OWNER’S
MANUAL
824–171
Rev
A
HVLP
Compressor/Cart
120
V
AC 50/60 Hz: Series
Maximum Working Pressure:
15 psi (1.0 bar, 104 kPa)
Model GTS–ProCart, Series A
Cart with material hose, 283–584
Cart with air & material hoses, 283–585
Cart with air & material hoses,
and GTS 980 Pressure Gun w/#3 fluid set, 232–576
The SHERWIN–WILLIAMS COMPANY, CLEVELAND, OHIO 44115
COPYRIGHT
1998, GRACO INC.
This manual contains important
warnings and information.
READ AND RETAIN FOR REFERENCE
Table
of Contents
Warnings
2
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Information 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shutdown 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This
symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This
symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
FIRE AND EXPLOSION HAZARD
Improper
grounding, poor ventilation, open flames or sparks can cause a hazardous condition and
result in a fire or explosion and serious injury
.
D
Ground the equipment and the object being sprayed. Refer to
Grounding
on page 7.
D
If there is any static sparking or you feel an electric shock while using this equipment,
stop spray-
ing immediately
.
Do not use the equipment until you identify and correct the problem.
D
Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
D
When flammable liquid is sprayed or used for flushing or cleaning the equipment, the compressor
must be placed at least 20 feet (6.1 m) away from areas where hazardous concentrations of flam
-
mable vapors are likely to occur
.
D
Use additional air hose if necessary to ensure that the compressor is operated in a clean, dry
, well
ventilated area.
D
Never place the compressor inside a spray booth!
Use this equipment outdoors or in extremely well
ventilated areas.
D
Keep the spray area free of debris, including solvent, rags, and gasoline.
D
Electrically disconnect all equipment in the spray area.
D
Extinguish all open flames or pilot lights in the spray area.
D
Do not smoke in the spray area.
D
Do not turn on or of
f any light switch in the spray area while operating or if fumes are present.
D
Do not operate a gasoline engine in the spray area.
824-1713
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment
misuse can cause the equipment to rupture or malfunction and result in serious injury
.
D
This equipment is for professional use only
.
D
Read all instruction manuals, tags, and labels before operating the equipment.
D
Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor
.
D
Do not alter or modify this equipment. Use only genuine Graco parts.
D
Check equipment daily
. Repair or replace worn or damaged parts immediately
.
D
Do not exceed the maximum working pressure of the lowest rated system component. The Com
-
pressor/Cart has a working pressure of 15 psi (1.0 bar
, 104 kPa).
D
Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the
Speci-
fications
on page 19 for this information.
D
Do not use hoses to pull equipment.
D
Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82
_
C (180
_
F) or below –40
_
C (–40
_F).
DW
ear hearing protection when operating this equipment.
D
Do not lift pressurized equipment.
D
Comply with all applicable local, state, and national fire, electrical, and safety regulations.
D
Do not point the gun at anyone or at any part of the body
.
D
Do not put your hand or fingers over the gun fluid nozzle.
D
Do not stop or deflect leaks with your hand, body
, glove or rag.
D
Do not “blow back” fluid; this is not an air spray system.
D
Follow the
Pressure Relief Procedure
on page 12 if the fluid nozzle clogs and before cleaning,
checking or servicing the equipment.
DT
ighten all fluid connections before operating the equipment.
D
Check the hoses, tubes, and couplings daily
. Replace worn or damaged parts immediately
.
WARNING
TOXIC FLUID HAZARD
Hazardous
fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
D
Know the specific hazards of the fluid you are using.
D
Store hazardous fluid in an approved container
. Dispose of hazardous fluid according to all local,
state and national guidelines.
D
Always wear protective eyewear
, gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer
.
D
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or
fluids containing such solvents in the turbine spray system, which contains aluminum and/or galva
-
nized-coated parts. Such use could result in a serious chemical reaction, with the possibility of
explosion, which could cause death, serious injury
, and/or substantial property damage.
Information
HVLP Compressor/Cart Information
The
GTS–ProCart HVLP Compressor/Cart when used
with a turbine sprayer and turbine spray gun can spray
most coatings or finishes currently being used for
automotive refinish, industrial, aerospace, marine,
wood, plastic and architectural applications.
The cart/compressor provides air pressure to a 2–1/2
gallon remote pressure pot or a 2 quart pressure pot.
Under pressure, fluid is propelled from the pot to
turbine spray gun.
