Juli 2011 12:39 12

Using Your Telephone

Display

Components

Entering Phone Numbers and Text

Keypad

In situations where text entry is possible, you can use the dial keys to enter text, punctua-

tion and special characters. To do this, press the numerical keys repeatedly.

Extra asterisk and pound key functions:

Key Function during text input Function when held down

*Write special characters Deactivate the ring tone.

#Switch between upper/lower case and digit entry. Activate telephone lock.

Status bar

Programmable sensor key list

Context-dependent displays

Level 2

Mirea, Ch.

Toussaint.

Rüscher

Stahl, Ing

Iller, Zin

10:29 am Wed 11/17/06

Company name

01234567

Own phone number

oi.book Seite 3 Dienstag, 19. Juli 2011 12:39 12

Important Operating Procedures

In Idle State

Answering a call with the handset

ZZ^

Answering a call in speakerphone mode

ZZn

Rejecting a call

ZZf"Reject" i

Deflecting a call

ZZf"Deflect" iZj destination phone number i

Dialing from the caller list

OZf"CallLog" iZf "Missed", "Dialled", "Received" or "Forwarded" i

Zf desired entry i

Activating callback

j destination phone number iZif no answer or busy: f"Call back" i

Saving a phone number to a key

SHold down programmable key Zf"Normal" or "Shifted" i

Zf"Selected dialling" iZf„Label“ iZjEnter name, e.g. Peter

Zf"Setting:" iZjdestination number i Zf"Option = Save & Exit" i

Zf"Save & Exit" i ZN

Dialing a saved number

Ssaved phone number Zn loudspeaker turns on automatically or ^

^Lift handset jEnter text or number

\Replace handset fSelect entry

[Conduct call gOpen context menu

ZRing tone/call waiting tone ZNext step in procedure

oi.book Seite 4 Dienstag, 19. Juli 2011 12:39 12

Important Operating Procedures

Saving a function to a key

SHold down programmable key Zf"Normal" or "Shifted" i

Zfselect function i(for funnctions with phone number: Zf"Setting:" i

Zenter the phone number) Zf"Option = Save & Exit" i Zf"Save & Exit" i ZN

Redialing a number

,"Repeat dialling" Zfdesired number iZ^

Programming call forwarding

rZf"Edit call forwarding" iZf"Destination" (e. g. under "All calls") i

Z"Edit favourites" iZf"Destination 1" iZjphone number i

ZSelected forwarding type, e.g. f"All calls" iZgZf"On" i

Zf"Options = Save & Exit" iZf"Save & Exit" i ZN

Turning call forwarding on/off for all calls

Requirement: Forwarding destination for "All calls" was programmed.

oi.book Seite 5 Dienstag, 19. Juli 2011 12:39 12

Important Operating Procedures

During Calls with a Party A

Switching to speakerphone mode

Hold down nZ\(US only: nZ\)

Consultation

gZ"Consultation" iZ

phone number for party B iZ[party B Zg

Z"Disconnect & return" iZ[party A

Accepting call waiting

Zcall waiting tone Zf"Accept" iZ[party B Zfparty B Zg

Zf"Disconnect & return" iZ[party A

Deflect call on call waiting

ZCall waiting tone Zf"Deflect" iZ

phone number for party B iZ[party A

Start conference

gZ"Consultation" iZ

phone number for party B iZ[party B Zg

Zf"Conference" iZ[party A and B

Start conference on call waiting

Zcall waiting tone Zf"Accept" iZ[party B ZgZf"Conference" i

Z[party A and B

Blind transfer to party B

gZf"Consultation" iZjdestination phone number iZ\

Transfer after consultation

gZf"Consultation" iZ

phone number for party B iZ[party B Z\

oi.book Seite 6 Dienstag, 19. Juli 2011 12:39 12

Communications GmbH & Co. KG

Hofmannstr. 51

80200 München

Deutschland

Siemens Enterprise

Communications GmbH & Co. KG

is a Trademark Licensee of Siemens AG

Reference No:

A31003-S2000-U113-3-7619

The information provided in this document

contains merely general descriptions or char-

acteristics of performance which in case of

actual use do not always apply as described

or which may change as a result of further

development of the products.

An obligation to provide the respective char-

acteristics shall only exist if expressly agreed

in the terms of contract. Availability and

technical specifications are subject to

change without notice. OpenScape,

OpenStage and HiPath are registered trade-

marks of Siemens Enterprise

Communications GmbH & Co. KG.

All other company, brand, product and ser-

vice names are trademarks or registered

trademarks of their respective holders.

Siemens Enterprise Communications

www.siemens-enterprise.com

Communication for the open minded
