Sharp AQUOS 4T-C50AH1X User manual

LED BACKLIGHT TV
OPERATION MANUAL
Please choose your favourite page from the content.
If you want to close the operation manual, press the
 (HOME) button.
Also, if you want to return to the previously displayed page,
press the   (BACK) button.
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>>

1. Part Names
1-1. TV
1-3. Remote Control Unit
2. Watching TV
2-1. Displaying an External Equipment
2-2. Initial Installation
3. Direct Button Operation
3-1. Changing Channels
3-2. Changing Volume
3-3. MUTE
3-4. AD/MPX
3-5. BROWSER
3-6. YouTube
3-7. HOME
4. On-Screen Display Menu
4-1. Introduction
4-3. On-Screen Display Menu Operation
4-4. Menu Operation Buttons
4-5. Initial setup
4-16. Information
4-22. Picture settings
4-24. Audio settings
4-25. Smart TV
4-30. System options
5. Enjoying Photo/Music/Video Playback
5-1. Preparation
5-3. USB Media Player
5-4. Selecting the Folders to Play Back
5-6. Playing Back Files on a USB Memory
Device/Home Network Server
6. Using LINK Operation
6-1. Controlling HDMI Equipment Using
LINK Operation
7. Using a PC
7-1. Control of the TV
7-7. PC Compatibility Chart
8. Using the Internet
8-1. Connecting to the Internet
8-4. Smart TV
8-7. Entering Text (Software Keyboard)
8-9. Using the Browser
8-14. Using Keyboard and Mouse
8-15. Using Applications via the Internet
9. Appendix
9-1. Troubleshooting
9-3. Troubleshooting - Error Message
9-4. Information on the Software License
for This Product
10. Trademarks
11. Specifications
11-1. TV
11-2. Wireless LAN
12. Dimensional Drawings
12-1. 4T-C50AH1X
Contents
EN Contents
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

IMPORTANT INFORMATION
EN Important1
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

IMPORTANT INFORMATION
EN Important2
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

TV
(Front)



(Side)

The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly
from the actual operations.
Part Names
One Button Key Functions Descriptions
Single Press On/Off (No OSD display)
Long Press Sub-menu display on TV screen (10s timeout)
Function During
Menu 1. INPUT*
2. CH  *
3. CH  *
4. VOL +*
5. VOL -*
* Single Press: Scroll Down
* Hold Press: Select item
EN 1-1
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

TV (Continue)
(Rear)



*1 See the Setup Guide. And see page 6-1
for external equipment connection.
*2 Use HDMI IN 1 to connect ARC-
compatible equipment.
*3 Usually do not connect anything to this
terminal as it reserved only for service
personnel.
Part Names
EN 1-2
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

Remote Control Unit 1 POWER: Switch the TV power on or enter standby.
2 0-9: Set the channel. (See page 3-1.)
3 AD/MPX: Select the sound multiplex mode and audio description.
(See page 3-4.)
4   (BROWSER): Display the BROWSER screen.
5  (BACK) : Return to the previous screen.
6   /   /   /  , ENTER: Select a desired item on the screen.
7 VOL+/-: Set the volume. (See page 3-2.)
8 R, G, Y, B: The coloured buttons are correspondingly used to select the
coloured items on the screen.
9 AV MODE: Select the video setting. (See page 4-22.)
10 SUPER ECO: Reduce backlight brightness to save power consumption.
11 EPG
DTV: Display the EPG screen.
12 YouTube: Display the YouTube screen.
13   (HOME): Display the HOME screen. (See page 3-7.)
14   (MUTE): Mute the sound. (See page 3-3.)
15 CH  /  : Select the channel. (See page 3-1.)
Part Names
EN 1-3
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<


Displaying an External Equipment Image
To view external source images, select the input source by pressing
 (HOME) on the remote control unit or One Button Key on the TV.

Watching TV

Example


1 Press   (HOME) to display the HOME screen.
2 Press   /   to select "Input".
3 Press  , press   /   to select the input source, and then press ENTER.
An image from the selected source automatically displays.
EN 2-1
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

Initial Installation
Perform the following steps before you press POWER on the remote control unit.
1. Insert the batteries into the remote control unit.
2. Connect the antenna cable to the TV.
3. Plug in the AC cord to the AC outlet.
4. Press POWER on the remote control.
The initial auto installation wizard appears. Press ENTER to start the wizard.

Language (Language setting)
Select from among 13 languages. (English, Simplified Chinese, Arabic, French, Portuguese, Russian,
Persian, Thai, Vietnamese, Indonesian, Hebrew, Hindi and Malay)
1 Press   /   to select the desired language listed on the screen, and then press ENTER.
Watching TV
EN 2-2
ENGLISH  |  FRANÇAIS  |  PORTUGUÊS  |  РУССКИЙ  |  中文  |  INDONESIA  |  ภาษาไทย  |  TIẾNG VIỆT  |  ﻲﺑرﻋ  |  АҒЫЛШЫН  |  O'ZBEK TILIDA
>><<

Initial Installation (Continue)
Location
Make settings for the country where you use the TV.
2 Press   /   /   /   to select "Iran", "Singapore", "Malaysia", "Morocco", "Vietnam", "Indonesia",
"Myanmar", "Thailand", "Uzbekistan", "Philippines", "Kenya", "Tanzania", "Nigeria", "Angola", "United Arab
Emirates", "Georgia", "Mauritius", "Egypt" or "Others", and then press ENTER.
Watching TV
EN 2-3