See Fig. 1 for Component Identification and Function.
HVLP System Operation
The
spray gun of the HVLP system utilizes inbound air
pressure from the cart/compressor and HVLP turbine
sprayer to produce a high quality paint finish. The
spray gun produces a cone of air that carries and
directs the paint from the gun to the surface. Over
-
spray is minimized. Application is easier since fewer
paint passes are required to obtain coverage. In
-
creased system transfer ef
ficiency reduces material
requirements and clean-up time. The system allows
compliance with clean air laws for reduced VOC (vola
-
tile organic compounds) emissions.
Refer to the HVLP turbine sprayer manual 824–170 for
information on the operation and use of the HVLP
turbine sprayer
. Refer to the turbine gun manuals,
308–336 or 308–810, for information on the operation
and use of the turbine spray gun.
Dif
ferent configurations of, HVLP compressor/carts,
turbine sprayers, guns, and accessories are available
to meet specific application requirements.
Unpacking
Unpack the Graco cart/compressor from the shipping
carton and inspect for any possible shipping damage.
If necessary
, call your distributor
.
The contents of the GTS–ProCart includes:
D
Cart with compressor
D
Material hose
D
Air hose (models 283–585 and 283–586 only)
D
GTS 980 spray gun (model 283–586 only)
D
Instruction manual, 824–171.
Component
Identification and Function
7930A
Fig.
1
E
C
B
G
D
A
F
H
I
J
A
Remote Paint Pot Holder
Provides space for 2 qt or 2–1/ gal paint pots
B
Air Outlet
Connection for compressor air supply to remote paint pots
CT
urbine Latch
Latch locks turbine sprayer in position on cart
D
Hose Holder
Provides storage space for sprayer hose, gun and accessories
E
Cart Handle
Compressor/cart handle. Handle folds flat for minimum storage space
FT
urbine Sprayer Base Mount
Provides lock–mount for turbine sprayer on cart
G
ON/OFF Switch
ON/OFF power switch for compressor motor
H
Air and Material Hoses
Hoses provide operating air and material to gun
I
2–1/2 Gallon Paint Pot
Holds 2–1/2 gallons of application material
JT
urbine Spray Gun
Controls and applies material to be sprayed
Setup
Grounding
WARNING
Improper
installation or alteration of the grounding
plug will result in a risk of electric shock, fire or
explosion that could cause serious injury or death.
120 V
ac Systems
1.
This equipment requires a 120 V
ac, 60 Hz, 15A
circuit with a grounding receptacle. See Fig. 2.
Fig. 2
Grounding
Prong
Grounded
Outlets
2. Do
not alter the ground prong or use an adapter
.
3.
A 12 A
WG gauge, 50 ft extension cord may be
used with this equipment.
Prepare the Fluid
1. Always
strain the fluid before spraying; this
includes color
, reducer and hardeners if used.
2.
When using a turbine spray system, you need to
use a slower drying reducer or thinner to compen
-
sate for the faster drying time caused by the warm
air of the turbine.
Do not over reduce.
NOTE:
The performance of the turbine sprayer will
vary with viscosity of material used and hose length.
Keep hose length short to prevent pressure drop.
Paint Reduction – Automotive Type Finishes
Reduce and catalyze all paint to manufacturer
’
s speci
-
fications. T
o compensate for the faster drying time of
turbine systems, use a reducer one-step slower than
what is used for conventional air spray
.
Paint Reduction – Industrial or Domestic Coatings
Reduce and catalyze all paint to manufacturer
’
s speci
-
fications. If no reductions are given, first thoroughly
mix the fluid to be sprayed. Then gradually mix in the
proper reducer
, testing the fluid until you have the
correct spraying consistency
.
T
o test the consistency:
Remove the stir stick from the
thinned paint. When the paint stream running of
f the
stir stick breaks into droplets, the first few drops should
be about one second apart.
Setup/Use Options
The
HVLP compressor/cart has a variety of user
options. See Fig. 3 for compressor/cart uses.
NOTES:
D
Refer to turbine manual 824–170 for information on
turbine setup and operation.
D
Refer to turbine gun manuals: 308–336 or 308–810,
for information on turbine spray gun setup and
operation.
Setup
7933A
7932A
7931A
Fig.
