ShowPro Truss Mate II User manual

Truss Mate II

User Manual

www.showtech.com.au

Truss Mate II

Table of Contents

1. Safety instructions…………………………………………………………3

1.1 Power Connection ………………………………….……………….4

1.2 Overhead Rigging …………………………………………………...4

1.3 DMX Connection ……………………………………………………..6

1.4 Cleaning and Maintenance ………………………………………6

2. Menu Navigation .…………………………………………………………7

3. DMX Allocation….………………………………………………………….8

4. Technical Specifications ……………………….……………………….9

Truss Mate II

1. Safety Instructions

FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperature.

Avoid exposing it to direct to rays of sun.

Operate only between 41°F/5°C and 95°F/35°C.

Keep away from humidity, water and dust.

Do not place the use in a location with high humidity or lots of dust.

It is ideal to use the Hercules away from such equipment:

Transformer motor, tuner, TV set and amplifier.

Avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a dry cloth to wipe off dust, or a wet soft cloth for stubborn dirt.

NO USER SERVICABLE PARTS INSIDE.

If unit is out of service, please contact your point of purchase.

If any troubles arise, remove the power plug and contact your ShowPro

representative for repair. Do not open the machine by yourself, it might result a

danger of electric shock.

Take care with the power cable. Never pull the power cable to remove the plug from

the receptacle, be sure to hold the plug.

When not using the unit for an extended period of time be sure to disconnect the

plug form the receptacle.

Truss Mate II

1.1 Power Connection

AC Power This product has an auto-ranging power supply that can work with an

input voltage range of 100–240 VAC

AC Plug

1.2 Overhead Rigging

This item must be built in a way that it can hold 10 times more of its weight for 1

hour without causing any damage. The installation must be secured with a secondary

safety attachment. The Safety attachment has to be constructed in a way that no

part of the installation can fall. When rigging, de-rigging or servicing the fixture

ensure that the area below is secure. Before putting the device into operation, the

installation must be approved by an expert. The operator has to make sure that

safety-relating and machine-technical installations are approved by a skilled person

once a year.

IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE.

Including (but not limited to) calculating working load limits, installation material

being used, and periodic safety inspection of all installation material and the

projector. If you lack these qualifications, do not attempt the installations yourself,

but instead use a professional structural rigger. Improper installation can result in

bodily injury and/or damage to property.

Use only professional trussing system if the item is to be lowered from the ceiling or

high joists. Never let the device swing freely in a room.

CAUTION: Overhead Items may cause serious injuries when not installed correctly!! If

there is concern about the safety DO NOT INSTALL the device.

Connection

Wire

AC Live

Brown

AC Neutral

Blue

AC Ground

Green/Yellow

Truss Mate II

DANGER OF FIRE!

When installing the device, make sure there is no highly-flammable material

(decoration articles, etc.) within a distance of min. 0.5m.

Mount the projector with the mounting bracket to your trussing system using an

appropriate clamp.

For overhead use, always install a rated safety - wire that can hold at least 10 times

the weight of the fixture. You must only use rated safety –wire with quick links with

screw cap. Pull the rated safety - wire through the hole in the mounting bracket and

over the trussing system or a safe fixation spot. Insert the end in the quick link and

tighten the safety screw. The maximum drop distance must never exceed 20cm

A safety - wire which has already held the strain of a fall or which is defective must

not be used again.

IMPORTANT!

Before taking into operation for the first time, the installation has to be approved by

an expert.

Truss Mate II

1.3 DMX Connection

DMX Linking the Trussmate II will work with a DMX controller using a 3-pin DMX serial

connection.

DMX Connection the Trussmate II uses 3-pin DMX data connections for its DMX

personalities:

3 Ch, 8 Ch. See the User Manual for information about connecting and configuring the product

for DMX operation.

1.4 Cleaning and Maintenance

Please make sure that safety-relating and machine-technical installations are inspected by a

skilled person once a year.

1. Make sure before installing that all screws are tightly connected and not corroded.

2. There must be no deformations on the housings, fixations and installations spots

3. Any defects on the electronics, power cables or housing must be repaired for safe

use.

If the exterior of the unit is going to be cleaned, please use moist, lint free cloths. Never use

alcohol or solvents.

The Cooling fan must be cleaned monthly and check to ensure it is free of obstructions.

To clean the interior of the device please use a vacuum cleaner or an air jet, however we

recommend cleaning the lenses weekly to ensure the best output from your unit.

Truss Mate II

2.0 Menu Navigation

NO.

Menu Level 1

Menu Level 2

Menu Level 3

Remark

Default: 3-CH，d 1

1：R

2：G

3：B

4：GB

5：RB

6：RG

7：RGB（Default ：RGB）

P1：3Colors snap (Default P1)

P2：3 Colors Fade

P3：7Colors snap

P4：7Colors Fade

Speed : 1-100（slow - fast）

Default:100

Sound

（Default: Snd1）

（Default 80）

（Default RGB=255）

OFF: Dimmer speed off

DIM1: Dimmer speed fast

DIM2: Dimmer speed middle

DIM3: Dimmer speed slow

Default：OFF

Default：On

Truss Mate II

3.0 DMX Allocation

3-CH

Function

Value

Percent/Setting

Red

000-255

0~100%

Green

000-255

0~100%

Blue

000-255

0~100%

8-CH

Function

Value

Percent/Setting

Red

000-255

0~100%

Green

000-255

0~100%

Blue

000-255

0~100%

Color

000-015

016-255

No Function

Color Macros

Strobe

000-015

016-255

No Function

Strobe Slow to Fast

Programs Speed

000-255

Programs Speed Slow to Fast

Programs

000-031

032-063

064-095

096-127

128-159

160-191

192-223

224-255

No Function

0-100%

100%-0

100% -0-100%

Colors Fade

3Colors snap

7Colors snap

Sound Control

Dimmer

000-255

0~100%

Dimmer

speed

mode

000-051

052-101

102-152

153-203

Preset dimmer speed from display

Dimmer speed mode off

Dimmer speed mode1 (fast speed)

Truss Mate II

204-255

Dimmer speed mode2 (middle

speed)

Dimmer speed mode3 (slow speed)

4.0 Technical Specifications

OPTICS

LED Specification

3W RGBW 3 in 1 LEDs

LED quantity

Field Angle

32°

Beam Angle

16 °

Output

114 lux @ 5 meters

Control

Control method

DMX

WDMX Compatibility

N/A

DMX Channels

3 & 8

Dimming Curves

4 Modes

Dimming Resolution

16 bit

Data Connections

3 Pin

LCD

Electrical

Power

240V

Battery Specifications

Working Hours

6 Hours

Charging hours

4.5 Hours

Charging

240v IEC

Truss Mate II

Charging during use

YES

Input Voltage AC

90V-240V AC 50/60 Hz auto-ranging

Power Consumption

13.6W

Fuse

T1A 250V

Physical

Weight

1.29 Kg

Size

135.5x121.3x108.3

Cooling System

Fan-free convection cooled

IP Rating

IP20
