Sibata SIP-32L User manual
CODE 080800-32
OPERATION MANUAL
Thank you for purchasing this product.
Be sure to read this operation manual before use.
Handle this product in accordance with the explanations described in this manual.
After reading this operation manual, keep it with the warranty in a safe place where
they can be referred to at any time.
If you find any unclear points in this manual, please contact your Sibata agent.
SIBATA SCIENTIFIC TECHNOLOGY LTD.
Suction Pump
SIP-32L
Using the Product Correctly and Safely
Read this operation manual carefully to the end before using the product
and make sure it is used correctly. Also, keep this manual handy.
Before Using the Product
(Be sure to read this, and handle this product with due care.)
△ Install this product horizontally at a stable location.
△ Be sure to ground this product.
△ This product is not explosion-proofed, so do not use it in the vicinity of
combustible or flammable substances.
△ [Modifications and Repairs Are Prohibited] Never disassemble or
modify this product, as doing so will void the warranty with Sibata. Doing so
may also result in an unforeseen fault or accident.
△ If a fault occurs, request repairs immediately. Never leave the fault as is or
attempt your own repairs, as subsequent use may result in an unforeseen
accident.
△ If this product starts to emit smoke, becomes abnormally hot, or is making
strange noises, immediately stop using the product, turn OFF the power, and
remove the plug from the electrical outlet. Then request repair of the product.
△ When removing the power plug from the outlet, hold the cord by the power plug
to avoid pulling on the power cord. Be sure your hands are dry before handling
the power cord. Otherwise, there is a risk of electric shocks.
△ Do not bend, stretch, or twist the cord. Do not connect it to a different cord.
△ If you notice that the cord has become damaged or broken or that the plug
does not connect properly, stop using it immediately and request repairs.
△ A breakdown will result if the pump sucks in dust or water. Prevent this by
using filters or traps.
△ Do not allow this product to be directly splashed with water.
- 1 -
Table of Contents
1Overview …………………………... 1 6 Spare Parts ……………………….. 3
2Specifications …………………….. 1 7 Troubleshooting ……………..….. 4
3Composition ……………………… 2 8 Warranty ………………………….. 4
4Instructions for Use …………..…. 2 9 External Dimension Diagram ….. 5
5Maintenance and Inspections ….. 2
5-1
Exploded View ………………. 3
1Overview
This is a diaphragm type suction pump, used for measurements of work
environment and air. This pump runs quietly, and is lightweight for easy transport.
A buffer is built into the suction mechanism to minimize suction pulsations. It can
also be used as a discharge pump.
2Specifications
Item code 080800-32
Model SIP-32L
Suction flow rate 40 L/min (with no load)
Suction pressure 27 kPa (max.)
Hose connection port External diameter: φ11 mm
Power supply 100 VAC 50/60Hz 1A
Dimensions and
Weight Approx. 150W×205D×177Hmm, Approx. 5kg
Usage conditions
Use it indoors for 0.5 hours to 72 hours at a time,
for a total annual period of 3,000 hours max.
(Ensure that the pump unit is placed on a level surface.)
- 2 -
Power cord
Grounding terminal
3Composition
Fig.1
4Instructions for Use
(1) Install the pump on a level surface.
(2) Check that the power switch is OFF. Then plug
the power plug into the outlet.
(3) Check the connections to the pump, and then turn it ON.
Note: Be sure to connect the grounding terminal prior to use.
5Maintenance and Inspections
Replace the chamber block every 3 years. The replacement procedures are
explained below and in Fig. 2.
(1) Remove the screws at the four corners of the cover over the base fastening
stand. Then insert a screwdriver between the suction exhaust port and the
cover, and remove the cover.
(2) Loosen the four screws attaching the casing, and remove the casing.
(3) Remove the lock nut at the center of the diaphragm. The diaphragm stand can
now be pulled forward.
(4) Reassemble as before with the new part. Assemble the opposite side similarly.
(5) Also, replace the L-tube connecting the casing and the base plate.
(6) When the replacements are finished, put the cover back on, and tighten it with
the four screws.
Power cord
Discharge port
Suction port
Switch
- 3 -
If Rust Turns the Whole Surface Red
If the diaphragm is damaged, the permanent magnet in the rod may rub against
the iron core in the electromagnet, resulting in fine iron powder scattering. Blow
this away using an air source, or wipe it away with a clean cloth before replacing
the chamber block.
If the Rod Breaks
If the pump continues to operate with the diaphragm damaged, the rod will
ultimately break and the permanent magnet will be dislocated. In this case,
exchange the rod for a new one, and replace the chamber block.
5-1 Exploded View
Fig.2
6Spare Parts (Please purchase them separately.)
Item code Product Name
080800-3201 Hose Adapter with Elbow for SIP-32L
080800-3202 Chamber Block Set New Type for SIP-32L 2pcs.
080800-3203 Rod New Type for SIP-32L
L-tube
Diaphragm stand
Rod
Chamber block se
t
Casing
Base fastening stand
Diaphragm
Lock nut
Base plate
Cove
r
Metal washer
- 4 -
7Troubleshooting
If you think there has been a breakdown, check the following points.
Problem Cause Remedy
There is no suction.
There is no running
noise.
The power is not ON. Connect it to the power
supply.
The coil temperature
protection has tripped.
The safety thermal cutoff has
tripped due to an internal
temperature increase. This
occurred because air was not
delivered due to damage to
the diaphragm. Please buy a
new pump.
The pump makes a
running noise, but
there is no suction.
The diaphragm or
valves are damaged. Replace the chamber block
set and L-tube as per Fig. 2.
The L-tube is damaged.
8Warranty
If a Sibata product fails within one year from date of purchase, it will be
repaired free of charge.
To request repairs, contact your Sibata representative or the distributor
where you purchased the product.
Be sure to provide the item code, product name, model number, serial
number, a description of the problem, and other relevant information.
Consumable parts included with Sibata products are not covered by the
warranty.
The warranty excludes any problems resulting from any of the following
causes. Such repairs are subject to normal service fees.
(1) Faults due to improper usage.
(2) Faults or damage resulting from repairs or modifications implemented by
parties other than Sibata.
(3) Faults or damage resulting from fires, earthquakes, or other natural
disasters.
(4) Faults or damage occurring after purchase due to relocation, movement,
falling, or vibration.
(5) Faults or damage resulting from the use of consumable items not
specified by Sibata.
(6) Any case in which the date of purchase or signature has not been
provided by the distributor where you purchased the product, or the
warranty items have been revised.
(7) [Modifications and Repairs Are Prohibited] Never disassemble or modify
this product, as doing so will void the warranty with Sibata. Doing so may
also result in an unforeseen fault or accident.
- 5 -
9External Dimension Diagram
Fig.3
20.06.25 K (05)
132
4.6
Note) Shape, dimensions, specifications, and other product information are subject to change without
notice in the interest of product improvement to the extent that product functions and applications will
not be impaired.