3
1. Place turbine (1) on cart
Cart/Compressor with turbine sprayer
and 2–1/2 gallon remote paint pot
1. T
urn knob to free handle
2. Fold handle down to store
1
1
T
O ST
ORE HANDLE
T
O LOCK AND CONNECT TURBINE AND CAR
T
2
T
O CARR
Y REMOTE P
AINT POT
1. Place remote paint pot in cart
2. Move latch (2) right to lock
1
2. Hook up per instructions
A
3. Plug cart into turbine outlet (A)
4. Plug turbine into grounded outlet
7934A
Fig. 4
C
D
D
2-1/2 Gallon Remote Pressure Pot
2 Quart Remote Pressure Pot
F
J
J
A
G
G
G
C
A
B
L
E
Cup Setup for Spray Gun
E
ZZ
HH
Cup–Over Option
see manual
308–336 or
308–810
F
KK
Y
XX
Y
Y
Z
X
Setup
Connect Fluid and Air Supplies
1. Connect
gun air supply hose (A) between turbine
air outlet (B) and gun air inlet (C). DO NOT use
wrench to tighten connections; hand–tighten only
.
See Fig. 4.
2.
For GTS–4900:
the GTS–4900 turbine uses
quick–connector at outlet (B). A wrench is not
required for hose connection.
3.
If using spray gun cup (D),
connect cup to gun
fluid inlet (E).
4.
If using accessory remote pressure pots (F),
connect fluid supply hose (G) between remote
pressure pot fluid outlet (H) and gun fluid inlet (E).
Connect pressure pot air hose (J) between pres
-
sure pot air regulator inlet (K) and cart compressor
air outlet (L).
NOTES:
D
The HVLP Cart/Compressor provides the air supply
for remote pressure pots.
D
The circled letters in Fig. 4 indicate hose line con
-
nections.
Connect to Electric Power
1. Plug
compressor/cart power cord into turbine
auxiliary outlet (A) or grounded outlet. See Fig. 3.
2.
If extension cord is used, it must be 3-wire, 12
A
WG and 100 ft or less in length.
10 824-171
Setup
Fill the Cup or Remote Pressure Pot
Spray Gun Cup
WARNING
The spray gun cup is pressurized by the gun’
s air
supply. T
o reduce the risk of serious injury from
pressurized fluid or accidental spray from the gun,
always turn of
f the air supply to the gun before
removing the spray gun cup.
Only fill the cup 3/4 full to help keep the air pressure
tube clean, then install the cover
. The under-cup cover
has a latch (H) to secure it to the cup. The over-cup
has a ring with notches (J) that secures the cup hood
into place when locked in place on the cup.
Fig. 5
H
J
Accessory Remote Pressure Pot
WARNING
The accessory remote pressure pots remain pres
-
surized until pressure is manually relieved. T
o
reduce the risk of serious injury from pressurized
fluid or accidental spray from the gun, always
relieve pressure in the pressure pot before loosen
-
ing or removing the cover
.
1.
Relieve remote pressure pot pressure as follows:
a. T
urn of
f air supply to pressure pot. See Fig. 6.
b.
2 1/2 Gallon Remote Pot:
Pull pressure relief
valve ring (206c) until pressure is completely
relieved.
2 Quart Remote Pot:
Turn out
pressure relief
knob (1
13) one turn. W
ait until pressure is
completely relieved before removing cover
.
Close knob.
Fig. 6
206c
113
2 quart
2 1/2 gallon
2. Remove
pressure pot cover and fill. Secure cover
.
NOTE:
2 quart remote pressure pot only:
lightly coat
the cover threads with petroleum jelly
.
CAUTION
If the 2 quart remote pressure pot is accidentally
tipped over or held at too great of an angle, fluid may
leak into the air regulator and cause damage. T
ake
precautions to avoid this. If fluid does get into the
regulator
, clean it immediately
.
CAUTION
Do not tighten the pressure pot cover more than
hand-tight. Excessive tightening may damage the
cover gasket.
This manual suits for next models
3
Popular Compressor manuals by other brands
Emerson
Emerson Copeland Scroll Digital HLR Series Application guidelines
Drawmer
Drawmer 1968 MKII Operator's manual
Badger Air-Brush
Badger Air-Brush X-Air 80-8 User and maintenance instructions
Omnitronic
Omnitronic CL-166 user manual
Scheppach
Scheppach HC24V Translation from the original instruction manual
Ingersoll-Rand
Ingersoll-Rand centac C950 Planning and installation manual
