Sharp AQUOS LC-22LE520M-RD User manual

LC-22LE520M (RD)

22” FULL HD (1920 X 1080) LCD PANEL

LED BACKLIGHT

1080/24P SIGNAL INPUT FOR THE FRAMES

JUST AS THEATER

3 HDMI TERMINALS

BUILT-IN TELETEXT

ECOLOGICAL FEATURES, SUCH AS ADVANCED

OPC

D-SUB 15 PIN TERMINAL FOR PC AND

ANALOGUE RGB SIGNALS

DIGITAL AMPLIFIER FOR PRODUCT CLEAR

SOUND

The LC-22LE520M Series expands the breadth of AQUOS LED LCD TV offerings with a contemporary, ultra-thin design and

high-quality performance. A powerful LCD panelcombined with an edge lit LED backlight system provide high contrast ratios for

deep blacks and vibrant colours in dark or bright scenes. They come equipped with HDMI® inputs for convenient connection to

HD-capable devices.

DISPLAY

Visible screen size: 22" (55cm)

Resolution: 1920 x 1080 x 3

HD-ready / HD-ready 1080p: Full HD 1080p

Brightness (cd/m²) / Contrast ratio: High Brightness/High Conrast

Backlight System LED/Multi/RGB+: Edge LED

Scanning Backlight 200 / 100Hz: 50Hz

Advanced Super View / Pure Black Panel: /

Viewing angle (horizontal/vertical): 176°/176°

Digital combfilter:

RECEIVING SYSTEM

DVB-T / Analogue: /

PAL-B/G, PAL-D/K, PAL-I: / /

SECAM-LL, SECAM-B/G, SECAM-D/K: / /

NTSC,PAL60 Hz: /AV input

STATION PRESETTING

Automatic Channel sorting:

Presets analogue tuner/digital tuner: Need to Tune/

AUDIOSYSTEM

Digital Technology:

Automatic Volume Control:

NICAM+A2-Stereo-Decoder/Virtual Dolby/Surround: / /

Output power: 3W + 3W

INTERFACES

S-Video/Video (Cinch) / Y/PB(CB)/PR(CR) via VGA Adapter: /

PC-Input Analog / HDMI / RS-232C: Yes/HDMI X3/Yes

GENERAL

Cabinet Colour: Red

Power Consumption Stand-by (W): 0.6W

Power Consumption Operation (W): 31W

Dimensions with Stand in mm (W x H x D): 536 x 373 x 170

Dimensions (W x H x D) in mm: 536 x 342 x 63

Weight incl. Stand (kg): 4.8 Kg

Wallmount: yes (Picture frame type)

Powered by TCPDF (www.tcpdf.org)

www.sharpmea.com SHARP HEADQUARTERS FOR MIDDLE EAST & AFRICA

JEBEL ALI FREE ZONE

P. O. BOX 17115 – DUBAI

UAE

PHONE: +971 4 8815311, FAX: +971 4 8816692, INTERNET: WWW.SHARPMEA.COM
