OPTION 2 - Surface Plate (Concrete Mount)
IMPORTANT: When concreting the in-ground anchor in place, make sure not to get slurry in
the screw threads. Either apply tape over the holes on both sides of the anchor or place the
spigot bolts in the threads and withdraw them with the concrete is set. Make sure that the
in-ground anchor is perfectly level. Allow the concrete to cure for the appropriate cure time for
your area before installing the umbrella onto the fitting.
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate/
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the in-ground
anchor.
STEP 1 Bolt Surface Plate to Concrete
Fix the surface plate to an existing
concrete slab using concrete bolts
STEP 2 Bolt Spigot to Surface Plate
Bolt the spigot plate to the surface plate
using the five (5) spigot bolts included with
umbrella.Insert the spigot bolts downward
through the holes in the spigot plate and
screw them into the threaded holes in the
surface plate. The spigot bolts should be left
just loose enough to allow final adjustment of
the orientation of the umbrella if necessary, then once correctly orientated,fully tighten
the spigot bolts.
You are now ready to operate your umbrella!
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate or
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the surface
plate.
OPTION 1 - In-Ground Anchor
STEP 2 Bolt Spigot to In-ground Anchor
Once the concrete is cured, bolt the spigot plate to the in-ground anchor plate using the five (5)
spigot bolts included with umbrella. Insert the spigot bolts downward through the holes in the
spigot plate and screw them into the threaded holes in the in-ground anchor. The spigot bolts
should be left just loose enough to allow final adjustment of the orientation of the umbrella if
necessary, then once correctly orientated, fully tighten the spigot bolts.
You are now ready to operate your umbrella!
STEP 1 Preparation
The in-ground anchor needs concreting in
the ground as per the diagram (right).
Concrete Footing
In-Ground Anchor
Ground Level
Threaded holes for
bolting Spigot plate to
In-Ground Anchor
Flare at bottom
Spigot
Spigot Plate
Spigot Bolts
Spigot Plate
Spigot Bolts
Spigot
Surface Plate
Concrete
Threaded holes for bolting spigot
plate to the Surface Plate
Countersunk holes
for bolting to concrete
Concrete
Bolts
The 1.0m deep x 0.5m wide hole size
recommended assumes the terrain is
thick clay. Should the terrain be fine soil
or sand, the hole size should be increased.
The recommended installation requires
approximately .50 cubic meters of
concrete for silty or fine soil and
approximately .25 cubic meters of
concrete for heavy clay.
